Key Features:
Integrated 10/100/1000 transceiver
Plug-and-Play compatible
Support IEEE 802.1q VLAN tagging
Transmit/Receive FIFO (32K) support
Support Wake-on-LAN (WoL) function and remote wake-up
Crossover Detection & Auto-Correction
16KB Jumbo Frame Support
Minimum System Requirement:
Pentium compatible process 200 MHz and above
Minimum 32MB RAM
Minimum 30MB available hard disk space
CD-ROM drive
One PCI slot
|
Interface Port
|
RJ-45 connectorPCI
specification 2.2 compliant
|
|
Data Connection
|
Data transfer rate: 10/100/1000Mbps
32K transmit FIFO and receive FIFO
|
|
Standard Compliance
|
IEEE 802.3 10BaseT
IEEE802.3u 100BaseTX
IEEE802.3ab 1000BaseT
IEEE 802.3x Full Duplex Flow Control
IEEE 802.1q VLAN tagging
|
|
Power Managerment
|
Wake-on-LAN (WoL)
|
|
LED
|
ACT: ON-NIC card is functioning
10: Flashing-NIC card is transferring data at 10Mbps
100: Flashing-NIC card is transferring data at 100Mbps
1000: Flashing-NIC card is transferring data at 1000Mbps
|
|
Dimension
|
119 (L) x 43 (W) x 16(H) mm
|
|
Unit Weight
|
50g
|
|
Power Consumption
|
1.5W
|
|
Environmental Specification
|
Operating temperature: 0C ~55C
Operating humidity: 5% ~95% (non-condensing)
Storage temperature: -25C ~75C
|
|
Emission
|
CE, FCC, VCCI, C-Tick MIC
|
|
Support OS
|
Window 98/98SE, ME, 2000 and XP
|
