Processor / System Bus
|
2 * Socket LGA771
Dual/Quad Core IntelXeon Processor 5000/5100/5300 Sequence
FSB 667/1066/1333MHz EM64T 2 x 2M or 4M L2 cache
|
|
Core Logic
|
Intel 5000P MCH
Intel 6321ESB I/O Controller Hub
|
|
Form Factor
|
SSI EEB 3.61, 12" x 13"
|
|
ASUS Features
|
Smart Fan: Smart Fan II
Rack Ready (Rack and Pedestal dual use):
ASWM2.0:
|
|
Memory
|
Total Slots: 12
Capacity: Maximum up to 48 GB
Memory Type: Four Channel (3 DIMMs per Channel) ECC Reg. DDR2 533/667 Fully-Buffered DIMM
Memory Size: 512 MB, 1 GB, 2GB, 4GB
|
|
Expansion Slots
|
Total Slots: 6 Slot 11 * PCI-X 133/100 MHz(support Zero Channel RAID card)
Slot 2: 1 * PCI-X 133/100 MHz
Slot 3: 1 * PCI-E x 8
Slot 4: 1 * PCI-E x 8
Slot 5: 1 * PCI-E x 16 (x 8 link)
Additional Slot 1: 1 * SODIMM socket for ASMB3-SOL
* Slot allocation is based on SSI EEB / CEB / ATX definition
|
|
Storage
|
IDE Controller
Intel 6321 ICH:
1 * Single Channel Bus Master IDE support UltraATA 33 / 66 / 100
SATA Controller
Intel 6321 ICH:
6 SATA2 300MB/s ports
Intel Matrix Storage(Windows) support RAID 0, 1, 0+1, RAID 5 (S/W)
SCSI Controller
-
SAS Controller
LSI 1068 PCI-X 8 ports SAS controller:
2 Mini-SAS x 4 connectors support RAID 0, 1, 1E
Optional LSI ZCR(Zero-Channel-RAID) PCI-X card:
upgrade to support RAID 5
|
|
Networking
|
LAN: Intel 82563EB Network Connection (Dual Port)
|
|
Graphic
|
VGA: ATI ES1000 VGA Controller / 32MB DDR VRAM
|
|
Onboard I/O Connectors
|
Floppy Connector: 1
PSU Connector: 24-pin ATX power connector + 8-pin ATX 12V power connector + 4-pin ATX 12V power connector
Management Connector: SODIMM socket for ASMB3-iKVM or ASMB3-SOL
USB Connectors: 1 (support 2 USB ports)
Fan Header: 10 * 4-Pin
SMBus: 2
Chassis Intruder: 1
Front LAN LED: 2
Serial Port Header: 1
|
|
Rear I/O Connectors
|
External Serial Port: 1
External USB Port: 2
VGA Port: 1
RJ-45: 2
PS/2 KB/Mouse: 1
|
|
Management Solution
|
Software: ASWM2.0
Out of Band Remote Management: Optional (ASMB3-SOL)
|
|
Monitoring
|
CPU Temperature:
FAN RPM:
|
|
EMI
|
US (FCC, CFR47 Part 15, Class B)
Europe (CE, EN55022 & EN55024)
|
|
Environment
|
Operation temperature: 10 ~ 35
Non operation temperature: -40 ~ 70
Non operation humidity: 20% ~ 90% ( Non condensing)
|
