Display technology
|
0.65", 1-Chip DMD, 12 deg. LVDS, Dark Chip 2 with DDP3020
|
Video input terminals
|
Composite RCA X 1
|
| S-Video X 1 |
|
Component (Y, CB, CR) x 1
|
|
Resolution
|
1280 x 768 (Total 983,040 pixels), 600 Video Lines
|
Output terminals
|
12V Trigger Out
|
|
Brightness
|
2000 ANSI lumens
|
Stereo mini jack ( 3.5mm) x 1
|
|
Contrast
|
2500:1 (on / off)
|
Communication terminals
|
RS-232C (8pin) x 1 (Direct command is available)
|
|
USB (Only for service)
|
|
Audio speaker
|
N/A
|
|
Picture size
|
40" ~ 275 " (100"=3.3m)
|
Fan noise
|
31dBA ( lamp mode low)
|
|
Source lamp
|
250W (Shut Off Time 2000Hrs) with Low Mode (200W: Shut Off Time 4000Hrs)
|
Dimensions (WxHxD)
|
310 x 100 x 245 mm (excluding stand)
|
|
Computer compatibility
|
VGA ~ SXGA (640 x 480 ~ 1280 x 1024)
|
Weight
|
2.9 kg
|
|
True : 1280 x 768, 1280 x 800 - Sync on green available
|
Power supply
|
AC100 ~ 120V / 220-240V / 10%, 50/60Hz
|
|
Video compatibility
|
NTSC / NTSC 4.43 / PAL (including PAL-M, N) / SECAM / PAL-60
|
Approximate figure representing average operational life cycle.
*Dark Chip 2, BrilliantColour, Digital Light Processing and DLP are trademarks of Texas Instruments.
*Windows is a registered trademark of Microsoft Corporation.
*Macintosh is a registered trademark of Apple Computer Inc.
*SXGA, XGA and SVGA are registered trademarks of IBM Corporation.
*All brand names and product names are trademarks, registered trademarks or trade names of their respective holders.
|
|
Component Video: 480i/p (525i/p), 576i/p (625i/p), 720p (750p 50/60Hz), 1080i (1125i 60Hz), 1080i(1125i 50Hz), SCART (RGB + 1V sync)
|
|
PC Input terminals
|
HDMI X 1; RGB:mini D-sub 15 pin x 1
|
