Video System:
|
|
Standard:
|
|
HDV 1080i / DV
|
|
Sensor:
|
|
1/2.7 inch Canon progressive HD CMOS sensor
|
|
Filter Array:
|
|
Primary Colour Filter (RGB Bayer)
|
|
Image Processor:
|
|
DiG!C DV II
|
|
Image Pixels:
|
|
Total:
|
|
2,9600,000 (1994 H x 1484 V)
|
|
Movie:
|
|
2.07MP (HD/DV 16:9)
|
|
Still Image:
|
|
2.76MP (4:3)
|
|
Widescreen Capability:
|
|
High Resolution Real Widescreen 16:9
|
|
Lens:
|
|
Type:
|
|
Canon High Definition Video Lens
|
|
Focal Length:
|
|
6.1 - 61mm
|
|
Maximum Aperture:
|
|
f/1.8-3.0 (tape)
|
|
Minimum Focusing Distance:
|
|
10mm
|
|
Shutter Speed:
|
|
Tape: 1/6 - 1/2000 sec / Card: 1/2 - 1/500 sec
|
|
Optical Zoom / Digital Zoom:
|
|
10x / 40x/200x (tape)
|
|
Image Stabilizer:
|
|
Super Range Optical Image Stabilization
|
|
Focusing :
|
|
AF System:
|
|
Hi-Speed Instant Auto Focus (Instant AF) / Normal AF
|
|
Focusing Range:
|
|
Auto / Manual / Forced Infinity / Dedicated switch and focus dial
|
|
Control/Balance:
|
|
Light Metering Method:
|
|
Evaluative / Centre-weighted average / Spot metering
|
|
Exposure Compensation:
|
|
11 Levels
|
|
White Balance Mode:
|
|
Auto, TTL, 6 Presets (Daylight / Shade / Cloudy / Tungsten / Fluorescent / Fluorescent H)
|
|
Back Light Correction:
|
|
Dedicated BLC button
|
|
Illumination:
|
|
Minimum Illumination:
|
|
0.2 lux (Night Mode) / Advanced illumination with gapless micro lens technology on CMOS
|
|
Flash:
|
|
Built in (Auto / On / Off / Slow-synchro / Red eye reduction is available)/Other flash supported via accessory shoe
|
|
Video Light:
|
|
Built in low luminance AF auxiliary video LED light with manual switch / Other video light supported via accessory shoe
|
|
Further Support:
|
|
Accessory shoe supports attachable flash (VFL-1) & video light (VL-3)
|
|
LCD Monitor/Viewfinder:
|
|
LCD:
|
|
2.7 inch Real Widescreen / approx. 211,000 pixels and AR coated. Brightness & backlight controls.
|
|
Viewfinder :
|
|
0.27 inch Real Widescreen & colour / 123,000 pixel / Filming Modes & Controls
|
|
AE Modes / Scene Modes (SCN):
|
|
13 modes. AUTO, [P], (P / Av / Tv / SCN / CINE (progressive HDV 25PF)) / Portrait / Sports / Night / Snow / Beach / Sunset / Spotlight / Fireworks
|
|
Image Quality Adjustment:
|
|
8 adjustments. Vidid / Neutral / Low Sharpening / Soft Skin Detail / Brightness / Contrast / Sharpness / Colour Depth
|
|
Effects:
|
|
Tape: Black & White, Sepia, Art / Card: Black & White, Sepia
|
|
Fades:
|
|
Auto Fade, Wipe Fade
|
|
Recording Formats:
|
|
Video Data:
|
|
HDV 1080/50i, 1080/25P, DV (PAL)
|
|
Recording Modes:
|
|
SP / LP (DV only)
|
|
Audio:
|
|
Audio Data:
|
|
HDV: MPEG1 Audio Layer II (16 - bit) / DV: PCM 16 bit 2 channels (48 kHz) or 12-bit 4 channels (32 kHz)
|
|
Audio Level Metering:
|
|
Manual audio level VR metering and control with adjustment via LCD / Four channel audio playback
|
|
Wind Screen:
|
|
Available
|
|
Still Image Recording:
|
|
Capture Sizes:
|
|
3.15 megapixel (2048 x 1536 4:3) / 2.07 megapixel (1920 x 1080 16:9)
|
|
Memory Card:
|
|
Mini SD (photo recording only)
|
|
Still Shooting Functions :
|
|
Simultaneous Photo Recording to Mini SD / Auto Exposure Bracketing / High Speed Continuous Shooting (x frames/sec) / 9-point AiAF
|
|
Still image file transfer:
|
|
USB
|
|
Direct Printing:
|
|
PictBridge and dedicated Direct Print/Print Share button
|
|
Interface:
|
|
Accessory Shoe:
|
|
Advanced Accessory Shoe for flash and guide light /
|
|
Terminals:
|
|
HDV/DV in/out / AV in/out / Component out / HDMI output / Headphone and Microphone terminals / USB Full Speed
|
|
Streaming:
|
|
IEEE1394 (MPEG2-TS/DV) / Analogue to Digital Converter
|
|
Down Converting:
|
|
Yes. Both analogue and digital
|
|
Included Accessories:
|
|
Wireless controller :
|
|
WL-D87 (Remote battery CR2025)
|
|
Battery Pack:
|
|
BP-2L13
|
|
Compact Power Adaptor :
|
|
CA-570
|
|
Stereo Video Cable :
|
|
STV-250N
|
|
Component Cable :
|
|
CTC-100/S
|
|
Software:
|
|
Digital Video Solutions Disk / USB Cable & AC Cable
|
|
Optional Accessories:
|
|
Battery Pack :
|
|
NB-2L / NB-2LH / BP-2L13 / BP-2L14
|
|
Compact Power Adapter :
|
|
CA-570
|
|
Battery Charger :
|
|
CB-2LTE / CB-2LWE
|
|
Component Cable :
|
|
CTC-100/S / CTC-100
|
|
Tele Converter Lens:
|
|
TL-H43
|
|
Wide Converter Lens:
|
|
WD-H43
|
|
Filter set :
|
|
FS-H43U / FS-43U II
|
|
Video Light :
|
|
VL-3
|
|
Video Flash Light :
|
|
VFL-1
|
|
Battery video light :
|
|
VL-10L (with battery pack from BP-9** series)
|
|
Soft Carrying Case :
|
|
SC-1000 / SC-2000
|
|
DV Cable :
|
|
CV-150F / CV-250F
|
|
Wrist Strap :
|
|
WS-20
|
|
Shoulder Strap :
|
|
SS-900
|
|
Digital Video cassette :
|
|
HDVM-E63PR / DVM-E60 / DVM-E80
|
|
Car Battery Adapter :
|
|
CBC-NB2
|
|
Interface Cable :
|
|
IFC-400PCI
|
|
SCART Adapter :
|
|
PC-A10
|
|
Other:
|
|
Self Timer:
|
|
10 sec/Remote Controller: 2 sec.
|
|
Search:
|
|
Date search, END search
|
|
Power Supply:
|
|
7.4V DC (battery pack), 8.4V (DC IN)
|
|
Power Save:
|
|
Power shutoff after recording continuously paused for 5 minutes
|
|
Dimensions:
|
|
88 x 80 x 138 mm (W x H x D)
|
|
Weight:
|
|
535 g (body only)
|
|
Operating Platforms:
|
|
PC: Windows 98SE, ME, 2000 (SP4), XP (SP1 & SP2) / Mac: OS X (v10.2 - v10.4)
|
|
*All data based on Canon's Standard Test Method:
|
|
*Subject to change without notice:
|
