Features
- Set & forget motion detection on 4 cameras simultaneously
- Easy save with USB connection straight to PC, DVD or CD
- Fast connect to TV, monitor & security cameras
- Runs really quickly with real-time quad viewing
- Control your cameras remotely with built-in PTZ function
|
Video Input Format
|
NTSC: BNC 4CH In / 2CH Out (Composite) PAL: BNC 4CH In / 2CH Out (Composite) |
|
Display Frame
|
NTSC: 120fps 4x30fps PAL: 100fps 4x25fps |
|
Recording Frame Rate (Quad Mode)
|
NTSC: Max. 30 fps (Quad) PAL: Max. 25 fps (Quad) |
|
Recording Frame Rate: (Each Mode)
|
NTSC: Max. 7.5 fps (Each) PAL: Max. 6.25 fps (Each) |
|
Compression Format (Each Channel)
|
Modified MJPEG (12-20K Bytes per frame) |
|
HDD
|
Over 250GB |
|
Recording Time:
|
9 days continuous with 80GB HDD @ 7 fps |
|
Recording Time
|
Continuous, Motion Detection, Sensor activated |
|
Sensor, Alarm:
|
4 Input, 1 Output |
|
USB Port
|
2.0 Version |
|
Power Adapter
|
110VAC / 12VDC 5A or 230VAC / 12VDC 5A |
|
Dimension (LxWxH)
|
315 x 224 x 52mm |
|
Weight
|
3.7 lb / 1.7 Kg |
|
Dimension:
|
12.40 x 8.81 x 2.04 / 315 x 224 x 52mm |
