| Form Factor |
microATX (9.60 inches by 9.60 inches [243.84 millimeters by 243.84 millimeters]) |
| Processor |
- Support for an Intel Core2 Duo processor in an LGA775 socket with a 1333 MHz system bus
- Support for an Intel Pentium Dual-Core processor in an LGA775 socket with an 800 MHz system bus
- Support for an Intel Celeron processor in an LGA775 socket with an 800 MHz system bus
|
| Memory |
- Two 240-pin DDR2 SDRAM Dual Inline Memory Module (DIMM) sockets
- Support for DDR2 800 MHz, or DDR2 667 MHz DIMMs
- Support for up to 8 GB of system memory
|
| Chipset |
- Intel G33 Express Chipset
|
| Audio |
Intel High Definition Audio (Intel HD Audio) subsystem in the following configuration:
- 6-channel (5.1) audio subsystem using the Realtek ALC888* audio codec
|
| Video |
Intel Graphics Media Accelerator 3100 (Intel GMA 3100) onboard graphics subsystem with Intel Clear Video Technology |
| I/O Control |
Legacy I/O controller for diskette drive, serial header, and PS/2* ports |
| LAN Support |
Gigabit (10/100/1000 Mbits/sec) LAN subsystem using the Intel 82566DC Gigabit Ethernet Controller |
| Peripheral Interfaces |
- Twelve USB 2.0 ports
- Four Serial ATA IDE interfaces
- Two IEEE-1394a interfaces (1 external port, 1 internal header)
- One Parallel ATA IDE interface with UDMA 33, ATA-66/100/133 support
- One serial port header
- One diskette drive interface
- PS/2 keyboard and mouse ports
|
| Expansion Capabilities |
- Two PCI Conventional* bus add-in card connectors
- One PCI Express* x1 bus add-in card connector
- One PCI Express x16 bus add-in card connector
|
| Microsoft Vista* Premium Ready |
With a PC built with Intel Core 2 Duo or Intel Core 2 Quad processors, and the Intel Desktop Board, you can experience a more responsive and manageable environment of Microsoft Windows Vista* including a new visual sophistication of the Windows Aero* interface. |
