| Form factor |
microATX (9.60 inches by 9.60 inches [243.84 millimeters by 243.84 millimeters]) |
| Processor |
- Support for an Intel Core2 Quad processor in an LGA775 socket with a 1066 or 800 MHz system bus
- Support for an Intel Core2 Duo processor in an LGA775 socket with an 1333, 1066 or 800 MHz system bus
- Support for an Intel Pentium dual-core processor in an LGA775 socket with an 800 MHz system bus
- Support for an Intel Celeron processor in an LGA775 socket with an 800 MHz system bus
|
| Memory |
- Four 240-pin DDR2 SDRAM Dual Inline Memory Module (DIMM) sockets
- Support for DDR2 800 MHz or DDR2 667 MHz DIMMs
- Support for up to 8 GB of system memory
|
| Chipset |
Intel Q35 Express Chipset |
| Audio |
Intel High Definition Audio subsystem in the following configuration:
- 2+2-channel audio subsystem using the RealTek* ALC268 audio codec
|
| Video |
Intel Graphics Media Accelerator 3100 onboard graphics subsystem |
| I/O control |
Legacy I/O controller for serial ports |
| LAN support |
Gigabit (10/100/1000 Mbits/sec) LAN subsystem using the Intel 82566DM Gigabit Ethernet Controller |
| Peripheral interfaces |
- Twelve USB 2.0 ports
- Six Serial ATA IDE interfaces
- Two IEEE 1394a ports (1 external port, 1 internal header)
- One Parallel ATA IDE interface with UDMA 33, ATA-66/100/133 support
- One serial port
|
| Expansion capabilities |
- One PCI Conventional* bus add-in card connector
- Two PCI Express* x1 bus add-in card connectors
- One PCI Express x16 bus add-in card connector
|
| Microsoft Windows Vista* Home Premium ready |
With a PC built with Intel Core 2 Duo or Intel Core 2 Quad processors, and the Intel Desktop Board, you can experience a more responsive and manageable environment of Microsoft Windows Vista including a new visual sophistication of the Microsoft Windows Aero* interface. |
