ATEN CE-700 KVM Console Extender - USB, 1280x1024 to 150m, USB Overcurrent Detection and Prevention

No Longer Available

Part Number:

75714

(?) Brand:

ATEN

Manuf No:

KVM-CE700
KVMCE700

Shipping Weight:

1 KG (Includes product packaging)
Estimate Shipping

Add to wishlist

Write a Review

Details Files Images & Video

All stock codes associated to this product

KVMCE700, KVM-CE700

KVM Extender

CE700 KVM Extender is a console extender with built-in USB and automatic signal compensation function. It allows remote users to connect and access to the computer via the console conveniently. This allows users to deploy system equipment in a safe environment for managing highly confidential data systems.

Features

	Uses Cat 5e cable to connect the local and remote units (up to 150m apart)
	Dual Console Operation - control your system from both the local and remote
	USB keyboard, USB mouse, and monitor consoles
	Supports USB Keyboard and USB Mouse
	Pushbutton selection - sequential selection between local and auto mode
	Automatic Gain Control - automatically adjusts signal strength to compensate for distance
	USB overcurrent detection and prevention
	High video resolution - up to 1280 x 1024
	Supports DDC2B for local monitor
	Supports VGA, SVGA, and Multisync Monitors
	Multiplatform support: Windows 2000/XP/Vista and Linux.

Package Content

	1x USB Console Extender (Local Unit)
	1x USB Console Extender (Remote Unit)
	1x USB KVM Cable
	2x Power Adapters
	1x User Manual

Diagram

Specification

Connectors	Console Ports (Local)	Keyboard	1 x USB Type A Female (White)
		Video	1 x HDB-15 Female (Blue)
		Mouse	1 x USB Type A Female (White)
		Unit to Unit	1 x RJ-45 Female (Black)
		Power	1 x AC Jack (Black)
	KVM Ports (Local)	Keyboard /Mouse	1 x USB Type B Female (White)
		Video
			1 x HDB-15 Male (Blue)
	Console Ports (Remote)	Keyboard	1 x USB Type A Female (White)
		Video	1 x HDB-15 Female (Blue)
		Mouse	1 x USB Type A Female (White)
		Unit to Unit	1 x RJ-45 Female (Black)
		Power	1 x AC Jack (Black)
LEDs (Local)	Local		1 (Green)
	Remote		1 (Green)
LEDs (Remote)	Status		1 (Green)
	On Line		1 (Green)
Emulation	Keyboard / Mouse		USB
Switches	Selection Mode		1 x Pushbutton
Video			1280 x 1024
Signal Range			150m (500')
Power Consumption			AC9V, 6.8W (Local) AC9V, 7.4W (Remote)
Environment	Operating Temp.		0 - 50C
	Storage Temp.		-20 - 60C
	Humidity		0~80% RH, Non-condensing
Physical Properties	Housing		Metal
	Weight	Local	0.30kg
		Remote	0.22kg
	Dimensions (L x W x H)	Local	13.00 x 10.00 x 3.50 cm
		Remote	13.00 x 10.00 x 3.50 cm
