Hardware Specifications
|
Network Interfaces
|
|
WAN
|
1 x 10/100/1000 Mbps Ethernet Port
|
|
LAN
|
1 x 10/100/1000 Mbps Ethernet Port
|
|
Wireless (optional)
|
IEEE 802.11b/g (using approved USB Dongles)**
|
|
Storage
|
|
HDD Bay
|
3 x 3.5 SATA HDD
|
|
HDD Capacity
|
80/120/160/200/250/300/400/500/750
|
|
IO Interfaces
|
|
PCI Interface
|
For proprietary Thecus application
|
|
eSATA Interface
|
1 x eSATA port (Back)
|
|
USB
|
2 x USB 2.0 ports (Front x1, Back x1)
|
|
IR receiver
|
For future options
|
|
System Information
|
|
LED Indicators
|
1 x Power LED
2 x Network link + activity LED
3 x Hard drive power + activity LED
|
|
LCD Module
|
For basic configurations and status display
|
|
Power Supply
|
|
External Adapter
|
AC 100 ~ 240 Volt, 50/60 Hz, auto detection
|
|
Environment
|
|
Safety and Environment
|
CE, FCC, BSMI, C-Tick, VCCI, RoHS Compliant
|
|
Temperature
|
5 to 40
|
|
Humidity
|
0 ~ 80% R.H. non-condensing
|
Software Specifications
|
Network
|
|
Configuration
|
Fixed IP address, Dynamic IP address, PPPOE, DDNS
|
|
Network File Protocols
|
Microsoft Networks (CIFS/SMB)
Apple Filing Protocol (AFP 3)
File Transfer Protocol (FTP)
WebDisk through Hyper Text Transfer Protocol (HTTP) or Secure Hyper Text Transfer Protocol (HTTPs)
|
|
Network Client Type
|
Microsoft Windows NT/2000/XP/2003/Vista
Unix/Linux/BSD
MAC OS X, OS 9, OS 8.6
|
|
DHCP Server
|
Assigning IP address on LAN/WLAN ports
|
|
Disk management
|
|
RAID
|
RAID 0, 1, 5, and JBOD
Auto Rebuild
Hot Swappable
Hot Spare
Disk Roaming
|
|
Power Management
|
Disk idle spin-down
|
|
External USB
|
HDD/Flash disk support
|
|
Multimedia Support
|
|
Media Server
|
Works with DLNA-certified players.
Supported File Types: MPEG, RMP, WPL, PLS, M3U, ASX, WAV, PNG, BMP, AVI, WMV, WMA, MP3, LPCM, JPEG
|
|
iTunes Server
|
Supported File Types: AAC, MP3, WAV
|
|
Photo Web Server
|
Supported File Types: GIF, JPG (JPEG), BMP, PNG
Support EXIF display
Support slide show
|
|
Web cam
|
Support Capture, preview, schedule
Support image size : 160 x 120, 320 x 240, 640 x 480
|
|
Share Management
|
|
User Authentication
|
Microsoft NT Domain Controller (PDC)*
Microsoft Active Directory Authentication (AD)* Supports built-in user accounts Supports built-in user groups
|
|
Folder Management
|
Share Folder Level Permission
Public Folder
|
|
File System
|
|
File System Type
|
Journaling File System
|
|
Language Support
|
Unicode Support
|
|
Authorization
|
Read, Write or Deny options on individual users or groups
|
|
Administration
|
|
Multi-Lingual Web-based Administration
|
Web-based server management Interface Supports English, Traditional Chinese, Simplified Chinese, Japanese, Korean, French, German, Italian, Spanish
|
|
Setup Wizard
|
MS Windows, MAC OS X device discovery and setup utility program
|
|
E-mail notification
|
Send system message via e-mail to specified e-mail accounts
|
|
NTP support
|
Network Time Protocol support
|
|
Backup
|
|
Thecus Backup Program
|
Thecus Backup Utility (Client backup utility; supports Microsoft Windows XP/2000 /MAC OS X)
|
|
USB copy
|
Copy USB Mass storage device contents to specified location to NAS
|
|
Misc.
|
|
Print Server
|
Network printing through Internet Printing Protocol (IPP) using USB printer
|
|
Download Manager
|
Support BT, FTP, HTTP schedule download
|
|
Schedule on/off
|
Schedule on/off form power saving
|
*PDC/AD support: Works as a client member in a Microsoft NT 4.0 domain/Active Directory domain, allowing the N3200 to utilize the domain users and groups setting for authentication to the system and authorization to the share folders.
**For supported USB dongles, please contact [email protected]
|
