| FSB 1333 |
- Speed up to FSB 1333 |
 |
|
Intel's best processor for multimedia applications with up to 80 percent faster performance for highly-threaded applications and four processing cores to handle the most massive throughput, the Intel Core 2 Extreme quad-core processor provides exceptional performance. With the I-N73HD you are prepared for the latest 65nm and next generation 45 nm multi-core CPUs. With processors supporting Intel's SpeedStep Technology (EIST) the I-N73HD offers even more advanced energy efficiency.
|
|
|
4 Phase PWM
|
- Better Power Switch Efficiency, and power supply |
 |
|
Each phase is composed of one high-side MOS and two low-side MOS. This design brings the system with better power switch efficiency. Also, with 4-phase-PWMs, the system is providing better power supply and increased stability.
|
|
|
PWM Heatsink
|
- Less heat, Uncreased Performance |
 |
|
With a dedicated heatsink on the PWM area, generated heat is efficiently dissipated, providing end-users with a more consistent and stable environment.
|
|
| nView |
- NVIDIA nView multi-display support |
|
|
|
NVIDIA's nView technology enables you to use two monitors at a time. The user can either use each monitor for displaying different content, or use two monitors to show the same content. Instead of a second monitor you can also, for example, use a projector.
|
Multiple Display
|
Entire Display |
|
|
| Digital Home for DIY-Live Your Way |
 |
|
HDMI
HDMI delivers uncompressed HD digital video and audio in one single cable. With HDMI application, images are transferred uncompressed to digital video and audio for the highest quality (signals transfer rate max. up to 5GB/s)
|
|
 |
|
USB
High Speed connection for digital video and audio and other high throughput multimedia and storage devices.
|
|
 |
|
D-SUB Connector
Standard Connector for conventional monitor
|
|
|
Optical
S/P DIP Out
|
- Connect to today's hottest digital audio devices without signal loss. |
 |
|
The Optical cable allows for the best digital audio quality and scalable music systems from 2 to 7.1 channels.
|
|
|
7.1 Channel
HD Audio
|
|
 |
|
Enjoy true surround sound at its best and create an enthralling sounds cape that puts you in the middle of the action. Multi-streaming and auto jack sensing add to your convenience.
|
|
 CPU |
Support Intel next generation 45nm Multi-core CPU
Designed for Intel socket 775 processors with 1333/1066/800MHz FSB
Support Intel Core 2 Extreme & Core 2 Quad & Core 2 Duo & Pentium Dual Core & Celeron Dual Core Processors
|
| Chipset |
NVIDIA GeForce7100/nForce 630i single chip
|
| Memory |
2 X 240-pin DIMM sockets support max. memory capacity 4GB
Supports DDR2-800 Un-buffered Non-ECC memory
|
| Graphics |
Integrated NVIDIA GeForce 7 Series Shader model 3.0 DirectX 9 graphics
|
| HDMI |
Support High Definition Video
Support Multi-channel audio
|
| LAN |
On board Gigabit PHY
|
| IEEE1394 |
On board PCI IEEE1394 Controller
|
| Audio |
On board 7.1 CH HD Audio
HDMI audio ready header (SPDIF header)
|
| Expansion Slots |
1 x PCI-E X16, 1 x PCI-E X 1, 2 x PCI
|
| Internal I/O |
1 x Floppy Port supports up to 2.88MB
1 x ATA 133/100 IDE Connector
3 x USB2.0 header, IEEE1394 x 1
1 x FP-Audio, 1 x HDMI Audio Header
4 x SATA 3Gb/s connectors
|
| Back Panel I/O |
1 x VGA, 1 x HDMI,
1 x PS/2 Keyboard, 1 x PS/2 Mouse
S/P DIF Out, IEEE1394 x 1
7.1 CH Audio connector (Front, Line-in, MIC-in, Center/Subwoofer, Surround, Rear Surround)
4 x USB2.0, 1 x RJ-45 LAN Connector
|
| Form Factor |
mATX form factor 244 x 244mm
PCB Color: Orange
|
| RoHS |
100% lead-free process and RoHS Compliant
|
| abit Engineered |
abit Softmenu Technology
|
|
