Processor / System Bus
|
1 * Socket LGA775
Intel CoreTM 2 Duo series
Dual-Core Intel Xeon 3000 series
Quad-Core Intel Xeon 3200 series
Next-Generation 45nm Intel Xeon Processor
Dual Core/Quad Core
FSB 800/1066/1333
|
|
Core Logic
|
Intel 3210 Memory Contoller Hub (MCH)
Intel ICH7R
|
|
Form Factor
|
ATX, 12" * 9.6"
|
|
ASUS Features
|
Smart Fan
Rack Ready (Rack and Pedestal dual use)
ASWM2.0
|
|
Memory
|
Total Slots: 4 (2-channel)
Capacity: Maximum up to 8GB
Memory Type: DDR2 667 / 800 Unbuffered , ECC / Non ECC
Memory Size: 256MB, 512 MB, 1 GB, 2GB
|
|
Expansion Slots (follow SSI Location #)
|
Total PCI/PCI-X/PCI-E Slots: 6
Slot Location 1: 1 * PCI 32bit/33 MHz
Slot Location 2: 1 * PCI 32bit/33 MHz
Slot Location 3: 1 * PCI 32bit/33 MHz
Slot Location 4: 1 * PCI-E x8 (x1 link)
Slot Location 5: 1 * PCI-E x16 (x8 link)
Slot Location 6: 1 * PCI-E x16 (x8 link)
Slot Location 7: -
Additional slot: 1* SO-DIMM socket for optional ASMB3-SOL
|
|
Storage
|
IDE Controller
Intel ICH7R:
1 * IDE support UltraATA 33 / 66 / 100
SATA Controller
Intel ICH7R:
4 SATA2 300MB/s ports
Intel Matrix Storage (for Windows only) (Support software RAID 0, 1, 10 & 5)
LSI MegaRAID (for Linux/Windows) (Support software RAID 0, 1& 10)
|
|
Networking
|
LAN: 4 * Broadcom BCM5721 PCI-E GbE LAN
|
|
Graphic
|
VGA: XGI Z9s DDR2 32MB
|
|
Onboard I/O Connectors
|
Floppy Connector: 1
Management connector: 1* SO-DIMM socket for optional ASMB3-SOL
PSU Connector: 24-pin ATX power connector + 8-pin ATX 12V power connector + 4-pin ATX 12V power connector
USB Connectors: 1 (support 2 USB port)
Fan Header: 5 * 4pin
SMBus: 1
Chassis Intruder: 1
Serial Port Header: 1
|
|
Rear I/O Connectors
|
External Serial Port: 1
External USB Port: 2
VGA Port: 1
RJ-45: 4
PS/2 KB/Mouse: 1
|
|
Management Solution
|
Software: ASWM2.0
Out of Band Remote Management: Optional (ASMB3-SOL)
|
|
Monitoring
|
CPU Temperature
FAN RPM
|
|
EMI
|
US (FCC, CFR47 Part 15, Class B)
Europe (CE, EN55022 & EN55024)
|
|
Environment
|
Operation temperature: 10 ~ 35
Non operation temperature: -40 ~ 70
Non operation humidity: 20% ~ 90% ( Non condensing)
|
|
Accessories
|
Standard Gift Box Pack (3pcs per Carton)
Manual, SCD, I/O shield, SATA Cable, SATA Power Cable, IDE/Floppy Cable(3 in 1)
Standard Bulk Pack (10pcs per Carton)
Manual, SCD, I/O shield
|
