| Form Factor |
Extended ATX (eATX) (12.00 inches by 13 inches [304.80 millimeters by 330.2 millimeters])
|
| Processor |
- Support for 45nm Intel Core2 Extreme processors in an LGA771 socket with a 1600 MHz system bus
- Support for both 45nm & 65nm Intel Xeon processors in an LGA771 socket with a 1600, 1333, or 1066 MHz system bus
|
| Memory |
- Four Fully Buffered DIMM (FBDIMM) DDR2 Module sockets
- Support for FBDIMM DDR2 800MHz, 667 MHz, DIMMs
- Support for up to 8 GB of system memory
- Support for ECC and non-ECC memory
|
| Chipset |
Intel 5400 Express Chipset |
| Audio |
Intel High Definition Audio subsystem in the following configuration:
- 8-channel (7.1) Dolby Home Theater Audio subsystem with five analog audio outputs and two S/PDIF digital audio outputs (coaxial and optical)
|
| Nvidia SLI* and ATI CrossFire* multi-GPU platform support |
Nvidia SLI and ATI CrossFire technology enables two graphics cards to work together for ultimate 3D gaming performance and visual quality
|
| I/O control |
I/O controller for Consumer IR |
| LAN support |
Gigabit (10/100/1000 Mbits/sec) LAN subsystem
|
| Peripheral interfaces |
- 10 USB 2.0 ports (6 external ports, 2 internal headers)
- Six Serial ATA 3.0 Gb/s ports, including 2 eSATA port with RAID support supplied by a Marvell* controller
- Two IEEE-1394a ports (1 external port, 1 internal header)
- Consumer IR receiver and emitter (via internal headers)
- One Parallel ATA IDE interface with UDMA 33, ATA-66/100 support (2 devices supported)
|
| Expansion capabilities |
- Two PCI Conventional* bus add-in card connectors (SMBus routed to both PCI Conventional bus add-in card connectors)
- Four primary PCI Express* 1.1 x16 (electrical x16) bus add-in card connector
|
| Microsoft Windows Vista Premium* Ready |
With a PC built with Intel processors and an Intel Desktop Board, you can experience a more responsive and manageable environment of Microsoft Windows Vista including a new visual sophistication of the Microsoft Windows Aero* interface.
|
