ASUS WL-AM604G Modem/Wireless Router - ADSL2/2+, 4-Port 10/100 Switch, 2x USB


Large image is available

Product May Vary From Image

Our Price:Discontinued

Techbuy Part No:82563
Usually Ships: No Longer Available Details
Brand:ASUS Web Site
Manuf No:WL-604G
 WL604G
Shipping Weight:1.5 KG How Much?
Date Added:2/4/2008
Rating: Not Rated
Currency:AUD Convert

Product Description

WL-AM604g
Wireless ADSL 2/2+ Home Gateway with 4 Ethernet Ports
Your first all-in-one solution at home! with Asus ADSL QuickSetup and EZQoS bandwidth management!

Wireless router + ADSL modem in ONE device
Support both ADSL 2 and ADSL 2+, which is capable of delivering up to 24Mbps of downstream data rate, depending on the service providers and actual distance. 802.11g wireless LAN standard provides 54Mbps data rate in the LAN.

"Quick Setup" auto-detection of local ADSL settings

  • Powered by a well-defined ADSL connection database
  • Auto-detection of local ISP settings (VPI/VCI/connection type) in almost every open channel ADSL-implemented territory.
  • No more complicated ADSL configuration! Modem & router in one box working in just a few clicks away.

EZQoS(Asus Bandwidth on Demand)
Intelligently optimizes network resources and automatically prioritizes network traffic to guarantee latency-free gaming experience.

WDS
Extend network coverage as an Internet gateway so that other routers and their client devices can connect to the Internet through WL-AM604g*Based on Broadcom solution.

Enhanced Security
Double firewall: NAT and SPI, protecting your LAN, your family from the attack of bad incoming traffic.





Specification
Features
  • T1.413 Issue 2, G.dmt, and G.lite compliant
    • Supports full range of ADSL standards
  • ADSL2/2+, RE-ADSL Support
  • Wireless Ethernet IEEE 802.11b/g support
  • Compatible with all major DSLAMs
  • F5 OAM Loopback/Send and Receive
  • Multiple PVC up to 8 support
  • Annex A support
ADSL Features
  • RADSL (ANSI T1.413 Issue 2)
  • G.dmt ADSL over POTS (G.992.1 Annex A)
  • G.lite (G.992.2)
  • G.hs (G.994.1)
  • Auto-negotiating rate adaptation
  • ADSL2 G.dmt.bis (G.992.3)
  • ADSL2 G.lite.bis (G.992.4)
  • ADSL2+ (G.992.5)
Protocol Support
  • ANSI T1.413 issue 2
  • ITU-T G.992.1, G992.2, G994.1
  • RFC 1483/2684 (Bridged/Routed Ethernet over ATM)
  • Support PPP over ATM (RFC 2364)
  • Support PPP over Ethernet (RFC 2516)
  • ITU-T 1.610 F4-F5 OAM Send and Receive/Loop back
  • Transparent Bridge Support
  • PAP/CHAP/MS-CHAP for password authentication support
  • DHCP Server/Client
  • DNS Relay Agent
  • DMZ Support
  • PPP Always on with configurable timeout
Connector
  • Four Ethernet 10/100Mbps Base-T
  • One RJ-11 port for ADSL connection
  • Power Jack
Wireless
  • IEEE 802.11, 802.11b, and 802.11g compliant
  • Conforms to Wireless Ethernet Compatibility Alliance (WECA)
  • Supports 802.11b and 802.11g simultaneously
  • Support seamless WLAN roaming
  • Support Direct Sequence Spread Spectrum (DSSS) technology
  • Modulation: DFDM with BPSK, QPSK, 16QAM, 64QAM, DBPSK
  • Wireless Media Access Protocol: CSMA/CA with ACK
Compliance Certificates
  • FCC Part 15, Part 68
  • CE Mark
Management
  • Web-base Configuration GUI
  • Command-line interpreter (CLI)
  • Telnet Remote Management
  • FTP/TFTP firmware upgrade and configuration backup/restore
  • Syslog Support
Security
  • NAT for Basic Firewall Support
  • Packet Filtering Firewall Support
  • Stateful Packet Inspection Ssupport
  • Protection against Denial of Service attacks
  • Password Authentication to Modem
Environmental
  • Operating Temperature: 0C ~ 50C
  • Humidity: 5% ~ 95% (non-condensing)
  • Storage Temperature: -40C ~ 70C

- All specifications are subject to change without notice. Please check with your supplier for exact offers. Products may not be available in all markets.
- PCB color and bundled software versions are subject to change without notice.
- Brand and product names mentioned are trademarks of their respective companies.


Product Warranty


1 Year Return to Base
