Gigabyte GA-EG31MF-S2 Motherboard
LGA775, G31, 1333FSB, 4x DDR2-800, PCI-Ex16, 4x SATA-II, GigLAN, 8Chl, Firewire, VGA, mATX


Large image is available
Product May Vary From Image

Our Price:Discontinued

Techbuy Part No:84546
Usually Ships: No Longer Available Details
Brand:Gigabyte Web Site
Manuf No:GA-EG31MF-S2
 GAEG31MFS2
Shipping Weight:2 KG How Much?
Date Added:13/5/2008
Rating: Not Rated
Currency:AUD Convert

Product Description

GA-EG31MF-S2
Intel  G31 + ICH7 Chipset
  1. Revolution energy saving design with GIGABYTE Dynamic Energy Saver(DES) technology.
  2. Supports Intel Core 2 multi-core and upcoming 45nm processors
  3. Ultra Durable2 design in CPU VRM
  4. Dual Channel DDR2 800 for outstanding system performance
  5. Integrated Intel Graphics Media Accelerator 3100 (Intel GMA 3100)
  6. Integrated SATA 3Gb/s interface
  7. Features Gigabit Ethernet and IEEE 1394 connection
  8. Integrated 8 channel High Definition audio


Overview

  GIGABYTE Dynamic Energy Saver


GIGABYTE Dynamic Energy Saver is a revolutionary technology that delivers unparalleled power savings with the simple click of a button. Featuring an advanced proprietary hardware and software design, GIGABYTE Dynamic Energy Saver is able to provide exceptional power savings of up to 70% and up to 20% improved power efficiency without sacrificing computing performance
  Intel  Core 2 multi-core and upcoming 45nm processors
GA-EG31MF-S2 with GIGABYTE Dynamic Energy Saver Technology supports Intel latest high performance CPU delivers the most energy-efficient performance. Based on Intel's Micro Architecture, the Intel multi-core processors with 4 cores and two shared L2 caches provide the best capability-per-watt solutions and are an ideal choice for multi-media enthusiasts and intensive multi-tasking environments. This cutting-edge processor offers significant performance boosts and provides an overall more energy efficient platform.
  Ultrab Durable2 for CPU VRM
Stable system operation depends upon the quality of CPU VRM (voltage regulator module). GIGABYTE adopts top quality highly efficient components of Ultra Durable 2 which includes Low RDS(on) MOSFETs, Ferrite core chokes, and Conductive Polymer Aluminum Solid Capacitors. Ultra Durable 2 for CPU VRM ensure a ultra cooling, lower power loss and longer lifespan for systems in daily operation and boost system stability under extreme conditions.
  PCI Express Interface
Revolutionary PCI Express interface provides scalable bandwidth for multi-purpose usage. PCI-E x16 interface delivers the utmost graphics experience; PCI-E x1interface delivers twice the bandwidth of PCI interface up to 250MB/s for new generation I/O peripheral devices.
  Dual Channel DDR2 800
Get a jump in memory performance with the advanced technology of DDR2 800 memory architecture, which delivers superior performance for the most demanding applications
  Intel GMA 3100
Intel Graphics Media Accelerator 3100 support Microsoft DirectX 9.0 and Windows Vista Aero experience. The 3D enhancement of GMA 3100 highly improves the realism and graphics performance.
  SATA 3Gb/s storage interface
The SATA specification doubles bus bandwidth from 1.5Gb/s to 3Gb/s. Native Command Queuing is a new specification that enables out-of-order execution of commands for efficient retrieval of data. Hot Plug support allows users to insert and remove hard disk drives without shutting off power to the system.
  Gigabit LAN connectivity
The Gigabit network interface delivers a high speed LAN connection with data transfer rate up to 1000Mb/s, providing new generation connectivity for the broadband era. Gigabit LAN is ideally for seamless internet connection such as streaming audio and video contents.
  IEEE1394 motherboard
This motherboard with IEEE1394 FireWire interface from Texas Instruments (TI). With the transfer speed up to 400Mb/s, the new generation IEEE1394 interface further enhances PC connectivity with consumer electronics audio/video (A/V) appliances, and storage peripherals.
  Smart
The Smart featured motherboards of GIGABYTE S-series provide GIGABYTE proprietary innovative software such as Download Center, @BIOS, Q-Flash, Xpress Install, Boot menu, and Smart Fan. BIOS and driver management now becomes much easier and user friendly through GIGABYTE Smart features!
  Safe
Safe is the key feature of GIGABYTE S-series motherboards with the following elements: Excellent hardware design reinforced BIOS protection through GIGABYTE Virtual Dual BIOS Technology and GIGABYTE BIOS Setting Recovery Technology. Unique system software such as Xpress Recovery 2, PC Health Monitor, HDD S.M.A.R.T., and C.O.M. further strengthen the stability and reliability of your PC!
  Windows Vista Premium Logo Certified
Windows Vista Premium promises to deliver a streamlined computing experience designed to fundamentally change how users view, find and organize their digital information. With G31/P965/G965/946/945 solutions all enabling support for Vista Premium, GIGABYTE offers a fresh and unique desktop experience that will be more informative, intuitive and completely new
  RoHS compliant
As a member of the global community to look after the environment, Gigabyte complies with the European Union's Restriction of use of certain Hazardous Substances (RoHS) directive which limits the use of lead, mercury, cadmium and other hazardous substances in electronic products.. From components and material selection to production processes, make up of accessories, packaging/color boxes etc; GIGABYTE has carefully examined and designed this product to be 100% RoHS compliant. GIGABYTE will continue to develop RoHS compliant PC components and commit valuable resources to promoting and advancing RoHS directive goals and objectives.

Specifications
CPU
  1. Support for an Intel  Core 2 Extreme processor/Intel  Core 2 Quad processor/Intel  Core 2 Duo processor/Intel  Pentium  processor Extreme Edition/Intel  Pentium  D processor/Intel  Pentium  4 processor Extreme Edition/Intel  Pentium  4 processor/Intel  Celeron  processor in the LGA 775 package
    (Go to GIGABYTE's website for the latest CPU support list.)
  2. L2 cache varies with CPU
Front Side Bus
  1. 1333/1066/800 MHz FSB
Chipset
  1. North Bridge: Intel  G31 Express Chipset
  2. South Bridge: Intel  ICH7
Memory
  1. 4 x 1.8V DDR2 DIMM sockets supporting up to 4 GB of system memory
  2. Dual channel memory architecture
  3. Support for DDR2 800/667 MHz memory modules
    (Go to GIGABYTE's website for the latest memory support list.)
Audio
  1. Realtek ALC888 codec
  2. High Definition Audio
  3. 2/4/5.1/7.1-channel
  4. Support for S/PDIF In/Out
  5. Support for CD In
LAN
  1. Realtek 8111C chip (10/100/1000 Mbit)
Expansion Slots
  1. 1 x PCI Express x16 slot
  2. 1 x PCI Express x1 slot
  3. 2 x PCI slots
Storage Interface South Bridge:
  1. 1 x IDE connector supporting ATA-100/66/33 and up to 2 IDE devices
  2. 4 x SATA 3Gb/s connectors supporting up to 4 SATA 3Gb/s devices
iTE IT8718 chip:
  1. 1 x floppy disk drive connector supporting up to 1 floppy disk drive
IEEE 1394
  1. T.I. TSB43AB23 chip
  2. Up to 2 IEEE 1394a ports (1 on the back panel, 1 via the IEEE 1394a bracket connected to the internal IEEE 1394a header)
USB
  1. Integrated in the South Bridge
  2. Up to 8 USB 2.0/1.1 ports (4 on the back panel, 4 via the USB brackets connected to the internal USB headers)
Internal I/O Connectors
  1. 1 x 24-pin ATX main power connector
  2. 1 x 4-pin ATX 12V power connector
  3. 1 x floppy disk drive connector
  4. 1 x IDE connector
  5. 4 x SATA 3Gb/s connectors
  6. 1 x CPU fan header
  7. 1 x system fan header
  8. 1 x front panel header
  9. 1 x front panel audio header
  10. 1 x CD In connector
  11. 1 x S/PDIF In/Out header
  12. 2 x USB 2.0/1.1 headers
  13. 1 x IEEE 1394a header
  14. 1 x power LED header
  15. 1 x chassis intrusion header
Back Panel Connectors
  1. 1 x PS/2 keyboard port
  2. 1 x PS/2 mouse port
  3. 1 x parallel port
  4. 1 x serial port
  5. 1 x D-Sub port
  6. 4 x USB 2.0/1.1 ports
  7. 1 x IEEE 1394a port
  8. 1 x RJ-45 port
  9. 6 x audio jacks (Center/Subwoofer Speaker Out/Rear Speaker Out/Side Speaker Out/Line In/Line Out/Microphone)
I/O Controller
  1. iTE IT8718 chip
H/W Monitoring
  1. System voltage detection
  2. CPU temperature detection
  3. CPU/System fan speed detection
  4. CPU overheating warning
  5. CPU/System fan fail warning
  6. CPU/System fan speed control
BIOS
  1. 1 x 8 Mbit flash
  2. Use of licensed AWARD BIOS
  3. PnP 1.0a, DMI 2.0, SM BIOS 2.4, ACPI 1.0b
Unique Features
  1. Support for @BIOS
  2. Support for Download Center
  3. Support for Q-Flash
  4. Support for EasyTune
  5. Support for Xpress Install
  6. Support for Xpress Recovery2
  7. Support for Virtual Dual BIOS
  8. Support for Dynamic Energy Saver
Bundle Software
  1. Norton Internet Security (OEM version)
Operating System
  1. Support for Microsoft  Windows  Vista/XP/2000
Form Factor
  1. Micro ATX Form Factor; 24.4cm x 23cm
Remark
  1. Due to different Linux support condition provided by chipset vendors, please download Linux driver from chipset vendors' website or 3rd party website.
  2. Due to most hardware/software vendors no longer offer support for Win9X/ME. If some vendors still has Win9X/ME drivers available, we will publish on website.


* The specification and pictures are subject to change without notice.
* All trademarks and logos are the properties of their respective holders.

* Due to standard PC architecture, a certain amount of memory is reserved for system usage and therefore the actual memory size is less than the stated amount.


Product Warranty


3-year Manufact.
