Processor / System Bus
|
2 * Socket LGA771
Quad-Core Intel Xeon 5400 Series (45nm)
Dual-Core Intel Xeon 5200 Series (45nm)
Quad-Core Intel Xeon 5300 Series
Dual-Core Intel Xeon 5000/5100 Series
Quad Core/Dual Core
FSB 667/1066/1333 MHz
|
|
Core Logic
|
Intel 5100 Memory Controller Hub (MCH)
Intel ICH 9R
|
|
Form Factor
|
SSI CEB 1.1 Compliant, 12"x10.5"
|
|
ASUS Features
|
Smart Fan
Rack Ready (Rack and Pedestal dual use)
ASWM2.0
|
|
Memory
|
Total Slots: 6 (2-channel)
Capacity: Maximum up to 48 GB*
Memory Type: DDR2 533/667 Reg. ECC
Memory Size: 512 MB, 1 GB, 2GB, 4GB
|
|
Expansion Slots (follow SSI Location #)
|
Total PCI/PCI-X/PCI-E Slots: 6
Slot Location 1: 1 * PCI-E x8 (x4 Link) ( Auto disable if AIO slot is occupied )
Slot Location 2: -
Slot Location 3: 1 * PCI 32bit/33 MHz
Slot Location 4: 1 * PCI-E x8 ( X8 Link)
Slot Location 5: 1 * PCI-E x8 ( X8 Link)
Slot Location 6: 1 * PCI-E x16 ( x16 Link) (Auto switch to x8 Link if slot 5 is occupied )
Additional Slot 1: 1* SO-DIMM socket for optional ASMB3-SOL
Additional Slot 2: 1* AIO Slot for Stroage expansion
|
|
Storage
|
IDE Controller
IT8213F (PCI to IDE)
SATA Controller
Intel ICH9R:
6 SATA2 300MB/s ports
Intel Matrix Storage (for Windows only)
(Support software RAID 0, 1, 10 & 5)
LSI MegaRAID (for Linux/Windows)
(Support software RAID 0, 1, 10)
SAS Controller
Optional:
ASUS PIKE 1064E 4-port SAS card
(Support software RAID 0,1,1E)
|
|
Networking
|
LAN: 2 * Broadcom BCM5721 PCI-E GbE LAN
|
|
Graphic
|
VGA: XGI Z9s PCI Display Controller 32MB
|
|
Onboard I/O Connectors
|
Floppy Connector: 1
PSU Connector: 24-pin ATX power connector + 8-pin ATX 12V power connector + 4-pin ATX 12V power connector
Management Connector: SO-DIMM socket for ASMB3
USB Connectors: 2 (support 4 USB ports)
Fan Header: 8 * 4Pin (With PWM control)
SMBus: 2
Chassis Intruder: 1
Front LAN LED: 2
Serial Port Header: 1
|
|
Rear I/O Connectors
|
External Serial Port: 1
External USB Port: 2
VGA Port: 1
RJ-45: 2
PS/2 KB/Mouse: 1
|
|
Management Solution
|
Software: ASWM2.0
Out of Band Remote Management: Optional (ASMB3-SOL)
|
|
Monitoring
|
CPU Temperature
FAN RPM
|
|
EMI
|
US (FCC, CFR47 Part 15, Class B)
Europe (CE, EN55022 & EN55024)
Australia (C-TICK)
|
|
Environment
|
Operation temperature: 10 ~ 35
Non operation temperature: -40 ~ 70
Non operation humidity: 20% ~ 90% ( Non condensing)
|
