Introduction
Based on the new Intel P43 chipset, GA-EP43-DS3L delivers a record setting 1600MHz Front Side Bus by overclocking for the latest Intel Core 2 multi-core processors, including 45nm CPUs. With supporting dual channel DDR2 up to 1200MHz by overclocking, GA-EP43-DS3L motherboard provides the highest levels of performance and stability. GA-EP43-DS3L delivers several advanced GIGABYTE innovations including the DES Advanced, Ultra Durable, DualBIOS design which provide optimized power savings, ultra cooling and ultra data protection. |
 |
 |
|
Smaller, Faster and More Efficient
GA-EP43-DS3L motherboards paired with Intel 45nm CPUs deliver the very best platform for multitasking, multimedia and high performance gaming. Not only do GIGABYTE's latest motherboards based on Intel Eaglelake chipsets all support Intel's new generation, 45nm multi-core processors. |
|
 |
|
Dual Channel DDR2 1200 by O.C
Experience the advanced technology of DDR2 1200 memory by overclocking, featuring faster speeds and higher data bandwidth, which delivers superior performance for the most demanding applications. * Please refer "Memory Support List" for memory support information |
|
 |
|
PCI-E 2.0 Graphics Interface
PCI-E 2.0 doubles the bus standard's bandwidth from 2.5 Gbit/s to 5 Gbit/s, meaning a x32 connector can transfer data at up to 16 GB/s in each direction. PCIE 2.0 also features improvements to the point-to-point data transfer protocol and its software architecture. |
|
 |
|
Dynamic Energy Saver Advanced
GIGABYTE Dynamic Energy Saver Advanced provides better energy saving capabilities and enhanced system performance. GIGABYTE Dynamic Energy Saver Advanced is the worlds only motherboard energy saving technology with hardware-based Dynamic 4-Gear* Switching. With support for VRD 11.1, GIGABYTEs DES Advanced allows the motherboard to switch to 1 Gear phase switching during idle, allowing for a dramatic increase in power savings.
GIGABYTE has also retooled Dynamic Energy Saver to allow overclockers to experience the benefits of multi-gear power phase switching while overclocking, providing ultra stable, ultra smooth overclocking performance.
* The 4-Gear feature may vary by model. Gear 1 phase switching requires 45nm processors with PSI signal enabled. |
|
 |
|
The Industry's Leading All-Solid Capacitor motherboard Design
To ensure a longer for systems in daily operation and boost system stability under extreme conditions, this platform adopts cutting-edge Conductive Polymer Aluminum Solid Capacitors from the world's leading vendors. With these high-quality components , users can take advantage of better electronic conductivity and excellent heat resistance for enhanced system durability. |
|
 |
|
Adjusts power consumption automatically according to your LAN cable lengths, up to 10% power savings. |
|
 |
|
Hardware Overvoltage Control ICs
Hardware Overvoltage Control ICs which provide more voltage control options than before for the CPU North Bridge and memory. The overvoltage controllers also provide hardware linear real-time voltage control. In addition, Hardware Overvoltage Controller ICs also allow for much finer voltage control, allowing power users to adjust voltage in as little increments as 20mV for better overclocking performance. |
|
 |
|
EasyTune6
GIGABYTE has completely redesigned EasyTune6 from the ground up to make it easier than ever to manage and monitor your hardware resources as well as tweak your system settings in order to achieve maximum system performance. Whether you are an overclocking enthusiast, or a computer novice, EasyTune6 provides the tools you need to quickly and effortlessly fine tune your system |
|
 |
|
DualBIOS - Patented Dual Hardware BIOS Protection
DualBIOS is a GIGABYTE patented technology that automatically recovers BIOS data when main BIOS has crashed or failed. Featuring 2 physical BIOS ROMs integrated onboard, GIGABYTE DualBIOS allows quick and seamless recovery from BIOS damage or failure due to viruses or improper BIOS updating. |
