| CNPS9300 AT |
|
| Innovatiive, patented and curved heatpipe design for a heat transfer capacity of up to four heatpipes with the use of just two. |
 |
| Pentium 4, Celeron D, Pentium D, Core 2 Duo, Core 2 Quad, Core 2 Extreme, Sempron, Athlon 64, Athlon 64 X2, Athlon 64 FX, Opteron, Dual-Core Opteron, Phenom |
|
|
|
 |
| |
 |
Socket |
|
CPU |
|
CPU Compatibility |
|
| Intel |
775 |
Celeron D |
Supports all speeds |
| Pentium 4 |
| Pentium D |
| Pentium Dual-Core |
| Core 2 Duo |
| Core 2 Quad |
| Core 2 Extreme |
| AMD |
AM2+ |
Sempron |
Supports all speeds |
| Athlon 64 |
| Athlon 64 X2 Dual-Core |
| Athlon 64 FX |
| Phenom |
| AM2 |
Sempron |
Supports all speeds |
| Athlon 64 |
| Athlon 64 X2 Dual-Core |
| Athlon 64 FX |
| 754 |
Sempron |
Supports all speeds |
| Athlon 64 |
| 939 |
Athlon 64 |
Supports all speeds |
| Athlon 64 X2 |
| Athlon 64 FX |
| Opteron |
| Dual-Core Opteron |
| 940 |
Athlon 64 FX |
Supports all speeds |
| Opteron |
| Dual-Core Opteron |
|
| |
 |
 |
| |
| Cases equipped with an Air Guide must have their Air Guide Ducts removed before installation. Install only on systems meeting the following conditions. |
| |
 |
There must be no interfering components (e.g. PSU, VGA card) within 54mm distance from the center of the PSU. |
| |
 |
There must be no interfering components (e.g. ODD) within 31mm distance from the center of the CPU. |
| |
 |
Case chassis cover must be distanced at least 143mm away from the motherboard. |
|
|
|
|
| |
 |
| |
 |
| |
| Dimensions |
61.35(L) x 108(W) x 132.5(H) mm |
| Weight |
407g |
| Base Material |
Pure Copper & Pure Aluminum |
| Dissipation Area |
2,583 |
|
| |
 |
| |
| Bearing Type |
Superflo |
| Speed |
1,500rpm 15 % ~ 2,400rpm 10 % |
| Noise Level(1) |
20.0dBA ~ 30.0dBA 10% |
| Control Method |
PWM Control, Auto Restart |
| Life Expectancy |
50,000 hours |
|
| |
| (1) Measured 1m distance away from source. |
| |
 |
|
Does not generate noise or vibration in Silent Mode. |
| |
|
Compatible with all Intel Socket 775 based Single, Dual, and Quad Core CPUs, and all AMD Socket AM2+, AM2, 754, 939, 940 based Single, Dual, and Quad Core CPUs. |
| |
|
100% copper heatsink with aerodynamically optimized tunnel design for maximum cooling efficiency. |
| |
 |
Patented figure 8 heatpipe design for cooling performance of up to 4heatpipes with the use of just 2. |
| |
 |
Low-noise 92mm PWM fan for automatic control of the fans RPM according to the CPUs temperature. |
|
|
|
| |
| |
 |
| Zalman affixes a Computer Noise Prevention System (CNPS) mark to all components used for noiseless computers. |
| |
 |
|
Excessive force exerted on the fan may damage the fan, resulting in damage to the system. |
| |
|
Check the components list and condition of the product before installation. If any problem is found, contact your place of purchase to obtain a replacement. |
| |
|
Do not ingest or make oral contact with the Thermal Grease. If ingested, get medical attention.
Disclaimer) Zalman Tech Co., Ltd. is not responsible for any damages due to external causes, including but not limited to, improper use, problems with electrical power, accident, neglect, alteration, repair, improper installation, or improper testing. |
| |
|
The operation of the PWM fan varies depending on the M/B setting. Please activate the PWM control mode from BIOS after installing. Refer to the motherboard manual for detailed information regarding the PWM control mode. |
| |
|
Zalman Tech Co., Ltd. is not responsible for any damages resulting from CPU Overclocking. |
|
|
