| LCD |
Type |
42" color TFT active matrix wide LCD |
| Display Area |
36.6" horizontal x 20.6" vertical; 42" diagonal |
| True Resolution |
1366x768 |
| Brightness |
500 (typ) |
| Contrast Ratio |
1500:1 (typ) |
| Viewing Angle |
178 horizontal, 178 vertical |
| Response Time |
8ms (typ) |
| Panel Surface |
Anti-glare, hard coating (3H) |
| Light Source |
Long life, 50,000 hrs. (typ) |
| Aspect Ratio |
16:9 |
| INPUT |
Video input |
HDMI, S-video, component, composite, RCA |
| Video output |
VGA, BNC, RCA (x2) |
| Control input/output |
RS-232 |
| INPUT SIGNAL |
TV/Video Comp. |
480i, 480p, 720p, 1080i |
| CONNECTOR |
Analog |
15-pin mini D-sub (VGA) |
| Digital |
HDMI |
| Power |
3-pin plug |
| AUDIO |
Speakers |
2x10-watt with SRS TruSurround (optional) |
| POWER |
Voltage |
AC 100-240V (universal), 50-60Hz |
| Consumption |
246W (typ) |
| CONTROLS |
Picture |
Brightness, contrast, sharpness, black level, noise reduction, tint, color, color temperature, color control, picture reset |
| Front Panel |
Exit, channel +/-, volume +/-, input, mute, power |
| Screen |
H. position, V. position, clock, clock phase, zoom mode, custom zoom, screen reset |
| Audio |
Balance, treble, bass, audio reset |
| PIP |
PIP size, PIP audio, PIP reset |
| Configuration 1 |
Auto set up, auto adjust, power save, language, screen saver, color system, configuration reset, factory reset |
| Configuration 2 |
OSD turn off, information OSD, off timer, OSD H. position, OSD V. position, monitor information |
| Advanced Option |
Input resolution, black level expansion, gamma selection, scan mode, scan conversion, film mode, IR control, monitor ID, tiling, date/time, schedule, DDC/CI, advanced option reset |
| OPERATING CONDITIONS |
Temperature |
landscape: 41-104F (5-40C) portrait: 41-95F (5-35C) |
| Humidity |
2080% (non-condensing) |
DIMENSIONS
(WxHxD) |
Physical with stand |
40.2" x 5.5" x 15.9" (1022mm x 647mm x 405mm) |
| Physical without stand |
40.2" x 24.1" x 5.0" (1022mm x 611mm x 126mm) |
| WEIGHT |
Net with stand |
69.8 lb. (31.7 kg) |
| Net without stand |
65.9 lb. (29.9 kg) |
| Gross with stand |
76.5 lb. (34.7 kg) |
| VESA MOUNT |
|
400mm x 200mm |
| REGULATIONS |
|
UL/cUL, FCC, NOM, UCIEE, S-Mark, ICES 003 |
| RECYCLING/DISPOSAL |
|
The lamp in this product contains mercury. Please dispose of in accordance with local, state and federal laws. |
