| LCD |
Type |
46" color TFT active matrix, wide LCD |
| Display Area |
40.1" horizontal x 22.5" vertical; 46.0" diagonal |
| Optimum Resolution |
1920x1080 |
| Contrast Ratio |
1500:1 (typ) |
| Viewing Angles |
176 horizontal, 176 vertical |
| Response Time |
6ms |
| Light Source |
Long life, 60,000 hrs. (typ) |
| Brightness |
450 cd/m2 (typ) |
| Aspect Ratio |
16:9 |
| Panel Surface |
Anti-glare, hard coating (3H) |
| INPUT |
Video Input |
HDMI (x2), S-video, component, composite, RCA (x2) |
| Video Output |
VGA, BNC, RCA |
| Control Input/Output |
RS-232 (in) / RS-233 (out) |
| AUDIO OUTPUT |
Speakers |
2x10-watt with SRS TruSurround (optional) |
| INPUT SIGNAL |
TV/Video Comp. |
480i, 480p, 720p, 1080i, 1080p |
| CONNECTOR |
Analog |
15-pin mini D-sub (VGA) |
| Digital |
HDMI (x2) |
| Power |
3-pin plug |
| POWER |
Voltage |
AC 115-230V (universal), 50-60Hz |
| Consumption |
285W (typ) |
| CONTROLS |
Front Panel |
Exit, channel +/-, volume +/-, input, menu, power |
| Picture |
Brightness, contrast, sharpness, black level, noise reduction, tint, color, color temperature, color control, picture reset |
| Screen |
H. position, V. position, clock, clock phase, zoom mode, custom zoom, screen test |
| Audio |
Balance, treble, bass, audio reset |
| PIP |
PIP size, PIP audio, PIP reset |
| Configuration 1 |
Auto set up, auto adjust, power save, language, screen saver, color system, configuration reset, factory reset |
| Configuration 2 |
OSD turn off, information OSD, off timer, OSD H. position, OSD V. position, monitor information |
| Advanced Option |
Input resolution, black level expansion, gamma selection, scan mode, scan conversion, film mode, IR control, monitor ID, tiling, date/time, schedule, DDC/CI, advanced option reset |
| OPERATING CONDITIONS |
Temperature |
32-104F (0-40C) |
| Humidity |
10-85% (non-condensing) |
DIMENSIONS
(W x H x D) |
Physical with stand (optional) |
44.2" x 27.7" x 15.9" (1122mm x 703mm x 404mm) |
| Physical without stand |
44.2" x 26.1" x 5.4" (1122mm x 663mm x 136mm) |
| WEIGHT |
Net with stand (optional) |
76.1 lb. (34.6 kg) |
| Net without stand |
72.6 lb. (33.0 kg) |
| Gross without stand |
94.6 lb. (42.9 kg) |
| VESA MOUNT |
|
400mm x 200mm |
| REGULATIONS |
|
UL/cUL, FCC, NOM |
| RECYCLE/DISPOSAL |
|
The lamp in this product contains mercury. Please dispose of in accordance with local and federal laws. |
