OptiColor technology Delivers 110% color saturation for richer, more precise colors. Enjoy more intense colors in your graphics, photos and documents.
ClearMotiv II 3ms video response Ultra-fast video response enables digital, HD broadcast-quality video.
4000:1 dynamic contrast ratio Provides for darker black levels and better overall front-of-screen performance.
Pivot, height and wall-mount versatility VESA wall-mount interface and detachable base for ergonomic flexibility with pivot,* height, tilt and 120o swivel adjustments.
PerfectSuite Plus control software Professional-grade LCD control software featuring color calibration, asset management, theft deterrence, and auto screen rotation.*
Full 25.5" viewable widescreen with 1920X1200 resolution
Multiple analog / digital inputs and integrated USB hub expand your connectivity
Certified for Windows Vista
|

|
 |
 |
 |
 |
 |
 |
| LCD Panel |
|
Type |
|
TFT Active Matrix WUXGA LCD |
| |
|
Display Area |
|
25.5 inch |
| |
|
True Resolution |
|
1920x1200 |
| |
|
Contrast Ratio |
|
1000:1 (typ), 4000:1 (DCR) |
| |
|
Brightness |
|
400 cd/m2 (typ) |
| |
|
Viewing Angle |
|
160 horizontal, 160 vertical (CR>10) |
| |
|
Response Time |
|
3ms (G to G) |
| |
|
Panel Surface |
|
Anti-Glare type, Hardness 3H |
 |
| Input Signal |
|
Analog |
|
RGB Analog (75 ohms, 0.7 / 1.0 Vp-p) |
| |
|
Digital |
|
DVI-D (TMDS, 100 ohms, with HDCP) |
| |
|
Frequency |
|
Fh: 24~92KHz; Fv: 50~85Hz |
| |
|
Sync |
|
Separate Sync / Composite Sync / SOG |
 |
| Compatibility |
|
PC |
|
VGA up to 1920X1200 non-interlaced |
| |
|
Mac |
|
Power Mac, up to 1920X1200 non-interlaced |
 |
| Connector |
|
Analog |
|
15 pin mini D-sub X 1 |
| |
|
Digital |
|
DVI-D X 1 |
| |
|
USB |
|
USB 2.0 up-sream X1, down-stream X4 |
| |
|
Power |
|
3-pin AC plug (CEE22) |
 |
| Power |
|
Voltage |
|
100-240VAC; 50/60 Hz (Switch) |
| |
|
Consumption |
|
120W (Max.) / 110W (Typ.) |
 |
| Controls |
|
Basic |
|
[1], [2], Soft power button, Up , Down |
| |
|
OSD |
|
Auto Image Adjust, Contrast/Brightness, Input Select (D-SUB, DVI), Color Adjust (sRGB, 9300K, 7500K, 6500K, 5000K, User Color [R,G,B]), Information, Manual Image Adjust (H/V Position, Horizontal Size, Fine Tune, Sharpness, Dynamic Contrast, Setup Menu (Language, Resolution Notice, OSD Position, OSD Timeout, OSD Background, OSD Pivot), Memory Recall |
 |
| Operating Conditions |
|
Temperature Humidity |
|
0C - 40C (32F - 104F) 10-90% (Non condensed) |
 |
| Dimensions |
|
Physical |
|
595mm(W) x 468mm(H) x 388mm(D) |
 |
| Weight |
|
Net |
|
11.5 Kgs |
 |
| Regulations |
|
|
|
UL, CUL, FCC-B (ICES), CB, CE, TCO'03, ICES-003B, ISO13406-2, TUV/GS, TUV ERGO(covers ISO13406-2 & MPRII), TUV-S, NOM, GOST-R, HYGIENIC (20 copies), Energy Star, CCC, BSMI, PSB, C-TICK, KTL/MIC, SASO, WEEE, RoHS |
 |
| Power Management |
|
|
|
Meets TCO'03 and Energy Star standards |
* VESA wall mount sold separately. |
|
