| CPU |
- Support for an Intel Core 2 Extreme processor/ Intel Core 2 Quad processor/Intel Core 2 Duo processor/Intel Pentium Dual-Core processo/Intel Celeron processor in the LGA 775 package
(Go to GIGABYTE's website for the latest CPU support list.)
- L2 cache varies with CPU
|
| Front Side Bus |
- 1333/1066/800 MHz FSB
|
| Chipset |
- North Bridge: Intel G43 Chipset
- South Bridge: Intel ICH10
|
| Memory |
- 4 x 1.8V DDR2 DIMM sockets supporting up to 8 GB of system memory
- Dual channel memory architecture
- Support for DDR2 800/667 MHz memory modules
(Because of chipset limitations, to avoid the system being unable to start or the memory being incorrectly detected, if only one memory module is to be installed, we suggest that you install it on the DDR2_1 or DDR2_3 socket; to install two memory modules, we suggest that you install them on the DDR2_1 and DDR2_3 sockets (when the DDR2_2 or DDR2_4 socket is populated with a DDR2 800 MHz memory module, the memory speed will be downgraded to 667 MHz).
(Go to GIGABYTE's website for the latest memory support list.)
|
| Onboard Graphics |
- Integrated in the North Bridge
|
| Audio |
- Realtek ALC888 codec
- High Definition Audio
- 2/4/5.1/7.1-channel
- Support for S/PDIF In/Out
- Support for CD In
|
| LAN |
- Realtek 8111C chip (10/100/1000 Mbit)
|
| Expansion Slots |
- 1 x PCI Express x4 slot (Refer to the graphics cards support list.)
- 1 x PCI Express x1 slot
- 2 x PCI slots
|
| Storage Interface |
South Bridge:
- 5 x SATA 3Gb/s connectors supporting up to 5 SATA 3Gb/s devices
- 1 x eSATA 3Gb/s port on the back panel supporting up to 1 SATA 3Gb/s device
iTE IT8213 chip:
- 1 x IDE connector supporting ATA-133/100/66/33 and up to 2 IDE devices
iTE IT8718 chip:
- 1 x floppy disk drive connector supporting up to 1 floppy disk drive
|
| IEEE 1394 |
- T.I. TSB43AB23 chip
- Up to 2 IEEE 1394a ports (1 on the back panel, 1 via the IEEE 1394 bracket connected to the internal IEEE 1394 header)
|
| USB |
- Integrated in the South Bridge
- Up to 12 USB 2.0/1.1 ports (6 on the back panel, 6 via the USB brackets connected to the internal USB headers)
|
| Internal I/O Connectors |
- 1 x 24-pin ATX main power connector
- 1 x 4-pin ATX 12V power connector
- 1 x floppy disk drive connector
- 1 x IDE connector
- 5 x SATA 3Gb/s connectors
- 1 x CPU fan header
- 1 x system fan header
- 1 x front panel header
- 1 x front panel audio header
- 1 x CD In connector
- 1 x S/PDIF In header
- 1 x S/PDIF Out header
- 3 x USB 2.0/1.1 headers
- 1 x IEEE 1394a header
- 1 x parallel port header
- 1 x serial port header
- 1 x power LED header
- 1 x chassis intrusion header
|
| Back Panel Connectors |
- 1 x PS/2 keyboard or PS/2 mouse port
- 1 x D-Sub port
- 1 x DVI-D port
- 1 x HDMI port
- 1 x optical S/PDIF Out connector
- 1 x eSATA 3Gb/s port
- 1 x IEEE 1394a port
- 6 x USB 2.0/1.1 ports
- 1 x RJ-45 port
- 6 x audio jacks (Center/Subwoofer Speaker Out/Rear Speaker Out/Side Speaker Out/Line In/Line out/Microphone)
|
| I/O Controller |
- iTE IT8718 chip
|
| H/W Monitoring |
- System voltage detection
- CPU/System temperature detection
- CPU/System fan speed detection
- CPU overheating warning
- CPU/System fan fail warning
- CPU/System fan speed control
|
| BIOS |
- 1 x 8 Mbit flash
- Use of licensed AWARD BIOS
- PnP 1.0a, DMI 2.0, SM BIOS 2.4, ACPI 1.0b
|
| Unique Features |
- Support for @BIOS
- Support for Q-Flash
- Support for Virtual Dual BIOS
- Support for Download Center
- Support for Xpress Install
- Support for Xpress Recovery2
- Support for EasyTune
- Support for Dynamic Energy Saver Advanced
- Support for Time Repair
- Support for Q-Share
|
| Bundle Software |
- Norton Internet Security (OEM version)
|
| Operating System |
- Support for Microsoft Windows Vista/XP
|
| Form Factor |
- Micro ATX Form Factor; 24.4cm x 24.4cm
|
| Remark |
- Due to different Linux support condition provided by chipset vendors, please download Linux driver from chipset vendors' website or 3rd party website.
- Due to most hardware/software vendors no longer offer support for Win9X/ME. If some vendors still has Win9X/ME drivers available, we will publish on website.
|
