| CPU |
AMD Socket AM2+ / AM2 Processors
AMD Phenom FX / Phenom / Athlon / Sempron
AMD Cool'n'Quiet Technology
Support CPU up to 140W |
| Chipset |
AMD 790GX/SB750
|
| System Bus |
Up to 5200/MT/s HyperTransport 3.0 interface for AM2+ CPU
2000 / 1600 MT/s for AM2 CPU |
| Memory |
4 x DIMM, Max. 16 GB, DDR2 1066/800/667 ECC,Non-ECC,Un-buffered Memory
Dual Channel memory architecture
*Due to AMD CPU limitation, DDR2 1066 is supported by AM2+ CPU for one DIMM per channel only.
**Please refer to www.asus.com or user manual for Memory QVL(Quality Vender List).
***When installing total memory of 4GB capacity or more, Windows 32-bit operation system may only recognize less than 3GB. Hence, a total installed memory of less than 3GB is recommended. |
| Expansion Slots |
3 x PCIe x16 (Support PCIe 2.0 / 1.0 Architecture ) (Dual x8 or Dual x16/x4; Triple x8/x4/x8)
1 x PCIe x1
2 x PCI 2.2
|
| VGA |
Integrated ATI Radeon HD 3300 GPU
SidePort Memory - onboard 128MB DDR3 1333 memory
Supports HDMI Technology with max. resolution up to 1920 x 1200 (1080P)
Supports Dual-link DVI with max. resolution up to 2560x1600 @60Hz
Supports D-Sub with max. resolution up to 2560x1440 @ 75Hz
Hybrid CrossFireX Support (For Windows Vista only)
HDMI/DVI/RGB Support
Supports Microsoft DirectX 10, OpenGL 2.0, Pixel Shader 4.0
Maximum shared memory of 512MB |
| Storage |
Southbridge
1 xUltraDMA 133/100
5 xSATA 3 Gb/s ports 1 x eSATA 3Gb/s ports with RAID 0, 1, 5 and 10 support
|
| LAN |
Gigabit LAN
|
| Audio |
Realtek ALC1200 8 -Channel High Definition Audio CODEC
-Coaxial S/PDIF out port at back I/O |
| USB |
12 USB 2.0 ports |
| ASUS AI Lifestyle Features |
ASUS Express Gate
ASUS Quiet Thermal Solution:
- ASUS AI Gear 2
- ASUS AI Nap
- ASUS Q-Fan2
- 4+1 Phases ASUS Power Design
ASUS Crystal Sound
- ASUS Noise Filter
ASUS EZ DIY:
- ASUS Q-Shield
- ASUS Q-Connector
- ASUS O.C. Profile
- ASUS EZ Flash 2
|
| Overclocking Features |
Intelligent overclocking tools:
- AI Overclocking (Intelligent CPU Frequency Tuner)
- ASUS AI Booster Utility
Precision Tweaker 2
- vCore: Adjustable CPU voltage at 0.125V increment
- vChipset (N.B.): 25-step voltage control
- vDIMM: 35-step DRAM voltage control
SFS (Stepless Frequency Selection)
- FSB tuning from 200MHz up to 600MHz at 1MHz increment
- Memory tuning from 533MHz up to 1066MHz
- PCIe frequency tuning from 100MHz up to 200MHz at 1MHz increment
Overclocking Protection:
- ASUS C.P.R. (CPU Parameter Recall) |
| Special Features |
Uses 100% All High-quality Conductive Polymer Capacitors!
ASUS MyLogo 2
AMD OverDrive Support*
* Advanced cooling system is required when advanced overclock functions of AMD OverDrive are enabled. |
| Back Panel I/O Ports |
1 x PS/2 Keyboard/Mouse
1 x S/PDIF Out (Optical)
1 x HDMI
1 x DVI
1 x D-Sub
1 x External SATA
1 x IEEE 1394a
1 x RJ45 port
6 x USB 2.0/1.1
8-Channel Audio I/O |
| Internal I/O Connectors |
3 x USB connector (6 ports)
1 x Floppy disk drive connector
1 x IDE connector
5 x SATA connectors
1 x CPU Fan connector
2 x Chassis Fan connectors
1 x Power Fan connector
Front panel audio connector
1 x IEEE 1394a connector
1 x S/PDIF Out Header
Chassis Intrusion connector
CD audio in
24-pin ATX Power connector
4-pin ATX 12V Power connector
System Panel
|
| BIOS |
8 Mb Flash ROM
DMI 2.0
AMI BIOS
PnP
WfM 2.0
SM BIOS 2.3
ACPI 2.0a
ASUS EZ Flash 2
|
| Accessories |
UltraDMA 133/100/66 cable
FDD cable
SATA cables
SATA power cables
Q-Shield
User's manual
3 in 1 Q-connector |
| Support Disc |
Drivers
Express Gate
ASUS PC Probe II
ASUS Update
AMD AOD
Anti-virus software (OEM version)
|
| Form Factor |
ATX Form Factor
12 inch x 9.6 inch ( 30.5 cm x 24.5 cm ) |
