ATEN CS-1734B 4 Port USB KVM Switch with OSD / USB 2.0 Hub - Cables Included

No Longer Available

Part Number:

88060

(?) Brand:

ATEN

Manuf No:

CS1734BC-AT
CS1734BCAT

Shipping Weight:

2.5 KG (Includes product packaging)
Estimate Shipping

Add to wishlist

Write a Review

Details Files Images & Video

All stock codes associated to this product

CS1734BCAT, CS1734BC-AT, CS1734B, CS-1734B

4-Port USB 2.0 KVMP Switch with OSD

The CS1734B is 4-port KVM switch combined with a 2-port USB 2.0 hub. As a KVM switch, it allows users to access four computers from a single keyboard, monitor, and mouse console. There are three methods to obtain instant access to any computer in your installation: Manual, Hotkey, and OSD.

Patent NO. :	TW 081926 ,CN ZL 02301212.9 ,CN ZL 01260527.1 ,DE 202004004227.4 ,US 6464197 ,US 7047344 ,US 6957287 ,TW 203183 ,TW I220489 ,TW I220476

Features

	4-port KVM switch with USB 2.0 support and 2.1 surround sound audio
	One console controls four computers and two additional USB devices
	2-port USB 2.0 hub built in
	USB 2.0 compliant
	Dual interface - supports computers with PS/2 or USB keyboard and mouse configurations
	Audio enabled - full bass response provides a rich experience for 2.1 surround sound systems
	Console audio ports on front panel for easy access ideal for IP phone users
	Supports both USB and PS/2 keyboards and mice configurations available with the included USB-to-PS/2 converter: USB keyboard and mouse; PS/2 keyboard and mouse; or PS/2 keyboard and USB mouse
	Independent switching of KVM, USB, and audio focus
	Superior video quality; 2048 x 1536; DDC2B
	Supports widescreen resolutions
	Computer selection via front panel pushbuttons, OSD (On Screen Display), and hotkeys
	Multiplatform support: Windows 2000/XP/Vista, Linux, Mac, and Sun
	Console mouse port emulation / bypass feature supports full mouse driver and multifunction mice
	Display Emulation Technology - stores the console monitor's EDID (Extended Display Identification Data) to optimize display resolution
	Complete keyboard emulation for error-free booting
	Sun/Mac keyboard support and emulation*
	Auto Scan Mode for monitoring all computers
	LED Display for easy status monitoring
	Easy installation no software required
	Firmware upgradeable *1.PC keyboard combinations emulate Sun/Mac keyboards 2.Sun/Mac keyboards only work with their own computers

Package Content

	1x 4-Port USB 2.0 KVMP Switch
	4x Custom USB KVM Cable Sets
	1x USB-to-PS/2 Converter
	2x OSD/Hotkey Stickers
	1x Firmware Upgrade Cable
	1x Power Adapter
	1x User Manual
	1x Quick Start Guide

Diagram

Specification

Computer Connections			4
Port Selection			OSD; Hotkey; Pushbutton
Connectors	Console Port	Keyboard	1 x USB Type A Female (Black)
		Video	1 x HDB-15 Female (Blue)
		Mouse	1 x USB Type A Female (Black)
		Speaker	2 x Mini Stereo Jack Female (Green)
		Mic.	2 x Mini Stereo Jack Female (Pink)
	KVM Port	Keyboard	4 x SPHD-15 Female (Yellow)
		Video
		Mouse
		Speaker	4 x Mini Stereo Jack Female (Green)
		Mic.	4 x Mini Stereo Jack Female (Pink)
	Firmware upgrade		1 x 4-conductor 3.5mm Jack (Black)
	Power		1 x DC Jack
	USB Hub		2 x USB Type A Female (White)
Switches	Selected		4 x Pushbutton
LEDs	On Line/ Selected		4 (Orange)
	USB Link		4 (Green)
Emulation	Keyboard / Mouse		PS/2; USB
Video			2048 x 1536 @ 60Hz; DDC2B
Scan Interval			1-255 seconds (Default: 5 sec.)
Power Consumption			DC5.3V, 3.4W
Environment	Operating Temp.		0-50C
	Storage Temp.		-20-60C
	Humidity		0-80% RH, Non-condensing
Physical Properties	Housing		Metal
	Weight		0.78 kg
	Dimensions ( L x W x H )		21.00 x 8.70 x 5.50 cm

* The specification and pictures are subject to change without notice.
* All trademarks and logos are the properties of their respective holders.
