Highlight
 |
The use of ultra-quiet 2-slot cooler from ZALMAN lowers the GPU temperature up to 18C compared to competitor's fansink |
|
New performance-driven layout offers space-efficient PCB layout and better components effectiveness compared to the reference design |
|
Build-in HDMI signal mixing function to transfer both video and audio data using the same cable* |
|
PCI Express 2.0 provides support for next generation PC platforms and doubles the interconnect bit rate from 2.5 GT/s to 5 GT/s (PCI Express 2.0 card is fully backwards compatible with existing PCI-E 1.0 motherboards) |
| |
Revolutionary 256-bit unified architecture GPU with GigaThread technology |
| |
The use of all solid aluminum capacitors provide ultra-high durability and stability even during overclocking |
| |
PureVideo HD delivers the ultimate HD movie experience when playing Blu-ray and HD-DVD |
| |
Ultra-high speed 512MB of GDDR3 memory |
| |
Support Dual Dual-Link DVI with awe-inspiring 2560x1600 resolution |
|
Full Microsoft DirectX 10 Shader Model 4.0 and OpenGL 2.1 support |
| |
Ultra-smoothly playback H.264, VC-1, WMV and MPEG-2 HD and SD movies |
|
Integrated HDTV encoder |
| * Via DVI-to-HDMI dongle and SPDIF-in audio cable (optional) |
Features
Ultra-quiet Cooler from ZALMAN
The use of ultra-quiet 2-slot cooler from ZALMAN lowers the GPU temperature up to 18C compared to competitor's fansink. The Zalman-original "flower" design made a name for itself with highly efficient heatsinks that work well with low airflow fan and provides an excellent combination for low noise.
New?PX9600 GT?Performance-driven Layout
New space-efficient PCB layout refines electrical characteristics to provide higher yield rate, better reliability, and longer service life. It also enhances overclocking capabilities without system instability.
PCI Express 2.0 support
Designed to run perfectly with the new PCI Express 2.0 bus architecture, offering a future-proofing bridge to tomorrow's most bandwidth-hungry games and 3D applications by maximizing the 5 GT/s PCI Express 2.0 bandwidth (twice that of first generation PCI Express). PCI Express 2.0 products are fully backwards compatible with existing PCI Express motherboards for the broadest support.
High-Speed 512MB GDDR3 Memory on Board
Enhanced memory speed and capacity ensures more flowing video quality in latest gaming environment especially in large scale textures processing.
All Solid Aluminum Capacitors
| Estimation of Life Time |
Aluminum Electrolytic Capacitor |
Aluminum Solid Capacitor |
| 85C |
8,000 h |
20,000 h |
| 65C |
32,000 h (3.6 years) |
200,000 h (22 years) |
 To ensure the high durability and stability even during overclocking and extreme condition, PX9600 GT use high-quality solid aluminum capacitors from the world's leading vendors. Solid aluminum capacitors are known for their reliability, durability and adaptability to high temperatures environments without the worry of problems such as electrolyte leakage or high heat generation.
|

Computer Display Standards
Leadtek WinFast Graphics Card Resolution Tables
 Dual Dual-Link DVI
Supports hardwares with awe-inspiring 2560-by-1600 resolution, such as the 30-inch HD LCD Display, with massive load of pixels, requiring a graphics card with dual-link DVI connectivity.
 HDCP Capable
Allows playback of HD DVD, Blu-ray Disc, and other protected content at full HD resolutions with integrated High-bandwidth Digital Content Protection (HDCP) support. (Requires other compatible components that are also HDCP capable.)
Full Microsoft DirectX 10 Shader Model 4.0 and OpenGL 2.1 support
The standard for today's PCs and next-generation consoles enables stunning and complex effects for cinematic realism.
NVIDIA SLI technology
 Delivers up to 2x the performance of a single GPU configuration for unparalleled gaming experiences by allowing two graphics cards to run in parallel. The must-have feature for performance PCI Express graphics, SLI dramatically scales performance on over 60 top PC games.
NVIDIA unified architecture
Fully unified shader core dynamically allocates processing power to geometry, vertex, physics, or pixel shading operations, delivering up to 2x the gaming performance of prior generation GPUs.
GigaThread Technology
Massively multi-threaded architecture supports thousands of independent, simultaneous threads, providing extreme processing efficiency in advanced, next generation shader programs.
Dual 400MHz RAMDACs
Blazing-fast RAMDACs support dual QXGA displays with ultra-high, ergonomic refresh rates up to 2048x1536@85Hz.
NVIDIA Quantum Effects Technology
Advanced shader processors architected for physics computation enable a new level of physics effects to be simulated and rendered on the GPUall while freeing the CPU to run the game engine and AI.
NVIDIA PureVideo HD technology
 The combination of high-definition video processors and NVIDIA DVD decoder software delivers unprecedented picture clarity, smooth video, accurate color, and precise image scaling for all video content to turn your PC into a high-end home theater.( Feature requires supported video software.)
Integrated HDTV encoder
Provides world-class TV-out functionality up to 1080 resolution.
NVIDIA ForceWare Unified Driver Architecture (UDA)
NVIDIA nView multi-display technology
|
