| LCD |
Type |
42" color TFT active matrix, wide LCD |
| Display Area |
36.6" horizontal, 20.6" vertical, 42.0" diagonal |
| Optimum Resolution |
1920x1080 |
| Contrast Ratio |
1500:1 static (typ), 10,000:1 dynamic |
| Viewing Angles |
176 horizontal, 176 vertical |
| Response Time |
6.5ms (typ) |
| Light source |
Long life, 50,000 hrs (typ) |
| Brightness |
500 cd/m2 (typ) |
| Aspect Ratio |
16:9 |
| Glass Surface |
Anti-glare, anti-reflective coat |
| Input |
PC |
RGB analog (75 ohms, 0.7 Vp-p) |
| TV |
S-video, TV/cable (x2), composite (RCA) (x2), component YPbPr/YCbCr (x2) |
| Audio |
3.5mm mini stereo audio in/out and RCA (x4)(left/right) audio in |
| RGB Frequency |
Fh: 30-64KHz; Fv: 60-75Hz |
| Sync |
H/V separated (TTL) |
| Digital |
HDMI 1.3 (x3) (with HDCP and audio support) |
| Tuner |
ATSC/NTSC/QAM |
| Audio Output |
Speakers |
2x10-watt |
| Compatibility |
PC |
640x480, 800x600,1024x768, 1280x720, 1280x1024, 1360x768, 1440x900, 1680x1050, 1920x1080 |
| Input Signal |
TV/Video comp. |
480i, 480p, 720p, 1080i, 1080p |
| Connector |
Analog |
15-pin mini D-sub (VGA) |
| Digital |
HDMI 1.3 (x3) |
| Power |
3-pin plug |
| Power |
Voltage |
AC 100-240V (universal), 50-60Hz |
| Consumption |
250W (typ) |
| Controls |
Basic |
Power, enter, channel +/-, volume +/-, menu |
| Picture |
Brightness, contrast, color, tint, sharpness, color temperature |
| TV/Audio |
Balance, bass, treble, surround, reverb, equalizer, SPDIF type, auto volume control, tuner mode, auto scan, channel skip, MTS, audio language |
| Set Up |
OSD language, aspect ratio, blue mute, time setup, closed caption, memory recall, channel block, program block, input block, change password, clear all |
| Operating Conditions |
Temperature |
32-104F (0-40C) |
| Humidity |
10-90% (non-condensing) |
| Dimensions (WxHxD) |
Physical with stand |
39.8" x 27.1" x 10.4" (1010mm x 688mm x 265mm) |
| Physical without stand |
39.8" x 25.4" x 3.9" (1010mm x 644mm x 99mm) |
| Weight |
Net with stand |
46.3 lb. (21.0 kg) |
| Net without stand |
42.0 lb. (19.1 kg) |
| Gross with stand |
51.3 lb. (26.0 kg) |
| VESA Mount |
|
200mm x 400mm |
| Regulations |
|
cUL (UL), FCC, NOM, BETS-7, CB, RoHS, HDMI |
| Recycle/Disposal |
|
The lamp in this product contains mercury. Please dispose of in accordance with local, state and federal laws. |
| Package Contents |
|
LCD TV display, power cable, remote control with batteries, Quick Start Quide, User Guide |
| Warranty |
|
One-year limited warranty on parts, labor and backlight. |
