 Widescreen aspect ratio with 1920 x 1080 resolution
The widescreen aspect ratio allows you to view HD content in its native format with no stretching or distortion.
16000:1 Dynamic Contrast Ratio
Provides darker black levels and better overall front-of-screen performance.
ClearMotiv 5ms video response time
Fast 5ms video response enables digital HD broadcast-quality video.
Multimedia enhanced
Save desk and workspace and enjoy rich, stereo sound with built-in 2Wx2 stereo speakers.
ECO Mode
Environmentally-friendly Eco-mode reduces power consumption and extends backlight life.
Aspect ratio adjustment
Eliminates image distortion by maintaining correct image proportions for both widescreen and native 4:3 content.
|
|
|
|
|
|
|
|
| LCD Panel |
|
Type |
|
21.5" wide Color TFT Active Matrix LCD 16:9 aspect ratio |
| |
|
Display Area |
|
21.5 inch |
| |
|
True Resolution |
|
1920x1080 |
| |
|
Contrast Ratio |
|
1000:1 (typ), 16000:1 (DCR) |
| |
|
Brightness |
|
300 cd/m2 (typ) |
| |
|
Viewing Angle |
|
170 (H), 160 (V) (CR10) |
| |
|
Response Time |
|
5ms |
| |
|
Panel Surface |
|
Anti-Glare, Hard coating (3H) |
| |
|
Light Source |
|
50,000 hrs (typ.) |
|
| Input Signal |
|
Analog |
|
RGB Analog (75 ohms, 0.7 / 1.0 Vp-p) |
| |
|
Frequency |
|
Fh: 24~82KHz; Fv: 50~85Hz |
| |
|
Sync |
|
Separate Sync |
|
| Compatibility |
|
PC |
|
VGA up to 19201080 Non Interlaced |
| |
|
Mac |
|
Power Mac, up to 19201080 |
|
| Connector |
|
Analog |
|
15 pin mini D-sub1 |
| |
|
Audio |
|
3.5 mm Audio line-in |
| |
|
Power |
|
Built-in power Adapter, 3-Pin plug |
|
| Audio |
|
Speakers |
|
2 2 watt |
|
| Power |
|
Voltage |
|
AC 100-240V (Universal); 50/60Hz (Switch) |
| |
|
Consumption |
|
44 (typ.) / 50 (max.) |
|
| Controls |
|
Basic |
|
[1], [2], Power, Down, Up |
| |
|
OSD |
|
Auto Image Adjust, Contrast/Brightness, Audio adjust ((for VA2213wm-2 only) Volume, mute), Color Adjust (sRGB, 9300K, 7500K, 6500K, 5000K, User Color [R, G, B]), Information, Manual Image Adjust (Horizontal Size, H/V Position, Fine Tune, Sharpness, Dynami |
|
| Operating Conditions |
|
Temperature
Humidity |
|
5C - 35C (41F - 95F)
20 - 80% (Non condensed) |
|
| Dimensions |
|
Physical |
|
512mm(W) x 388mm(H) x 246mm(D) |
|
| Weight |
|
Net |
|
4.0 Kgs |
|
| Regulations |
|
|
|
CB, TCO'03, WEEE, ROHS, UL/cUL, FCC-B, IRAM, NOM, Energy Star, ERGO, CE, Ukraine, GOST-R+Hygienic, SASO, BSMI, PSB, C-TICK, KCC, VCCI, CCC |
|
| Power Management |
|
|
|
TCO'03, ENERGY STAR |
|
