 Full HD 1080p display with 1920x1080 resolution
OptiSync digital/analog inputs expand your connectivity
Multiple input technology supports both digital (DVI,HDMI) and analog (VGA) signals for ultimate compatibility and configuration flexibility.
ClearMotiv 2ms video response time
Ultra-fast 2ms video response enables digital HD broadcast-quality video.
20,000:1 dynamic contast ratio
Provides darker black levels and better overall front-of-screen performance.
ECO Mode
Environmentally-friendly Eco-mode reduces power consumption and extends backlight life.
Aspect ratio adjustment
Eliminates image distortion by maintaining correct image proportions for both widescreen and native 4:3 content.
Stereo speakers with SRS WOW HD for amazing sound
Stylish slim-bezel design with glossy, piano-black finish
The thin bezel lets you see more without taking up valuable desktop real estate. The high neck and floating head design accentuate the visual experience.
|
|
 |
|
Model Number: VX2433wm |
|
|
|
|
|
|
|
|
|
|
| LCD Panel |
|
Type |
|
23.6" wide Color TFT Active Matrix LCD 16:9 aspect ratio |
| |
|
Display Area |
|
23.6 inch |
| |
|
True Resolution |
|
1920x1080 |
| |
|
Contrast Ratio |
|
1000:1 (typ), 20000:1 (DCR) |
| |
|
Brightness |
|
300 cd/m2 (typ) |
| |
|
Viewing Angle |
|
170 (H), 160 (V) at 5:1 c/r |
| |
|
Response Time |
|
5ms ( typ), 2ms ( max) |
| |
|
Panel Surface |
|
Anti-Glare, Hard coating (3H) |
| |
|
Light Source |
|
50,000 hrs (typ.) |
|
| Input Signal |
|
Analog |
|
RGB Analog (75 ohms, 0.7 / 1.0 Vp-p) |
| |
|
Frequency |
|
Fh: 24~83KHz; Fv: 50~76Hz |
| |
|
Sync |
|
Separate Sync / Composite Sync / SOG |
|
| Compatibility |
|
PC |
|
VGA up to 19201080 non-interlaced |
| |
|
Mac |
|
Power Mac, up to 19201080 |
|
| Connector |
|
Analog |
|
15 pin mini D-sub 1 |
| |
|
Digital |
|
DVI-D (with HDCP) / HDMI |
| |
|
Audio |
|
3.5 mm Audio in / 3.5 mm Audio out |
| |
|
Power |
|
3-pin AC plug (CEE22) |
|
| Audio |
|
Speakers |
|
2 2 watt with SRS WOW sound |
|
| Power |
|
Voltage |
|
AC 100-240V (Universal); 50/60Hz (Switch) |
| |
|
Consumption |
|
45 (typ.) |
|
| Controls |
|
Basic |
|
[1], [2], Power, Down, Up |
| |
|
OSD |
|
Auto image adjust, contrast/brightness, input select (D-sUB, DVI, HDMI PC, HDMI AV), audio adjust (volume, mute), color adjust (sRGB, 9300K, 7500K, 6500K, 5000K, user color [RGB]), information, manual image adjust (H/V position, horizontal size, fine tune, sharpness, dynamic contrast, response time, aspect ratio, display mode, ECO mode), setup menu (language, resolution notice, OSD position, OSD timeout, OSD background, sleep), memory recall |
|
| Operating Conditions |
|
Temperature
Humidity |
|
0 - 40C (32 - 104F)
20 - 90% (Non condensed) |
|
| Dimensions |
|
Physical |
|
572mm(W) x 418mm(H) x 231mm(D) |
|
| Weight |
|
Net |
|
5.0 Kgs |
|
| Regulations |
|
|
|
UL, CUL, FCC-B (ICES), CB, CE, CES-003B, VCCI, Nemko ERGO (MPR II, ISO 13406-2), TUV-S, NOM, GOST-R, HYGIENIC (20 copies), Energy Star, CCC, BSMI, PSB, C-TICK, KTL/MIC, SASO, WEEE, RoHS, Ukraine, EPEAT Silver |
|
| Power Management |
|
|
|
ENERGY STAR standards |
* VESA wall mount sold separately. |
|
