Express Internet Access
The router complies with worldwide ADSL standards. It supports downstream rates of up to 12/24 Mbps with ADSL2/2+, 8 Mbps with ADSL, and upstream rates of up to 1 Mbps. With this technology, users enjoy not only high-speed ADSL service but also broadband multimedia applications such as interactive gaming, video streaming and real-time audio much more quickly and easily than ever. Particularly, the Annex A+M model also supports the latest ADSL2/2+ for higher upload speeds by doubling the upstream data rate.
SOHO Firewall Security
Along with the built-in NAT firewall feature, the routers advanced anti-hacker pattern-filtering protection feature automatically detects and blocks Denial of Service (DoS) attacks. In addition to the NAT technology, the BiPAC 5210S RC supports Packet Filtering for high-level security control.
Easy Network Management
The Web-based User Interface makes the BiPAC 5210S RC extremely easy for users to install and manage the network. The router supports DHCP client and server, enabling system administrators to easily fit this router into existing network environment and manage the IP assignment without re-configuring other stations. Furthermore, future firmware upgrades can be downloaded via the user-friendly Web-based Interface.
Dual Flexibility
The BiPAC 5210S RC integrates both USB and Ethernet LAN interface into one box. Whenever you like, BiPAC 5210S RC lets you connect your computer by either USB cable or Ethernet port to access the Internet. You can easily share your Internet connection and multimedia applications with other users. Just plug and play and experience dual-flexibility of 10/100 Ethernet and USB at the same time.
Features & Specifications
ADSL Compliance
Compliant with ADSL Standard
- Full-rate ANSI T1.413 Issue 2
- G.dmt (ITU G.992.1)
- G.lite (ITU G.992.2)
- G.hs (ITU G.994.1)
- ADSL over ISDN / U-R2
Compliant with ADSL2 Standard
- G.dmt.bis (ITU G.992.3)
- ADSL2 Annex M (ITU G.992.3 Annex M) (Available for BiPAC 5210S RCA model only)
Compliant with ADSL2+ Standard
- G.dmt.bis plus (ITU G.992.5)
- ADSL2+ Annex M (ITU G.992.5 Annex M) (Available for BiPAC 5210S RCA model only)
Network Protocols and Features
NAT, static routing and RIP-1 / 2
Multi-to-multi NAT
Transparent Bridging
Dynamic Domain Name System (DDNS)
SNTP
DNS client/relay
USB driver support: Windows 98SE/ME/XP/2K/Vista 32/64 bit
Firewall & Virtual Private Network (VPN)
Built-in NAT Firewall
Prevent DoS attacks including Land Attack, Ping of Death, etc.
Anti probe function
Packet filtering
Password protection for system management
VPN pass-through
Operating Environment
Operating temperature: 0 - 40oC
Storage temperature: -20 - 70oC
Humidity: 20 - 95% non-condensing
ATM and PPP Protocols
ATM Adaptation Layer Type 5 (AAL5)
Multiple Protocol over AAL5 (RFC 2684, formerly RFC 1483)
Bridged or routed Ethernet encapsulation
VC and LLC based multiplexing
PPP over Ethernet (PPPoE)
PPP over ATM (RFC 2364)
OAM F4/F5
ATM QoS: UBR, CBR, VBR-rt, VBR-nrt
Management
Web-based configuration
Firmware upgrades and configuration data upload and download via HTTP/FTP
SNMP v2 MIB supported
Supports DHCP server/client/relay
TR-069 supports remote management
Hardware Specifications
Physical Interface
DSL: ADSL port
USB: Comply to USB v1.1
Ethernet: single Ethernet 10/100M auto-crossover (MDI/MDI-X) switch
Factory default reset button
Power jack
Power switch
Physical Specifications
Dimensions: 5.53" x 3.56" x 1.38 (140.5mm x 90.5mm x 35mm)
Power Requirements
Input: 12V AC, 1A
Models & Standards Supported
Product Models
BiPAC 5210S RC:
Dual-Port ADSL2+ Modem/Router Standards
BiPAC 5210S RCA:
Supports Annex A and Annex M (Annex A and Annex M: ADSL over POTS)
BiPAC 5210S RCU:
Supports Annex B and U-R2 (Annex B and U-R2: ADSL over ISDN)
Application Diagram
