All stock codes associated to this product
JFS516200AUS, JFS516-200AUS, 606449023794
PROSAFE 16-PORT 10/100 MBPS FAST ETHERNET SWITCH
JFS516
- 16 10/100 ports
- Plug and Play
- Auto-detects speed and duplex
Overview
Affordable Network Capacity
NETGEAR presents a great way to increase your networks capability without breaking your budget: the 16-port JFS516. This 10/100 Mbps Fast Ethernet switch provides expanded connectivity for small office networks so users no longer have to compete with each other for bandwidth.
All of the essential features automatic speed and full/half duplex sensing, 200 Mbps throughput per port, Auto Uplink are included, but at an economical price that a value-conscious business owner cant ignore.
Thrifty
The ideal, low-cost solution youve been looking for, the unmanaged JFS516 lets you ramp up your office network to a new power level affordably.
Capable
Sixteen switched ports provide private bandwidth for PCs, servers, or hubs, and support 200 Mbps of throughput. Each port delivers 200 Mbps of network speed in full-duplex mode.
Perceptive
As soon as its powered on, it begins operating. Every port automatically senses the proper speed and full/half duplex mode, and Auto Uplink adjusts for straight-through or crossover cables to make the right link.
Practical
This high-performance switch makes it easy to combine 10 and 100 Mbps devices within your network. As an added convenience, these sturdy metal units can be mounted in a standard 19-inch rack.
Product Specifications
Network Ports
- 16 10 or 100 Mbps RJ-45 ports
Performance (64 byte packets)
- Store-and-forward packet switching
- Forward rate (10 Mbps) 14,800 packet per sec.
- Forward rate (100 Mbps) 148,000 packet per sec.
- Latency (10 to 100 Mbps) 20 usec max
- MAC addresses 4,000
- Queue buffer KBytes 320
- Mean time between failures (MTBF): 120,000 hours (~14 years)
Physical Specifications
- Dimensions (h x w x d): 43 x 320 x 202 mm (1.7 x 13 x 8 in)
- Weight: 2.0 kg (4.4 lb)
AC Power
- 15W maximum
- Auto-sensing 100 to 240V, 50/60-Hz
- Localized plug for North America, Japan, UK, Europe, Australia
Standards Compliance
- IEEE 802.3i 10BASE-T Ethernet
- IEEE 802.3u 100BASE-TX Fast Ethernet
- Compatible with all major network software
Status LEDs
- Unit: Power
- Per network port: 10 or 100 Mbps operations, Rx/Tx and collision, link, half/full duplex
Electromagnetic Emissions
- CE mark, commercial
- FCC Part 15 Class
- EN 55022 (CISPR 22), Class A
- VCCI Class A
- C-Tick
- MIC
Environmental Specifications
- Operating temperature: 0 to 40 C
- Operating humidity: 80% max. relative humidity, non-condensing
Safety Agency Approvals
Warranty
- NETGEAR Lifetime Warranty
ProSupport Service Packs Available
OnCall 24x7, Category 1
- PMB0331-100 (US)
- PMB0331 (non-US)
XPressHW, Category 1
Package Contents
- ProSafe 16-port 10/100 Fast Ethernet Switch (JFS516)
- Power cord
- Rack-mount kit
- User guide
- Warranty card
- Support card
Ordering Information
- North America: JFS516NA
- Europe - General: JFS516GE
- Europe - UK: JFS516UK
- Asia: JFS516AU
- Japan: JFS516JP
