Multi Functional Performance
 |
Fax Function with Duplex Printing
The SyncThru Web Admin Service is the web-based management tool for configuring and monitoring Samsung network printers and other SNMP (Simple Network Management Protocol) compliant printers. Manage all the printers on your network without ever leaving your desk. |
 |
SmarThru
Samsungs SmarThru 4 is a powerful image and distribution application that allows for utmost versatility and a wide range of document management solutions. |
Status Pop-up Message
This printer features a Status Pop-up that covers all your troubleshooting needs in one easy-to-read panel. Here you can find your printer and driver settings, toner information, Power Save mode, and general troubleshooting guide. No worries, just check with the Status Pop-up. |
|
Large Paper Capacity
Multi-purpose tray carries full industry standard of 50 pages, with 250 pages in the main cassette and an additional 250 in a second cassette. Full industry standard of 550 pages saves restocking and maintenance time.

Specifications
 |
|
Print
|
|
Method
|
|
Laser Beam Printing
|
|
|
Speed*
|
|
Up to 28 ppm in A4 (30 ppm in Letter)
|
|
|
Resolution
|
|
Up to 1,200 dpi effective output
|
|
|
First Print Out Time
|
|
8.5 seconds (from Standby)
|
|
|
Emulation
|
|
PCL6
|
|
|
Duplex Print
|
|
Standard
|
|
|
Copy
|
|
Speed**
|
|
Up to 28 ppm in A4 (30 ppm in Letter)
|
|
|
Resolution (Optical)
|
|
600 x 600 dpi Text, Text/Photo mode: 600 x 300 dpi Photo mode: 600 x 600 dpi (Platen), 600 x 300 dpi (ADF)
|
|
|
First Copy out Time
|
|
8.5 Seconds (from Standby)
|
|
|
Zoom Rate
|
|
25~400% (platen), 25~100% (ADF)
|
|
|
Multi Copy
|
|
1~99 Pages
|
|
|
Scan
|
|
Compatibility
|
|
Twain standard, WIA standard
|
|
|
Method
|
|
Colour CCD
|
|
|
Resolution (Optical)
|
|
600 x 1200 dpi
|
|
|
Resolution (Enhanced)
|
|
Max 4,800 x 4,800 dpi
|
|
|
Effective Scan Length
|
|
Platen: 297 mm (11.7")
ADF: 356 mm (14.0")
|
|
|
Effective Scan Width
|
|
208 mm (8.2")
|
|
|
Colour Bit Depth
|
|
Internal: 36 Bit
External: 24 Bit
|
|
|
B/W Bit Depth
|
|
1 Bit for Text Mode
8 Bit for Gray Mode
|
|
|
Gray Scale
|
|
256 Levels
|
|
|
Fax
|
|
Compatibility
|
|
ITU-T Group
|
|
|
Applicable Line
|
|
Public Switched Telephone Network (PSTN) or behind PABX
|
|
|
Modem Speed
|
|
33.6 Kbps
|
|
|
Transmission Speed ***
|
|
Approx. 3 seconds per page
|
|
|
Compression Mode
|
|
MH / MR / MMR (ECM Mode) / JBIG / JPEG
|
|
|
Scan Speed ****
|
|
2.5 sec/letter @ 203x98dpi
|
|
|
Resolution
|
|
Max. 400 x 400 dpi
Standard : 203 x 98 dpi
Fine : 203 x 196 dpi
Super Fine : 300 x 300 dpi
Photo : 203 x 196 dpi
Color : 200 x 200 dpi
|
|
|
Memory
|
|
6 MB (Approx. 480 pages at ITU-T #1 Chart)
|
|
|
Auto Dial
|
|
1-touch dial : 30 Locations Speed dial : 240 Locations (including 1-touch dial)
|
|
|
Paper Handling
|
|
Input Capacity and Types
|
|
250-sheet Cassette Tray (75 g/, 20 lbs), 50-sheet MP Tray
|
|
|
Output Capacity and Types
|
|
150-sheet Face Down (75 g/, 20 lbs), 1-sheet Face Up
|
|
|
Media Size (for Print)
|
|
Main Tray : A4, A5, Letter, Legal, Executive, Folio, Oficio, ISO B5, JIS B5, A6
Manual Tray: A4, A5, Letter, Legal, Executive, Folio, Oficio, ISO B5, JIS B5, A6, Envelope B5/Monarch/Com-10/DL/C5/C6 - 76 x 127 mm (3" x 5") ~ 215.9 x 356 mm (8.5" x 14")
|
|
|
Media type
|
|
Tray : Plain Paper
Manual Tray : Plain Paper, Transparency, Envelope, Labels, Card stock, Thick, Thin, Cotton, Colour, Pre-Printed, Recycled, Bond, Archive
|
|
|
ADF Capacity
|
|
50 sheets (Letter / A4, 20 lb / 75 g/)
|
|
|
ADF Document Size
|
|
Width: 142 ~ 216 mm (5.6" ~ 8.5") Length: 148 ~ 356 mm (5.8" ~ 14")
|
|
|
General
|
|
Net Dimension (WxDxH)
|
|
466 x 435.4 x 458 mm (18.35" x 17.1" x 18")
|
|
|
Packing Dimension (WxDxH)
|
|
590 x 559 x 640 mm (23.3" x 22" x 25,2")
|
|
|
Weight with Consumables
|
|
18.5 Kg (40.78 lbs)
|
|
|
Packing Weight
|
|
23 Kg (50.7 lbs)
|
|
|
LCD
|
|
2 line x 16 characters
|
|
|
System Memory
|
|
96 MB (64 MB on board + 32 MB DIMM)
|
|
|
Interface
|
|
USB 2.0 (High Speed), IEEE 1284, Ethernet 10/100 base Tx
|
|
|
OS Compatibility *****
|
|
-Windows 98/Me/NT4.0/2000/XP
-Various Linux OS (via USB interface only) including Red Hat 8~9, Fedora Core 1~3, Mandrake 9.2~10.1, and SuSE 8.2~9.2
|
|
|
Warm-up Time
|
|
Less than 20 seconds (from sleep mode)
|
|
|
Noise Level ******
|
|
Warm up: Less than 49 dBA
Stand by : Less than 39 dBA
Printing: Less than 54 dBA
Copying: Less than 55 dBA
|
|
|
Power Requirement
|
|
110 ~ 127 VAC, 50/60 Hz, 6.4A 220 ~ 240 VAC, 50/60 Hz, 3.2A
|
|
|
Power Consumption
|
|
Sleep Mode: 20 W (Energy Star Compliant)
Standby Mode: 150 W
Average: 520 W
|
|
|
Operating Conditions
|
|
Temperature: 10 ~ 32 (50 ~ 89 )
Humidity: 20 % ~ 80 % RH
|
|
|
Duty Cycle, monthly
|
|
Up to 25,000 pages
|
|
|
Consumables
|
|
Type
|
|
Single Cartridge
|
|
|
Yield
|
|
High Yield : 8,000 pages at ISO 19752 5% Coverage (Ships with 4,000 pages Standard Toner Cartridge)
|
|
|
Code
|
|
Standard Toner (4K): SCX-D5530A High Yield Toner (8K) SCX-D5530B
|
|
|
Options
|
|
Others
|
|
Memory: Up to 320MB (ML-00MA/MB/MC/MD/MEM140: 16/32/64/128/256MB) Paper Cassette : 1EA x 250-sheet Cassette Tray (SCX-S5530A)
|
|
* Print speed will be affected by Operating system used, computing performance, application software, connecting method, media type, media size and job complexity.
** Copy Speed is based on Single Document Multiple Copy
*** Condition: Standard resolution, MMR(JBIG), Maximum modem speed, Phase"C" by ITU-T No.1 Chart, Memory Tx, ECM
**** Condition: ITU-T No.1 Chart, Standard Resolution
****** Sound Pressure Level, ISO7779
******* May be affected by operating environment, printing interval, media type and media size |
|
|
|
|
