No Longer Available

Part Number:
70429
(?) Brand:
Manuf No:
NVS 440 16x
Shipping Weight:
2 KG (Includes product packaging)
Estimate Shipping
All stock codes associated to this product
NVS44016x, NVS 440 16x, LNVS440X16

The NVIDIA Quadro NVS 440 multi-display graphics solution provides rock-solid hardware that delivers crystal clear images and display flexibility with support for both analog and digital displays. Combining hardware and software, the Quadro NVS 440 supports up to 256MB ultra-fast DDR3 memory and incorporates the innovative NVIDIA nView display technology, the highly efficient Lightspeed Memory Architecture (LMA) II, and the advanced NVIDIA Accuview antialiasing techniques.

Power by two state-of-the-art GPUs (Graphics Processing Units) and equipped with two high-density DMS-59 connectors and dual integrated 400 MHz RAMDACs, the Quadro NVS 440 supports up to four analog and/or digital displays. (4 x DVI-I or 4 x VGA; up to 2048x1536 at 75 Hz for analog displays and up to 1920x1200 for digital displays.) Combined with nView software which manages and displays more data faster, these features make the Quadro NVS 440 the ideal graphics solution that requires multi-display function with the best price performance.

Aim to offer superior graphics performance and value to power users, the NVIDIA Quadro NVS 440 delivers high image quality, compatibility, and stability to professionals who require such abilities as tracking data across multiple displays, navigating several desktop applications and administering the entire corporate enterprise. Quadro NVS 440 is the preferred choice for a majority of the financial trading houses, hospitals, corporate desktops, insurance, emergency dispatch (911), call centers, advertising, video wall, EDA, and process control centers. Hundreds of applications can run on Quadro NVS 440 including: Bloomberg, Reuters, Hummingbird, pcAnywhere, Lotus Notes, Microsoft Office Suites, and many others.

NVIDIA nView software allows Quadro NVS 440 users to spread their work across multiple displays instead of stacking window upon window on one monitor. Professionals can section off displays with gridlines to organize windows, gain quicker access to hidden windows using transparencies in applications and maximize desktop real estate.

NVIDIA UDA, the single unified driver for all NVIDIA graphics products, ensures high performance and image quality with a set of backward-and-forward, top-to-bottom compatible graphics drivers that make large-scale system deployment and unattended installations easy.


The Quadro NVS 440 key features:
PCI Express Standard
With double the bandwidth of the AGP 8X graphics bus, NVS 440 PCI-E x16's PCI Express solutions deliver a new level of PC performance for graphics and networking. This new bus doubles the bandwidth of AGP 8X delivering over 4 GB/sec. in both upstream and downstream data transfers.


High-Density Connectors
Provide flexible support for a variety of display types from analog to digital. Dual high-density connectors support quad-analog or digital displays (4 x DVI-I or 4 x VGA).
\
Dual 400MHz RAMDACs
Deliver crystal-clear image quality, and support to 2048 1536 at 75Hz on each display.

Intergrated TMDS Transmitters
Enable support for the latest digital flat panel (DFP) displays, resolution up to 1920 1200.

nView Multi-Display Technology
Permits work to be viewed on two monitors with nView multi-display software. The nView hardware and software technology combination delivers maximum flexibility for multi-display options, and provides unprecedented end-user control of the desktop experience.

Unified Driver Architecture
Provides easy installation and manage ability through a single unified driver for large scale system deployment.


Quadro NVS 440 Specifications
Board Features Quadro NVS 440
Memory Size 256MB GDDR3
Memory Interface 128-bit
Bus Interface         PCI-E x16
Form Factor ATX
Display Connectors DMS-59 (2)
Max Displays per Board 4 [4 VGA/DVI]
Maximum Digital Display Support 1920 x 1200
Maximum Analog Display Support 2048 x 1536
Passive Cooling Yes
nView Enabled Yes
RoHS Compliant Yes

No additional files, specification sheets, guides or documentation found for product.

Warranty: 1 Year Return to Base

Full manufacturers warranty details are available at the manufacturers (Leadtek) web site.

Unless otherwise specified Techbuy is normally your first point of contact for warranty related returns, further information regarding our warranty policies and consumer guarantees is available on our policies and service & support pages.

To apply for return of a product just go to our returns page.

These terms are in addition to and do not affect any terms, conditions, guarantees and warranties implied by law.
