Cubid CS2699 Mini-ITX Case - 60W PSU, Black
2xUSB2.0, 1xFirewire, 1xAudio, 2x40mm Fan, Mini-ITX

No Longer Available

Part Number:

71164

(?) Brand:

Cubid

Manuf No:

CS 2699

Shipping Weight:

4 KG (Includes product packaging)
Estimate Shipping

Add to wishlist

Write a Review

Details Files Images & Video

All stock codes associated to this product

CS2699, CS 2699, CS2699BR, CS-2699BR

The image “/images/P71164-I2.jpg” cannot be displayed, because it contains errors.

Model No.: CS 2699
Case dimensions(mm): 63.5(H) x 270(D) x 295(W)
Main board: Mini-ITX Form Factor (170 x 170)
Drive space: slim type DVD/CD x 1, slim type floppy x 1, normal type 3,5" x 1
LED Display: Power & HDD
USB port x 2 + Mic x 1 + Audio x 1 + IEEE1394 x 1
Expansion slot: with riser card x 1
Cooling fan(sleeve type): 2 x 4cm fan

Internal DC-DC Power Converter :
Dimensions: (mm)	160 (L) x 45 (W)
Input Voltage Required(V) :	11.4 ~ 12.60 Voltage
Input :	DC 12V in (From External AC Adapter)
Maximum Output(W) :	Output Voltage(V)	Output Current(A)	Power Output(W)	Ripple & Noise
	5VSB	1.50	7.50	50mV
	+3.3V	5.00	16.50	50mV
	+5V	5.00	25.00	50mV
	+12V	2.50	30.00	120mV
	-12V	0.10	1.20	120mV
Total :	80.20W
External Power Supply (60W AC Adapter) :
Input :	AC 100~240 V
Output :	DC 12V, 5.00A
