Raising the bar in Entry Level Workstation Graphics
Introducing the ATI FireGL V3600 workstation graphics accelerators from AMD with Unified Shader architecture - this entry-level graphics accelerator with 256MB of memory is ideal for 3D models and realistic textures for the Computer Aided Design (CAD), Digital Content Creation (DCC) and simulation markets. The ATI FireGL V3600 delivers industry leading features and performance at a very affordable price.

Innovation for Today and Tomorrow - Next Generation Professional Graphics Accelerators
With the new ATI FireGL graphics accelerators, AMD has added even more innovation with features like native multi-card support, so users can see more and do more with four displays and AutoDetect, which instinctively configures the driver for users workflow. As users move between applications, or open new ones the graphics driver settings are automatically configured for maximum performance with varied workflows. AMD provides the graphics horsepower for today's professional applications and looks forward toward tomorrows technology innovations.

Unprecedented Visual Fidelity with ATI Unified Shaders and 10-bit display pipeline
Unified Shaders maximize graphics throughput by utilizing all the processing power for whatever task is being performed. Intelligent management of computation resources enables real-time rendering of more complex and realistic images. Designed with a 10-bit display pipeline and High Dynamic Range, ATI FireGL professional graphics accelerators can produce over one billion colors for the most vibrant visual fidelity on 10bit displays.

World Class Performance, Reliability, and Support
ATI FireGL workstation graphics accelerators are thoroughly tested and certified with major Computer Aided Design (CAD) and Digital Content Creation (DCC) applications ensuring a high level of reliability and performance. ATI FireGL unified drivers simplifies installation, deployment and maintenance. AMD offers direct customer access to a dedicated professional class technical support team.

ATI FireGL Visualization Series with Unified Shader Technology

ATI FireGL V3600, ATI FireGL V5600, ATI FireGL V7600, ATI FireGL V8600, and ATI FireGL V8650

Overview

• Powered by scaleable ATI FireGL graphics accelerator with parallel processing Unified Shader architecture
• AutoDetect instinctively optimizes for users workflow
• 2 Dual Link DVI-I outputs
• High Dynamic Range (HDR) rendering with 8-bit, 10-bit & 16-bit per RGB color component support
• Full Shader Model 4.0 support for vertex and pixel shaders
• CAD and DCC application certification
• Up to 2GB GDDR4 graphics memory and 256-bit ring-bus memory controller
• 128-bit full floating point precision
• Hardware Accelerates DirectX 10 and OpenGL 2.1 advanced features

ATI FireGL Unified Shader Architecture

• Automatically directs graphics power where it is needed
• Makes better use of computation resources enabling real-time rendering of more complex and realistic images
• Intelligent management of computation resources maximizes graphics throughput at all stages of design

Display Capabilities

• 2 Dual Link DVI-I outputs support any combination of digital and analog displays
• Independent multi-monitor resolution and refresh rate selection
• Dual Link outputs ideal for driving 30-inch cinema / widescreen (2560 x 1600) displays
• Maximum individual Dual Link output capable of ultra-high resolutions up to 9 Megapixels (3840 x 2400)
• Individual Dual Link output capable of ultra-high resolutions up to 9 Megapixels (3840 x 2400)
• Stereoscopic 3D output connector with quad buffer support ¹
• Dual VGA analog support²
• HD Component Video (YPrPb) output
• Drive four 3D displays with multi-card support

API and OS Support

• OpenGL 2.1 with OpenGL Shading Language
• Microsoft DirectX 10
• Windows XP, Windows XP64
• Linux 32 and Linux 64³
• Windows Vista

System Requirements

• PCI Express based workstation with available x16 lane graphics slot
• Connection to the system power supply (adapter included)⁴
• 350-Watt power supply or greater (assumes fully loaded system)⁵
• 512MB of system memory
• Installation software requires CD-ROM drive

Warranty and Support

• Enterprise class support
• Three year limited product repair/replacement warranty
• Direct toll free phone and email access to dedicated workstation technical support team⁶
