Netgear MBM621 3G HSDPA Ethernet Modem - 3G Mobile Internet, 1x RJ45

IMG 1 of 1
No Longer Available
Part Number:
84663
(?) Brand:
Netgear Web Site
Manuf No:
MBM621-100AUS
MBM621100AUS
Shipping Weight:
2 KG (Includes product packaging)
Estimate Shipping
Details Files Finance Images & Video
All stock codes associated to this product
MBM621-100AUS, MBM621100AUS, XMBM621100AUS, XMBM621-100AUS

3G HSDPA ETHERNET MODEM

MBM621

Supports standards-based HSDPA wireless networks around the world

Connects to the Internet at broadband speeds wirelessly from anywhere there is 3G coverage

Provides auto-sensing, an AutoUplink 10/100 LAN Ethernet port that connects directly to a computer without the need for crossover cables

Mobile Connectivity Wherever You Are

Flexible Connectivity
The MBM621 supports standards-based HSDPA wireless networks around the world. Integrated into the unit is an HSDPA module and SIM card. Its easy, just plug into power and the modem will connect to your mobile operators high-speed wireless network. Imagine being able to connect to the Internet at broadband speeds wirelessly from anywhere there is 3G coverage. An ideal solution for home and small business CPE deployments.

Easy to Install and Use
The MBM621 provides auto-sensing, which is an Auto Uplink 10/100 LAN Ethernet port that can connect directly to a computer, wireless router or switch, without the need for crossover cables. HSDPA AirLink supports up to a 7.2 Mbps connection rate with receive diversity and equalizer, enabling service providers to deliver a true broadband experience wirelessly.

/upload/product/mbm621/enus_diagram1_mbm621.gif

/upload/product/mbm621/enus_diagram2_mbm621.gif



Technology/Bands

  • Tri-band HSDPA/UMTS 850**/1900/2100 MHz
  • Quad-band EDGE/GPRS 850/900/1800/1900 MHz

Advanced Technologies

  • Two-channel receiver diversity on HSDPA/UMTS 850** and 2100 MHz bands improves performance at cell edges
  • Receive equalization improves performance in noisy and highly mobile environments

Data Speeds

  • Category 6 (3.6 Mbps); future upgrade to HSDPA Category 8 (7.2 Mbps)
  • Supports 3.6 Mbps downlink and 384 Kbps uplink
  • 7.2 Mbps downlink firmware upgradeable

Power Class

  • WCDMA 850/1900 Power Class 3
  • WCDMA 2100 Power Class 3
  • GPRS 850/900 Power Class 4
  • GPRS 1800/1900 Power Class 1
  • EDGE 850/900/1800/1900 Power Class E2

RF Approvals

  • FCC parts 2, 15, 22 & 24
  • CE
  • R&TTE directive 1999/5/EC (health, safety, EMC, spectrum)
  • GCF

Routing

  • DHCP server
  • DHCP client
  • DNS proxy
  • NAT
  • Port forwarding
  • Port triggering

Protocols and Standards

  • Complies with the following standards: IPv4, TCP, UDP, DHCP, IEEE 802.2, IEEE 802.3, ICMP, HTTP, TFTP, NTP

Physical Interfaces

  • LAN port: One 10/100 Mbps auto-sensing Auto-MDI-X, RJ-45 port (one Cat 5 UTP cable included)
  • WAN: Embedded HSDPA module for Wireless WAN
  • SIM: Slot for SIM module

LEDs

  • Power
  • Test
  • LAN
  • Internet

Hardware Specifications

  • Memory: 4 MB flash, 16 MB DRAM
  • Current HSDPA module (internal module): Novatel Wireless EU870D (Optional modules: Novatel Wireless EU730/740; Sierra Wireless MC8775 and MC8780/8781)
  • 2 dBi external whip antenna
  • Power requirements: 12V DC, 1.0A; Plug is localized to country of sale, RoHS compliant

Environmental Specifications

  • Operating temperature: 32 to 104 F (0 to 40 C)
  • Storage temperature: 4 to 158 F (-20 to 70 C)
  • Operating relative humidity: 90% non-condensing

Physical Specifications

  • Dimensions: 25 x 172 x 114 mm (1 in x 6.75 in x 4.5 in)
  • Weight: 0.3 kg (0.7 lb)

No additional files, specification sheets, guides or documentation found for product.

Warranty: 1 Year Return to Base

Full manufacturers warranty details are available at the manufacturers (Netgear) web site.

Unless otherwise specified Techbuy is normally your first point of contact for warranty related returns, further information regarding our warranty policies and consumer guarantees is available on our policies and service & support pages.

To apply for return of a product just go to our returns page.

These terms are in addition to and do not affect any terms, conditions, guarantees and warranties implied by law.
