 10000:1 Dynamic Contrast Ratio
Provides for darker black levels and better overall front-of-screen performance.
Multimedia enhanced
Save desk and workspace and enjoy rich, stereo sound with built-in 2Wx2 stereo speakers.
16:10 Wide-screen experience
16:10 wide-format screen is ideally suited to maximize natural field of vision for intense game play, HD format video, and multiple document windows.
OptiSync digital/analog inputs expand your connectivity
Multi-mode input technology supports both digital (DVI) and analog (VGA) signals for ultimate compatibility and configuration flexibility.
sRGB Color Management
Ensures color accuracy from screen to print when used with other sRGB-compliant peripherals.
ClearMotiv II 5ms video response
Video response as fast as 5ms enables digital HD broadcastquality video.
|
|
|
|
|
|
|
|
| LCD Panel |
|
Type |
|
19" Wide Color a-Si TFT Active Matrix LCD |
| |
|
Display Area |
|
19 inch |
| |
|
True Resolution |
|
1440x900 |
| |
|
Contrast Ratio |
|
1000:1 (typ), 10000:1 (DCR) |
| |
|
Brightness |
|
300 cd/m2 (typ) |
| |
|
Viewing Angle |
|
160 horizontal, 160 vertical (CR 10) |
| |
|
Response Time |
|
5ms |
| |
|
Panel Surface |
|
Anti-glare, hard-coating (3H) |
|
| Input Signal |
|
Analog |
|
RGB Analog (75 ohms, 0.7 / 1.0 Vp-p) |
| |
|
Digital |
|
DVI (TMDS, 100 ohms) (DVI-D Cable optional) |
| |
|
Frequency |
|
Fh: 24~82KHz; Fv: 50~75Hz |
| |
|
Sync |
|
Separate Sync |
|
| Compatibility |
|
PC |
|
PC Compatibles (from VGA up to 1440 X 900 Non Interlaced) |
| |
|
Mac |
|
Power Mac up to 1440 X 900 |
|
| Connector |
|
Analog |
|
15 pin mini D-sub X 1 |
| |
|
Digital |
|
DVI (support HDCP and DDC/CI) (DVI-D Cable Optional) |
| |
|
Audio |
|
3.5 mm Audio line-in |
| |
|
Power |
|
Built-in power Adapter, 3-Pin plug |
|
| Audio |
|
Speakers |
|
2W X 2 |
|
| Power |
|
Voltage |
|
100-240VAC; 50/60 Hz (Switch) |
| |
|
Consumption |
|
32W (Typ.) / 36W (Max.) |
|
| Controls |
|
Basic |
|
[1], [2], Power, Down, Up |
| |
|
OSD |
|
Auto Image Adjust, Contrast / Brightness, Input Select, Color Adjust (sRGB, 9300K, 6500K, 5400K, User Color [R,G,B]), Information, Manual Image Adjust (Horizontal Size, H/V Position, Fine Tune, Sharpness), Setup Menu(Language Select, Resolution Notice, OSD |
|
| Operating Conditions |
|
Temperature
Humidity |
|
0C - 40C (32F - 104F)
10-90% (Non condensed) |
|
| Dimensions |
|
Physical |
|
440.2mm(W) x 383.4mm(H) x 195mm(D) |
|
| Weight |
|
Net |
|
4.4 Kgs |
|
| Regulations |
|
|
|
UL/CUL, FCC-B (ICES-003B), CB, CE, TCO'03, TUV/GS, TUV Ergo(covers ISO13406-2 & MPRII), TUV-S, VCCI, NOM, GOST-R (4 copies), HYGIENIC, Energy Star, CCC, BSMI, PSB, C-TICK, KTL/MIC, SASO, WEEE, RoHS, Ukraine |
* VESA wall mount sold separately. |
|
