All stock codes associated to this product
XAVB101100AUS, XAVB101-100AUS
POWERLINE AV ETHERNET ADAPTER KIT
Turn any electrical power outlet into a high speed Internet and home network connection
Easily connect TiVo, Slingbox, game consoles, or TVs
Fast enough to stream HD video
Extend Your Network Using Electrical Outlets
- Turn any electrical power outlet into a high speed Internet and home network connection
- Easily connect TiVo, Slingbox, game consoles, or TVs
- Fast enough to stream HD video
- Plug and play: just plug into a wall outlet, no setup required
Features
- Turns any electrical power outlet into an Ethernet network connection
- Delivers fast 200 Mbps speed
- Secure your Powerline AV network by just pushing a button
- For use with both wired and wireless routers and gateways
- Simply plug one XAV101 into your router and another XAV101 into any Ethernet-ready device1
- Connect a desktop, notebook PC, gaming console, NETGEAR ReadyNAS, Slingbox, a DVR or NETGEAR Print Server (PS121)
- 128-bit AES data encryption ensures privacy and security
- Red, yellow, green status LEDs indicate maximum data rate
- Supports Windows Vista
- HomePlug AV compatible
Plug-and-play connection of a Powerline Network
1 Requires use of a HomePlug AV-compatible Powerline device (two (2) XAV101 devices included).
2 XAV101 will coexist, but is not compatible nor interoperable with NETGEARs Homeplug 1.0 products including XE102, XE103, XE104, XEPS103, XET1001, and WGX102 products and UPA products, HDX101 and HDX111.
Outlets must be electrically connected in order for Powerline devices to provide a network connection between them.
Network Ports
- One 10/100 Mbps Ethernet port
- One 200 Mbps Powerline HD interface
Power Supply
LEDs
Environmental Specifications
- Operating temperature: 0-40 C (32-104 F)
- Operating relative humidity: 10% to 90% non-condensing
Physical Specifications
- Dimensions: 98 x 72 x 40 mm (3.86 x 2.83 x 1.57 in)
- Weight: 0.18 kg (0.4 lb)
Electromagnetic Emissions
- FCC Part 15 Class B
- CE
- C-Tick
Power and Safety Regulations
Typical Coverage
- Up to 5000 square foot home
