| Specifications |
| Platform |
Intel Centrino Atom processor technology
- Intel Centrino Atom processor Z530 (1.6GHz, 512 L2 Cache, 533Mhz)
- Intel System Controller Hub |
| Operating System |
Genuine Windows Vista Home Premium
(or Genuine Windows Vista Business) |
| Display |
5.6-inch SuperFine WXGA TFT10, 1280 x 800 pixels, Passive Touch Panel |
| Memory |
1x 1GB DDR2 533MHz |
| Hard Disk |
60GB HDD |
| Bluetooth |
v2.1 + EDR |
| Battery |
Up to 3.5hrs 1 on HDD / Up to 4hrs 1 on SSD(2-cell Li-Ion 2900mAh) |
| Weight |
Approx. 0.61kg |
| Detailed Specifications |
| Hard Disk Drive |
60GB HDD: 1.8-inch PATA Ultra DMA 100 (4200rpm), 2 plates, S.M.A.R.T support, Two Partitions - 50/502 |
| Graphics |
Intel Graphics Media Accelerator 500 |
| High Definition (HD) Audio |
RealTek ALC269 HD audio codec with built in speaker and digital microphone |
| Communication |
Bluetooth v2.1, RealTek Fast Ethernet, Atheros XSPAN 802.11n 3 with dual antenna, 1.3 Mega Pixel camera, GPS 11 |
| User Interface |
Keyboard with Glide Point: 68-keys, 15mm key pitch, 1.3mm key stroke
Glide Point with two buttons (left & right)
Touch Screen Panel with Stylus Pen
4 LEDs Indicator (Power-LED, DC-in/ Charge-LED, Battery Status-LED, HDD Access-LED)
|
| Card Slot |
1 x Type I/II CF Card slot
1 x Secure Digital (SD) Card Reader |
| Connector Interface |
USB 2.0 x 1, Audio-in, Audio-out, Power Adapter DC-in, VGA (external display) and RJ45 (LAN) via bundled LAN/ VGA adapter connector |
| Quick Launch Panel |
Two programmable application buttons, two programmable up/down key buttons, one rotation button, one Ctrl+Alt+Del button and one FnKey button |
| Security4 |
User and supervisor BIOS password, Boot Sector Write Prevention, Fingerprint Sensor, SMART HDD, Anti-theft Lock Slot |
| Dimensions |
Approx 171mm (W) x 135mm (D) x 26.5 - 33.0mm (H) |
| Bundled Accessories |
| AC Adapter |
Input AC100-240V, Output DC16V,2.5A (40W) |
| Bundled Software |
Microsoft Origami Experience 2.0 Pack (Runs on Genuine Windows Vista Home Premium Operating System only), Acronis True Image, Softex OmniPass, ArcSoft Camera Capture, Adobe Acrobat Reader, Sun Microsystems Java Runtime, Fujitsu UpdateNavi 5, Fujitsu Hardware Diagnostic Tool, Fujitsu Display Manager, Roxio Easy Media Creator, Microsoft Office Professional 2007 60-day Convertible Trial 6 |
| Other Softwares |
1 year Full Licensed Norman Virus Control |
| VGA/ LAN Adapter7 |
External adaptor for connection to RJ45 (LAN), VGA (external display) |
| Carrying Case7 |
Portable Slip Case |
| Optional Accessories |
| Port Replicator |
Connector Interface:
USB 2.0 x 4, VGA (external display), RJ45 (LAN), Power Adapter DC-in
Dimensions: 190 mm (W) x 110mm (D) x 159mm (H)
Weight: 0.33kg |
| Extended Battery |
Up to 7.5hrs 1 on HDD/ Up to 8.5hrs 1 on SSD (4-cell Li-Ion 5800mAh) |
