 Widescreen aspect ratio with 1920 x 1080 resolution The widescreen aspect ratio allows you to view HD content in its native format with no stretching or distortion. 18000:1 Dynamic Contrast Ratio Provides darker black levels and better overall front-of-screen performance. ClearMotiv 5ms video response time Fast 5ms video response enables digital HD broadcast-quality video. OptiSync digital/analog inputs expand your connectivity Multi-mode input technology supports both digital (DVI) and analog (VGA) signals for ultimate compatibility and configuration flexibility. ECO Mode Environmentally-friendly Eco-mode reduces power consumption and extends backlight life. Aspect ratio adjustment Eliminates image distortion by maintaining correct image proportions for both widescreen and native 4:3 content. Stylish slim-bezel design with glossy, piano-black finish The thin bezel lets you see more without taking up valuable desktop real estate. The floating head design accentuate the visual experience.
|
|
|
|
|
|
|
|
| LCD Panel |
|
Type |
|
21.5 wide Color TFT Active Matrix LCD with 16:9 aspect ratio |
| |
|
Display Area |
|
21.5 inch |
| |
|
True Resolution |
|
1920x1080 |
| |
|
Contrast Ratio |
|
1000:1 (typ), 18000:1 (DCR) |
| |
|
Brightness |
|
300 cd/m2 (typ) |
| |
|
Viewing Angle |
|
170 (H), 160 (V) (CR10) |
| |
|
Response Time |
|
5ms |
| |
|
Panel Surface |
|
Anti-Glare, Hard coating (3H) |
| |
|
Light Source |
|
50,000 hrs (typ.) |
|
| Input Signal |
|
Analog |
|
RGB Analog (75 ohms, 0.7 / 1.0 Vp-p) |
| |
|
Frequency |
|
Fh: 24~82KHz; Fv: 50~75Hz |
| |
|
Sync |
|
Separate Sync |
|
| Compatibility |
|
PC |
|
VGA up to 1920 x 1080 Non Interlaced |
| |
|
Mac |
|
Power Mac, up to 1920 x 1080 |
|
| Connector |
|
Analog |
|
15 pin mini D-sub |
| |
|
Digital |
|
DVI-D |
| |
|
Power |
|
Built-in power Adapter, 3-Pin plug |
|
| Audio |
|
Speakers |
|
2 x 2 watt |
|
| Power |
|
Voltage |
|
AC 100-240V (Universal); 50/60Hz(Switch) |
| |
|
Consumption |
|
45 (typ.) / 51 (max.) |
|
| Controls |
|
Basic |
|
[1], [2], Power, Down, Up |
| |
|
OSD |
|
Auto image adjust, Contrast/Brightness, Input select (D-SUB, DVI), Audio adjust (volume, mute), Color adjust (sRGB, 9300K, 7500K, 6500K, 5000K, User color [R, G, B]), Information, Manual image adjust (H/V Position, Horizontal size, Fine tune, Sharpness, Dynamic contrast, Aspect ratio, Eco mode), Setup menu (Language select, Resolution notice, OSD position, OSD time out, OSD background) Memory Recall |
|
| Operating Conditions |
|
Temperature
Humidity |
|
32F - 104F (0C - 40C)
20 - 90% (Non condensed) |
|
| Dimensions |
|
Physical |
|
512mm(W) x 388mm(H) x 217mm(D) |
|
| Weight |
|
Net |
|
4.2 Kgs |
|
| Regulations |
|
|
|
UL, CUL, FCC-B (ICES), CB, CE, CES-003B, ISO13406-2, GS, ERGO, NOM, GOST-R, HYGIENIC (20 copies), Energy Star, CCC, BSMI, PSB, C-TICK, MIC(KCC), SASO, WEEE, RoHS, VCCI , SASO, Ukraine, EPEAT Silver |
|
| Power Management |
|
|
|
Meets ENERGY STAR standards |
* VESA wall mount sold separately. |
|
