GA-P55A-UD3P (rev. 1.0)
Intel  P55 Chipset
  1. Industry leading 12 phase power VRM design for optimum power efficiency and thermal solution
  2. Leading quality standard of Ultra Durable 3 technology with 2oz copper PCB design
  3. Supports newest NEC SuperSpeed USB 3.0 with superfast transfer rates of up to 5 Gbps
  4. 3X USB power delivery for greater compatibility and extra power for USB devices
  5. Provides newest Marvell SE9128 high speed SATA3 storage interface with superfast 6Gbps link speed
  6. Support Intel Core i7/ Core i5 processors with LGA 1156 socket
  7. New Dynamic Energy Saver 2 technology enables best energy efficiency
  8. Innovative Smart 6 technology for smarter PC management
  9. Support ATI CrossFireX for ultimate graphics performance
  10. Features high speed Gigabit Ethernet connection
  11. Smart TPM provides 2048 bits key via Bluetooth cellphone
  12. XHD technology accelerating hard drive performance with ease
  13. AutoGreen technology Greening your PC via Bluetooth cellphone
  14. Patented GIGABYTE DualBIOS technology delivering highest level failure protection
  15. Home theater quality 8-channel High Definition Audio
  16. Compatible with Windows 7 to deliver the best operation experience
  Overview

    Industry leading 12 Phase Power VRM Design
GIGABYTE's leading 12 phase power VRM design utilizes the highest caliber components to provide unadulterated, smooth power delivery for the CPU. GIGABYTEs 12 phase power design enables better delivery of power to supercharge your system, giving power users unparalleled overclocking ability and lower temperatures to reach maximum performance levels.
The 12 phase power VRM has been designed and engineered to deliver fast transient response times through quick and seamless power delivery during extensive CPU loading variations. In addition, heat from the VRM is effectively reduced by spreading the load between the 12 power phases, resulting in a cooler and more stable platform.
  USB 3.0 Support
The GIGABYTE P55A-series motherboards support the latest generation SuperSpeed USB 3.0 technology made possible through an onboard NEC uPD720200 host controller. With superfast transfer rates of up to 5 Gbps, users are able to experience an almost a 10x improvement over USB 2.0. Additionally, backwards compatibility with USB 2.0 assures users of long term use of their legacy USB 2.0 devices. The onboard NEC SuperSpeed USB 3.0 technology also provides new power management features that include increased maximum bus power and device current draw to better accommodate power-hungry devices.

  SATA 6 Gbps Support
Yet another onboard feature of GIGABYTE P55A motherboards are Marvells new SE9128 chips for high-speed SATA Revision 3.0 compatibility, delivering superfast 6Gbps link speeds for twice the data transfer rates of SATA Revision 2.0 (3 Gbps). When used in RAID 0 (Stripe) mode, GIGABYTE P55A series motherboards offer even faster data transfer rates of up to 4x the speed of current SATA interfaces.

  3x USB Power Boost
GIGABYTE P55A-series motherboards feature a 3x USB power boost, delivering greater compatibility and extra power for USB devices. GIGABYTEs unique USB power design is also able to efficiently regulate output over the full voltage range, which greatly enhances USB device compatibility. In addition, dedicated lower resistance fuses ensure lower voltage drops, and provide more stable and plentiful power delivery.

    Ultra Durable 3

Ultra Durable 3
GIGABYTE Ultra Durable 3 design, featuring 2 ounces of copper for both the Power and Ground layers which dramatically lowers system temperature by delivering a more efficient spreading of heat from critical areas of the motherboard such as the CPU power zone throughout the entire PCB. GIGABYTE's Ultra Durable 3 also lowers the PCB impedance by 50%, which helps to reduce electrical waste and further lowers component temperatures. A 2oz Copper layer design also provides improved signal quality and lower EMI (Electromagnetic Interference), providing better system stability and allowing for greater margins for overclocking...more
    Benefits of 2 oz Copper PCB



Cooler than traditional motherboards
Enhanced durability
Improved energy efficiency
Greater margins for overclocking... more
    Smart 6- A Smarter way for PC system Management
GIGABYTE Smart 6 is designed with user-friendliness in mind, and offers a combination of 6 innovative software utilities that provide easier and smarter PC system management. Smart 6 allows you to speed up system performance, reduce boot-up time, manage a secure platform and recover previous system settings easily with a click of the mouse button.


Smart QuickBoot
No more waiting for PC Boot up

Smart DualBIOS
Smart personal reminder
Smart QuickBoost
One-click Overclocking
Smart Recorder
Your PC's Watch Dog
Smart Recovery
Reverse time for you
Smart TimeLock
Time Controller for PC
    Windows  7 WHQL Certified
The motherboard has obtained WHQL (Windows Hardware Quality Labs) certification for Windows 7 from Microsoft  for an Intel-based motherboard, setting the standard for future Windows 7 certified motherboards...more
  Dynamic Energy Saver 2
GIGABYTE Dynamic Energy Saver 2 incorporates a host of intelligent features that use a proprietary hardware and software design to considerably enhance PC system energy efficiency, Reduce power consumption and deliver optimized auto-phase-switching for the CPU, Memory, Chipset, VGA, HDD, and fans with a simple click of button.
    Intel  Core i7/ Core i5 LGA 1156 Processors



The Intel brand new computing architecture based on the innovation of micro-architecture transforms 3-chip solutions to a 2-chip platform. The next generation Intel  Core i7/ Core i5 processors with LGA1156 package integrate graphics and memory controller to support dual channel DDR3 memory. Supporting Intel Turbo Boost technology and Hyper-Threading Technology, Intel  Core i7/ Core i5 processors provide the overwhelming performance with optimized power efficiency.
  DDR3 2200+ Support
P55A-UD3P support Intel Core i7/ Core i5 processors delivering native support for DDR3 memory up to 2200+MHz by the enhanced design of GIGABYTE, Intel Core i7/ Core i5 processors feature the memory controller integrated directly into the processor die, rather than as part of the Northbridge as in previous generations, allowing for faster memory performance.
* Please refer "Memory Support List" for memory support information
  Smart TPM - A smarter , better way to protect your data
GIGABYTE Smart TPM provides the industry's highest level of data protection with 2048 bit hardware encryption. Smart TPM allows users to store their digital key on a USB thumb drive. In addition, Smart TPM allows users to lock the protected data remotely using a Bluetooth enabled mobile phone.
  XHD (eXtreme HardDrive)-Accelerating hard drive performance with ease
Accelerating system performance is made easy with the user friendly GIGABYTE eXtreme Hard Drive (X.H.D). GIGABYTE eXtreme Hard Drive (X.H.D) provides a quick and easy way to boost your hard drive performance simply by adding another hard drive.
  AutoGreen- Greening your PC via Bluetooth cellphone
AutoGreen technology can automatically save power for you simply by your bluetooth cell phone when you are away from your computer
    Multi-display support with ATI CrossFireX
P55A-UD3P supporting ATI CrossFireX delivers the ultimate in graphics performance for gaming enthusiasts who demand the highest frame rates without compromising on resolution.
  Norton Internet Security
Fast, comprehensive, and up-to-the-minute protection against online threats. It safeguards your computer, identity, and home network without slowing you down. It sets a new standard for speed and makes online shopping, banking, and browsing safer and more convenient than ever.
  Specifications
CPU
  1. Support for an Intel  Core i7 series processor/Intel  Core i5 series processor in the LGA1156 package
    (Go to GIGABYTE's website for the latest CPU support list.)
  2. L3 cache varies with CPU
Chipset
  1. Intel  P55 Express Chipset
Memory
  1. 4 x 1.5V DDR3 DIMM sockets supporting up to 16 GB of system memory
  2. Dual channel memory architecture
  3. Support for DDR3 2200/1333/1066/800 MHz memory modules
  4. Support for non-ECC memory modules
  5. Support for Extreme Memory Profile (XMP) memory modules
* Go to GIGABYTE's website for the latest memory support list.
Audio
  1. Realtek ALC889 codec
  2. High Definition Audio
  3. 2/4/5.1/7.1-channel
  4. Support for Dolby  Home Theater
  5. Support for S/PDIF In/Out
  6. Support for CD In
LAN
  1. 1 x RTL8111D chip (10/100/1000 Mbit)
Expansion Slots
  1. 1 x PCI Express x16 slot, running at x16 (PCIEX16) (The PCIEX16 slot conforms to PCI Express 2.0 standard.)
  2. 1 x PCI Express x16 slot, running at x4 (PCIEX4)
  3. 2 x PCI Express x1 slots
  4. 3 x PCI slots
* When set Turbo SATA3 / USB3.0 (Marvell 9128 /NEC USB 3.0 Controller) to enable in BIOS setup, 1st PCIex16 slot will run at x8 bandwidth and 2nd PCIex16 slot will be disabled.
Multi-Graphics Technology
  1. Support for ATI CrossFireX technology
Storage Interface Chipset:
  1. 6 x SATA 3Gb/s connectors (SATA2_0, SATA2_1, SATA2_2, SATA2_3, SATA2_4, SATA2_5) supporting up to 6 SATA 3Gb/s devices
  2. Support for SATA RAID 0, RAID 1, RAID 5, and RAID 10
Marvell 9128 chip:
  1. 2 x SATA 6Gb/s connectors (GSATA3_6, GSATA2_7) supporting up to 2 SATA 6Gb/s devices
  2. Support for SATA RAID 0
JMB362 SATA2 chip:
  1. 2 x eSATA 3Gb/s connectors on the back panel supporting up to 2 SATA 3Gb/s devices
  2. Support for SATA RAID 0, RAID 1, and JBOD
iTE IT8213 chip:
  1. 1 x IDE connector supporting ATA-133/100/66/33 and up to 2 IDE devices
iTE IT8720 chip:
  1. 1 x floppy disk drive connector supporting up to 1 floppy disk drive
USB Chipset:
  1. Up to 12 USB 2.0/1.1 ports (8 on the back panel, 4 via the USB brackets connected to the internal USB headers)
NEC chip:
  1. Up to 2 USB 3.0/2.0 ports on the back panel
Internal I/O Connectors
  1. 1 x 24-pin ATX main power connector
  2. 1 x 8-pin ATX 12V power connector
  3. 1 x floppy disk drive connector
  4. 1 x IDE connector
  5. 6 x SATA 3Gb/s connectors
  6. 2 x SATA 6Gb/s connectors
  7. 1 x CPU fan header
  8. 2 x system fan headers
  9. 1 x power fan header
  10. 1 x front panel header
  11. 1 x front panel audio header
  12. 1 x CD In connector
  13. 1 x S/PDIF In header
  14. 1 x S/PDIF Out header
  15. 2 x USB 2.0/1.1 headers
  16. 1 x serial port header
  17. 1 x parallel port header
  18. 1 x clearing CMOS jumper
Back Panel Connectors
  1. 1 x PS/2 keyboard or PS/2 mouse port
  2. 1 x coaxial S/PDIF Out connector
  3. 1 x optical S/PDIF Out connector
  4. 8 x USB 2.0/1.1 ports
  5. 2 x USB 3.0 ports
  6. 2 x eSATA 3Gb/s ports
  7. 1 x RJ-45 port
  8. 6 x audio jacks (Center/Subwoofer Speaker Out/Rear Speaker Out/ Side Speaker Out/Line In/Line)
I/O Controller
  1. iTE IT8720 chip
H/W Monitoring
  1. System voltage detection
  2. CPU/System temperature detection
  3. CPU/System/Power fan speed detection
  4. CPU overheating warning
  5. CPU/System/Power fan fail warning
  6. CPU/System fan speed control
BIOS
  1. 2 x 16 Mbit flash
  2. Use of licensed AWARD BIOS
  3. Support for DualBIOS
  4. PnP 1.0a, DMI 2.0, SM BIOS 2.4, ACPI 1.0b
Unique Features
  1. Support for @BIOS
  2. Support for Q-Flash
  3. Support for Xpress BIOS Rescue
  4. Support for Download Center
  5. Support for Xpress Install
  6. Support for Xpress Recovery2
  7. Support for EasyTune
  8. Support for Dynamic Energy Saver 2
  9. Support for Smart TPM
  10. Support for Smart 6
  11. Support for Auto Green
  12. Support for eXtreme Hard Drive
  13. Support for Q-Share
Bundle Software
  1. Norton Internet Security (OEM version)
Operating System
  1. Support for Microsoft  Windows 7/Vista/XP
Form Factor
  1. ATX Form Factor; 30.5cm x 24.4cm
Remark
  1. Due to different Linux support condition provided by chipset vendors, please download Linux driver from chipset vendors' website or 3rd party website.
  2. Due to most hardware/software vendors no longer offer support for Win9X/ME. If some vendors still has Win9X/ME drivers available, we will publish on website.
Note
  1. TPM function is optional due to different regional policy
* The entire materials provided herein are for reference only. GIGABYTE reserves the right to modify or revise the content at anytime without prior notice.
* All trademarks and logos are the properties of their respective holders.

* Due to standard PC architecture, a certain amount of memory is reserved for system usage and therefore the actual memory size is less than the stated amount.
