ATEN Altusen Console Module - PS/2-USB For KM0932/0532/0032 With Audio

No Longer Available

Part Number:

137309

(?) Brand:

ATEN

Manuf No:

KA7230

Shipping Weight:

3 KG (Includes product packaging)
Estimate Shipping

Date Added:

26/2/2010

Add to wishlist

Write a Review

Details Files Finance Images & Video

All stock codes associated to this product

KA7230, KVAKA7230, KVA-KA7230, 4710423776272

Altusen PS/2-USB Console Module for KM0932/0532/0032 with Audio

PS/2-USB Console Module

The KA7230 Console Module offers secure access to the servers in a Matrix KVM Switch (KM0932/KM0532) from a PS/2 or USB console (monitor, keyboard, and mouse) up to 300 meters away. It provides an extra computer port for integration with a computer workstation, enabling users to seamlessly switch between the local computer and the servers in the Matrix KVM Switch. The KA7230 also features an intuitive graphical user interface, the Graphical OSD, with easy-to-use menus and icons that enable easy access and efficient management.

KA7230 has a built-in RS-232 port. Administrators can establish a serial terminal login to the Console Module in order to control the KVM port access for all consoles connected to switch any console can be assigned to access any KVM port from a single interface point. This function is extremely useful in large data centers where the display of all the consoles can be projected onto a wall for easy viewing of all operations, and the entire installation can be monitored on a port-by-port basis.

Patent NO. :	CN ZL 98252015.8 ,CN ZL 01124239.6 ,CN ZL 02122202.9 ,CN ZL 200410031689.0 ,CN ZL 200410042771.3 ,DE 29903667.7 ,DE 102004017843 ,DE 102004019107 ,TW 194030 ,TW 150098 ,TW 183765 ,TW D108320 ,TW I276963 ,TW I237762 ,TW I269992 ,TW I243890 ,US 6160543 ,US 6489854 ,US 7386584 ,JP 3917598 ,JP 4160936 ,GB 2412456 ,FR 0500514

Features

	One Combo Graphic Console Module can control a local computer and a matrix KVM switch (KM0932/KM0532)
	Supports PS/2 and USB keyboards and mice(Console)
	Switch between your workstation computer and the matrix KVM switch
	Graphical OSD-intuitive, easy-to-use graphical On Screen Display to manage servers
	RS-232 port login support permits an administrator to control the KVM port access for all consoles connected to switch any console can be assigned to access any KVM port from a single interface point
	Connects to matrix KVM switch via Cat 5e/6apple cable
	Superior video quality 1280 x 1024 @ 60 Hz for up to 300 m
	Manual video gain control for fine tuning
	Convenient computer selection via intuitive hotkey combinations or graphical OSD menus
	Firmware upgradeable

Package Content

	1x KA7230 PS/2-USB Console Module with stacking brackets
	1x KVM Cable
	1x Power Adapter
	1x RS-232 Cable (DB-9F to DB9-F)
	1x Grounding Wire
	1x Rack Mount Kit
	1x User Guide

Diagram

Specification

Computer Connections			2 (KVM Port), 1 (Local Computer)
Console Connections			1
Port Selection			GUI, Hotkey
Connectors	Console Port	Keyboard	1 x USB Type A Female (White) 1 x 6-pin Mini-DIN Female (Purple)
		Video	1 x HDB-15 Female (Blue)
		Mouse	1 x USB Type A Female (White) 1 x 6-pin Mini-DIN Female (Green)
	Local Computer KVM Port		1 x SPHD-17 Female (Yellow)
	KVM Switch Ports		2 x RJ-45 Female
	RS-232		1 x DB-9 Male (Black)
	Power		1 x DC Jack
Switches	Local/Remote		1 x Pushbutton
	F/W Upgrade		1 x Slide
	Video Gain Adjustment		2 x Pushbutton
LEDs	Power		1 (Blue)
	Online		1 (Green)
	Local		1 (Orange)
	Remote		1 (Orange)
Emulation	Keyboard / Mouse		PS/2; USB (PC, Sun, Mac)
Video			1280 x 1024 @ 60Hz (300m max.)
Scan Interval			1-240 Seconds
Power Consumption			DC5.3V,6.5W
Environment	Operating Temperature		0 - 50C
	Storage Temperature		-20 - 60C
	Humidity		0-80% RH, Non-condensing
Physical Properties	Housing		Metal
	Weight		1.22 kg
	Dimensions ( L x W x H )		17.15 x 22.71 x 5.48 cm (including stacking bracket)

No additional files, specification sheets, guides or documentation found for product.

Warranty: 1 Year Return to Base

Full manufacturers warranty details are available at the manufacturers web site.
