Altusen 32 Port 9 Console Matrix KVM Switch w/Virtual Media, Dual Power
9-Console 32-Port Matrix KVM Switch
ATEN Matrix KVM Switches are designed for modern data centers that require reliable, high security access and control of multiple servers. With non-blocked access and flexible expansion support, Matrix KVM switches offer high quality video sessions for secure, real-time control of your entire data center devices.
With automatic skew compensation and Auto Signal Compensation (ASC) techniques, Matrix KVM switches provide greatly enhanced video quality via Cat 5e/6 cabling - 1280x1024 @60Hz for up to 300 meters. The industrys first full screen Graphical User Interface offers a tree view list of installed devices - providing smooth navigation and convenient access and control - not only saving on training time and costs; but increasing user efficiency, as well.
Features
Hardware
- 9 consoles independently and simultaneously control up to 32 directly connected servers
- Flexible expansion - the installation can grow as your needs grow:
- Up to 7 Matrix Expansion KVM switches can be daisy chained from a master switch
- Switches can be cascaded to three levels to access and manage more than 8,000computers (supports KH1508 / KH1516 switches for economical expansion)
- Dual root configuration allows up to 18 consoles to access any servers on the installation
- Audio support for multimedia-capable devices
-
Redundant power supply for 24 x 7 reliability
- Multiplatform support: PC, Mac, Sun, and Serial Console access any type of console can control any type of computer; mixed combinations (PS/2 & USB) supported on both the console and computer sides
- Compact design rack mounts in only 1U of rack space
- Easy-To-Use Interface
- Full screen graphical user interface saves on training time and costs increases user efficiency
- Embedded web interface for easy system configuration and management
- Composite tree view all connected devices are integrated in a single device tree for convenient management access and control
-
The port list automatically expands when stations are added port names are automatically reconfigured when the station sequence changes
- Multilingual user interface support English, German, Japanese, Korean, Traditional Chinese, Simplified Chinese, Russian
Convenient Port Operation
- Computer selection via GUI or intuitive hotkey combinations
-
Port level access control users can only access the ports they have been authorized for whether in a single-station or multi-stage installation
- Users can access features on multiple computers simultaneously a user can be working and listening to music on computer 1 while utilizing virtual media on computer 2 at the same time.
- Versatile port operation modes for flexible server management:
- Scan provides automatic monitoring of user-selected computers
- Exclusive allows the first user to access a port to gain exclusive viewing rights and control over it for as long as he accesses it
- Occupy allows the first user to access a port to control that port while others can only view it
- Share allows multiple users to access and control a port at the same time on a cooperative basis
-
Broadcast support enables executing the same command on multiple servers at the same time
Management
-
Broadcast support enables executing the same command on multiple servers at the same time
- Three level password security: Super Administrator, Administrator, User
- Stringent password policy features that include password expiration; required password changes, account disabling, and account expiration.
- Intelligent Path Assignment a master station can allocate the best available path for the user under multi-path cascading and daisy-chaining
- Power Over the NET integration for power control
- Power Association enables the switchs KVM ports to be associated with a PN0108s power outlets for remote power management of the servers from the switchs interface
- RS-232 port login support permits an administrator to control the KVM port access for all consoles connected to switch any console can be assigned to access any KVM port from a single interface point
- Session Management a Kill Session function provides administrators with the ability to force user logouts
-
Backup and restore of configuration settings and user account information
- Firmware upgrades can be performed simultaneously on all daisy chained and cascaded slave switches as well as connected adapter cables
-
Adapter ID adapter cables configuration information is stored with the adapter no need to reconfigure the adapter when moving a server to a new port
- Event Log support
Virtual Media
- Virtual Media support lets you map storage media to servers that are connected to the switch allowing operators to conduct file transfers, install applications and OS patches, and perform diagnostics from a single console
- Works with USB enabled servers at the operating system and BIOS levels
-
Supports DVD/CD drives, USB mass storage devices
Video
- Users display automatically adjusts to resolution differences on the remote servers
- Superior video quality 1280 x 1024 @ 60 Hz for up to 300 m
- Auto Signal Compensation (ASC) assures optimum video resolution for distances up to 300 m between computers and consoles no DIP switch setting required
- Enhanced video quality via automatic skew compensation support for the KA7240 console module, and the newer KVM adapter cable series (KA7120, KA7170, KA7130, KA7176)
Package Content
-
1x KM0932 Matrix KVM Switch
- 2x Power Cords
- 1x Grounding Wire
- 1x Rack Mount Kit
-
1x Foot Pad Set (4 pcs.)
- 1x User Manual
-
1x Quick Start Guide
Diagram
