  • Connect to system via superspeed USB 3.0 or eSATA port (connecting cable included).
  • Install up to five 3.5" SATA hard drives of any capacity (drives not included).
  • Drives are added or removed like tape cartridge from each drive bay with no special tool required.
  • Drives can be configured as RAID0 (Striping), RAID1 (Mirroring), RAID5 (Parity), RAID10 (Mirrored Striped), JBOD* (Concatenation), Clone Mode (N-Way Mirror) using built-in hardware RAID.
  • OS independent, can be used on any system when all drives are configured as a single RAID volume.
  • For Windows operating systems, confiure RAID using RAID diagnostic software utility.
  • For Linux and Mac operating systems, configure RAID using onboard jumpers

Components list made up this model:
Storage Tower V (ST5), 5X1 HPM-XA Enclosure Version (AD5HPMRXA-E), 5 units Snap-In Mobile Rack (AESNAPMRSA), USB 3.0 to eSATAp Adapter (ADU3ESA), one 3-foot eSATA cable (AAESATA100C).

The RAID Tower V is built basing on the Storage Tower platform that features five 5.25" drive bays in a lightweight and compact chassis with a stylish and functional front bezel. Depending on the model, up to eight 3.5" hard drives can be installed into the RAID Tower V. The drives can be configured as a RAID set and be connected to the computer via the high speed eSATA or USB 3.0/2.0connection. Each model comes with everything needed for connecting to the computer. All is needed is to add your own hard drives and configure the RAID via either a simple on board rotary switch or onboard jumpers/software utility depending on the model of the RAID Tower.

RAID Tower V Basic Specification

  • Great for variety of storage applications - external RAID storage, Video storage, Server storage
  • Sturdy and attractive black metal frame construction
  • Compact size - 7.5 x 16 x 10.4 inches
  • Support any SATA 1.0, 2.0 or 3.0 hard drive
  • Sturdy metal frame construction
  • Ball bearing high CFM low noise cooling fans
  • 320 watts 110/240V AC power supply
  • LED indicators for each storage device, RAID status, host connection and power

No additional files, specification sheets, guides or documentation found for product.


You can finance this product via Flexirent! For more information regarding flexirent, and to use the flexirent finance calculator, please click here.

The calculator provides an indicative rental cost only. Flexirent prices quoted include GST and stamp duty. Subject to credit approval. To obtain full quote and pre-approval please contact Flexirent Customer Service on 1800 240 102. Rental is payable monthly.

Warranty: 1 Year Return to Base

Full manufacturers warranty details are available at the manufacturers (Addonics) web site.

Unless otherwise specified Techbuy is normally your first point of contact for warranty related returns, further information regarding our warranty policies and consumer guarantees is available on our policies and service & support pages.

To apply for return of a product just go to our returns page.

These terms are in addition to and do not affect any terms, conditions, guarantees and warranties implied by law.
