| Operating indicators |
|
| Visual |
Large LED (red/green/blue) |
| Non-visual |
Buzzer |
| Operating keys |
|
| Entry options |
1 scan key |
| Communication |
|
| Bluetooth |
Ver. 1.2, SPP, output power class 2, range up to 10 m, 1 to 1 connection, master/slave mode, authentication and encryption |
| Power |
|
| Current consumption |
165mA (typical use), max. 220mA |
| Rechargeable battery |
Lithium-Ion 3.7V 1620mAh |
| Operating time |
Ca. 25 hours (1 scan / 5 sec) |
| Charging method |
Separate cradle CHG3101 or CRD3101 |
| Barcode scanner Optics |
|
| Light source |
650 nm visible laser diode |
| Scan method |
Bi-directional scanning |
| Scan rate |
100 scans/sec |
| Trigger mode |
Manual, auto-trigger |
| Reading pitch angle |
-35 to 0, 0 to +35 |
| Reading skew angle |
-50 to -8, +8 to +50 |
| Reading tilt angle |
-20 to 0, 0 to +20 |
| Curvature |
R>15 mm (EAN8), R>20 mm (EAN13) |
| Min. resolution at PCS 0.9 |
0.127 mm / 5 mil |
| Min. PCS value |
0.45 |
| Depth of field |
40 - 720 mm / 1.57 - 28.35 in (1.0 mm / 39 mil), 20 - 430 / 0.79 - 16.93 in (0.5 mm / 20 mil), 20 - 230 / 0.79 - 9.06 in (res 0.25 mm / 10 mil), 20 - 120 mm / 0.79 - 4.72 in (0.15 mm / 6 mil), 30 - 100 mm / 1.18 - 3.94 in (0.127 mm / 5 mil), at PCS 0.9, Code 39 |
| Supported Symbologies |
|
| Barcode (1D) |
JAN/UPC/EAN incl. add on, Codabar/NW-7, Code 11, Code 39, Code 93, GS1-128 (EAN-128), GS1 DataBar (RSS), IATA, Industrial 2of5, Interleaved 2of5, ISBN-ISMN-ISSN, Matrix 2of5, MSI/Plessey, S-Code, Telepen, Tri-Optic, UK/Plessey |
| Postal code |
Chinese Post, Korean Postal Authority code |
| 2D code |
Composite codes, MicroPDF417, PDF417 |
| Durability |
|
| Temperature in operation |
-10 to 60 C / 14 to 140 F |
| Temperature in storage |
-20 to 60 C / -4 to 140 F |
| Humidity in operation |
5 - 95% (non-condensing) |
| Humidity in storage |
5 - 95% (non-condensing) |
| Ambient light immunity |
Fluorescent 4,000 lx max, Direct sun 80,000 lx max, Incandescent 4,000 lx max |
| Drop test |
2 m / 6.5 ft drop onto concrete surface |
| Vibration test |
10 - 100 Hz with 2G for 30 min |
| Protection rate |
IP 54 |
| Physical |
|
| Dimensions (w x h x d) |
68 x 165 x 155 mm / 2.68 x 6.50 x 6.10 in |
| Weight body |
Ca. 290 g / 10.2 oz (incl. battery) |
| Case |
ABS, Black or White |
| Regulatory & Safety |
|
| Product compliance |
CE, FCC, VCCI, RoHS, EN300 328, EN301 489, JIS-C-6802 Class 2, IEC 60825-1 Class 2, FDA CDRH Class II |
