Momentus Thin Overview 1 Drive
Opens new frontiers for system designers.
Seagate has purpose-built the Momentus Thin hard drive to meet our customers demand for affordable, slimmer, fully functional computing solutions. Meet your needs with 500GB, 320GB, 250GB and 160GB capacity options.
While traditional laptop hard drives offer a z-height of 9.5 mm, Momentus Thin hard drives stands apart with a z-height of just 7mm.
Smooth migration to Advanced Format.
Momentus Thin hard drives include Seagate SmartAlign technology. This innovation helps you easily get all the benefits of the new Advanced Format 4K sector standardno utilities, no extra steps.
Momentus Thin Overview 2 Drive with 4K icon
Secure Self-Encrypting Drive options.
Momentus Thin Self-Encrypting Drives deliver government-grade encryption without performance degradationprotecting your data where it lives. You get all the benefits of secure data encryption without the headaches.
  • The first Seagate SED to ship with the Trusted Computing Group (TCG) Opal protocol
  • The worlds first 7mm SED to ship with FIPS 140-2 validation
Momentus Thin Overview 3 Drive and lock icons
Momentus Thin  Features 1 Seagate logo
Enter Seagate® ingenuity.
Until recently, system integrators and OEMs had no choice but to limit their thinner, fully functional computing designs to high-end devices. The available hard drive options were either too costly, too slow performing or both.
Enter Seagate ingenuity. Momentus® Thin hard drives leverage current laptop drives in both material and product design to provide the world’s first 7mm 2.5-inch form factor drive.
The result is affordable, thin storage for entry-level to mainstream laptops, high-end netbooks, thin ultraportables and more. Momentus Thin drives open new frontiers in slim-computing design.
Seagate SmartAlign technology for easy 4K migration.
A change is coming to the hard drive industry. The smallest sector of organized data on a drive is moving from 512 to 4,096 bytes. The new format, known as Advanced Format (AF) 4K, offers advantages like increased efficiency, but migrating your drive can be challenging.
Luckily, Seagate is ready to help you make a seamless transition to 4K sectors.
Momentus Thin hard drives feature Seagate SmartAlign technology, which automatically does the work of AF migration in the background. The drive's performance is not affected, and there is no need for time-consuming utilities required by other AF-enabled drives.
Momentus Thin Features 2 Drive and 4K icons
Momentus Thin Features 3 Drive and lock icons
Optimal security with Self-Encrypting Drives.
Momentus Thin hard drives are available as Self-Encrypting Drives (SED) that help secure your data the instant you save it to your drive. For government-grade security, the Momentus Thin hard drive can also be purchased as a FIPS 140-2 Validated SED.
Lost laptop? Rest easy knowing that your data is secure and 100% encryptedalways. Momentus Thin hard drive features include:
  • Instant on-the-fly encryption without performance degradation
  • Instant SecureErase technology that can instantly erase the security key data on your hard drive, enabling secure and easy disposal or repurposing of the drive
Capacity 500GB 320GB 250GB 160GB
Form Factor 2.5" 2.5" 2.5" 2.5"
Interface Options SATA 3Gb/s SATA 3Gb/s SATA 3Gb/s SATA 3Gb/s
Spindle Speed (RPM) 5400 7200, 5400 7200, 5400 5400, 7200
Cache (MB) 16 16 16 16
Transfer Rate, Max Ext (MB/s) 600 300, 600 300, 600 300
Sustained Data Rate OD
Average Latency (ms) 5.6 4.17, 4.2, 5.6 4.17, 5.6 5.6, 4.17
Reliability/Data Integrity
Nonrecoverable Read Errors per Bits Read 1in 1014 1in 1014 1in 1014 1in 1014
Annualized Failure Rate (AFR)   0.50%, 0.48% 0.50% 0.50%
Power Management
Seek, Typical Operating (W) 1.40 1.60, 1.40 1.60, 1.40 1.40, 1.60
Idle, Typical Operating (W) 0.45 0.66, 0.58, 0.48, 0.45 0.66, 0.48, 0.45 0.48, 0.66
Operating 0to60C 0to60C 0to60C 0to60C
Non-operating -40to70C -40to70C -40to70C -40to70C
Operating: Gs (ms) 400(2ms) 350(2ms), 400(2ms) 350(2ms), 400(2ms) 350(2ms)
Non-operating: Gs (ms) 1000(1ms) 1000(1ms) 1000(1ms) 1000(1ms)
Acoustics (bels - sound power)
Idle 2.0 2.3, 2.4, 2.0 2.3, 2.0 2.0, 2.3
Operating 2.2 2.5, 2.2 2.5, 2.2 2.2, 2.5
Height (in/mm) 0.276/7.0 0.276/7.0 0.276/7.0 0.276/7.0
Width (in/mm) 2.760/70.10 2.76/70.10, 2.760/70.10 2.76/70.10, 2.760/70.10 2.76/70.10
Length (in/mm) 3.959/100.55 3.959/100.55 3.959/100.55 3.959/100.55
Height (in/mm) (maximum)   0.276/7.0 0.276/7.0
Width (in/mm) (maximum)   2.76/70.10 2.76/70.10
Length (in/mm) (maximum)   3.959/100.55 3.959/100.55 3.959/100.55
Weight (lb/g) 0.209/95 .203/92, 0.209/95 .203/92, 0.209/95 .203/92
