NTSC |
PAL |
| SENSOR SECTION |
| Image Sensor |
1/5.8" BSI MOS Sensor |
1/5.8-type BSI MOS Sensor (For Europe)
1/5.8" BSI MOS Sensor (For Asia) |
| Total Pixels |
2.51 megapixels |
2.51 megapixels |
| Effective Pixles |
Motion Image |
2.07 megapixels [16:9] |
2.07 megapixels [16:9] |
| Still Image |
2.07 megapixels [16:9] |
2.07 megapixels [16:9] |
| LENS SECTION |
| F Value |
F1.8 (WIDE) / F4.2 (TELE) |
F1.8 (WIDE) / F4.2 (TELE) |
| Optical Zoom |
38x |
38x |
| Focal Length |
2.35 - 89.3 mm |
2.35 - 89.3 mm |
35 mm Film
Camera
Equivalent |
Motion Image |
34.4 - 1646 mm [16:9] |
34.4 - 1646 mm [16:9] |
| Still Image |
34.4 - 1646 mm [16:9] |
34.4 - 1646 mm [16:9] |
| Lens Brand |
Panasonic Lens |
Panasonic Lens |
| CAMERA SECTION |
| Standard Illumination |
1400 lx |
1400 lx |
| Minimum Illumination |
4 lx (Scene Mode Low Light 1/30),
1 lx (Color Night Rec.) |
4 lx (Scene Mode Low Light 1/25),
1 lx (Colour Night View) |
| Focus |
Auto / Manual |
Auto / Manual |
| Zoom |
Intelligent Zoom OFF |
48 x |
48 x |
| Intelligent Zoom ON |
72 x |
72 x |
| Digital Zoom |
100 x / 2500 x
(The maximum value of zoom magnification) |
100 x / 2500 x
(The maximum value of zoom magnification) |
| White Balance |
Auto / Indoor1 / Indoor2 / Sunny / Cloudy / White set |
Auto / Indoor1 / Indoor2 / Sunny / Cloudy / White set |
| Shutter Speed |
Motion Image |
[60i]
Auto Slow Shutter ON : 1/30 - 1/8000
Auto Slow Shutter OFF : 1/60 - 1/8000 |
[50i]
Auto Slow Shutter ON : 1/25 - 1/8000
Auto Slow Shutter OFF : 1/50 - 1/8000 |
| Iris |
Auto / Manual |
Auto / Manual |
| Image Stabilizer |
Image Stabilizer |
Image Stabilizer |
| RECORDING SECTION |
| Recording Media |
SD/SDHC/SDXC Memory Card |
SD/SDHC/SDXC Memory Card |
| Recording Format |
[AVCHD] AVCHD
[iFrame] [MP4] MP4 |
[AVCHD] AVCHD
[iFrame] [MP4] MP4 |
| Compression Method |
MPEG-4 AVC/H.264 |
MPEG-4 AVC/H.264 |
| Recording/ Playback Mode |
HA (17Mbps / VBR), (1920 x 1080)
HG (13Mbps / VBR), (1920 x 1080)
HE (5Mbps / VBR), (1920 x 1080)
iFrame (28Mbps / VBR), (960 x 540)
MP4 (1.5Mbps / VBR), (640 x 360) |
HA (17Mbps / VBR), (1920 x 1080)
HG (13Mbps / VBR), (1920 x 1080)
HE (5Mbps / VBR), (1920 x 1080)
iFrame (28Mbps / VBR), (960 x 540)
MP4 (1.5Mbps / VBR), (640 x 360) |
| Thumbnail Display |
20 thumbnails/page,
9 thumbnails/page,
1 thumbnail/page |
20 thumbnails/page,
9 thumbnails/page,
1 thumbnail/page |
| Audio Recording System |
HA, HG, HE: Dolby Digital (2ch)
iFrame, MP4: AAC (2ch) |
HA, HG, HE: Dolby Digital (2ch)
iFrame, MP4: AAC (2ch) |
| Microphone |
2ch Stereo |
2ch Stereo |
| Speaker |
Dynamic type |
Dynamic type |
| STILL IMAGE SECTION |
| Recording Format |
JPEG (DCF/Exif2.2) |
JPEG (DCF/Exif2.2) |
| Recirding Image Size |
Simultaneous Recording |
[16:9] 8.9 megapixels (3968 x 2232),
2.1 megapixels (1920 x 1080) |
[16:9] 8.9 megapixels (3968 x 2232),
2.1 megapixels (1920 x 1080) |
| GENERAL SECTION |
| Power Supply |
3.6V (Battery) / 5.0V (AC Adaptor) |
3.6V (Battery) / 5.0V (AC Adaptor) |
| Power Consumption |
Max. 3.5W (Recording) / Max. 5.3W (Charging) |
Max. 3.5W (Recording) / Max. 5.3W (Charging) |
| Dimensions (W x H x D) |
Approx. 53 x 60 x 114 mm
(2.087 x 2.362 x 4.488 inch) |
Approx. 53 x 60 x 114 mm
(2.087 x 2.362 x 4.488 inch) |
| Weight (w/o battery and SD card) |
Approx. 181g (0.399lb) |
Approx. 181g (0.399lb) |
| LCD Monitor |
2.7" Wide LCDmonitor (230,400 dots) |
6.7 cm (2.7") Wide LCDmonitor (230,400 dots) (For Europe)
2.7" Wide LCDmonitor (230,400 dots) (For Asia) |
| Interface |
AV |
Yes |
Yes |
| HDMI |
Yes (mini) |
Yes (mini) |
| USB |
2.0 Hi-Speed |
2.0 Hi-Speed |
| USB Charge |
Yes |
Yes |
| On-Screen Display Language |
 |
|
| STANDARD ACCESSORY |
| AC Adaptor |
Yes |
Yes |
| Rechargeable Battery Pack |
Yes (970 mAh) |
Yes (970 mAh) |
| HDMI Cable |
Yes (mini)* |
Yes (mini)** |
| AV Cable |
Yes*** |
Yes**** |
| USB Cable |
Yes |
Yes |
| Bandled Software |
HD Writer LE 2.0 |
HD Writer LE 2.0 |
