Intel Xeon Processor E5-2420 v2 (15M Cache, 2.20 GHz)

Status Launched
Launch Date Q1'14
Processor Number E5-2420V2
# of Cores 6
# of Threads 12
Clock Speed 2.2 GHz
Max Turbo Frequency 2.7 GHz
Intel Smart Cache 15 MB
Intel QPI Speed 7.2 GT/s
# of QPI Links 1
Instruction Set 64-bit
Instruction Set Extensions Intel AVX
Embedded Options Available
Lithography 22 nm
Scalability 2S Only
Max TDP 80 W
VID Voltage Range 0.65-1.30V
Additional Information URL Link
Memory Specifications
Max Memory Size (dependent on memory type) 384 GB
Memory Types DDR3-800/1066/1333/1600
# of Memory Channels 3
Max Memory Bandwidth 38.4 GB/s
Physical Address Extensions 46-bit
ECC Memory Supported
Expansion Options
PCI Express Revision 3.0
PCI Express Configurations   x4, x8, x16
Max # of PCI Express Lanes 24
Package Specifications
Max CPU Configuration 2
Package Size 45mm x 42.5mm
Sockets Supported FCLGA1356
Low Halogen Options Available See MDDS
Advanced Technologies
Intel Turbo Boost Technology   2.0
Intel Hyper-Threading Technology
Intel Virtualization Technology (VT-x)
Intel Virtualization Technology for Directed I/O (VT-d)
Intel VT-x with Extended Page Tables (EPT)
Intel TSX-NI No
Intel 64
Idle States Yes
Enhanced Intel SpeedStep Technology
Intel Demand Based Switching
Thermal Monitoring Technologies Yes
Intel Flex Memory Access No
Intel Identity Protection Technology   No
Intel Data Protection Technology
AES New Instructions
Secure Key Yes
Intel Platform Protection Technology
OS Guard Yes
Trusted Execution Technology Yes
Execute Disable Bit   Yes
