Datacenter Capacity HDD
WD Se
Overview
WD Se datacenter capacity storage is an ideal solution for scale-out datacenters, delivering a cost-effective combination of performance, capacity, and workload capability, while maintaining the hardiness of a true enterprise-class design. WD Se is best suited for bulk cloud storage, distributed file systems, replicated environments, cost-efficient RAID architectures and content delivery networks (CDNs).
Cost effective enterprise-class storage.
Get the right blend of performance, workload capability and capacity and keep your total cost of ownership low.
24x7x365 reliability.
Choose the storage foundation specifically designed for large-scale datacenter replication environments running 24x7x365.
High capacity for hyperscale environments.
Build a massive data footprint with capacities up to 6 TB - 216 TB per square foot.
Designed for quality and reliability.
Datacenter drives undergo at least 5 million hours of functional testing, and over 20 million hours of comprehensive Interoperability testing in an extensive array of server and storage systems. Please see the product AVL list on our website for more information.
Dual processor
Twice the processing power to maximize performance.
Dual actuator technology
A head positioning system with two actuators that improves positional accuracy over the data track(s). The primary actuator provides coarse displacement using conventional electromagnetic actuator principles. The secondary actuator uses piezoelectric motion to fine tune the head positioning to a higher degree of accuracy. (2 TB and above)
StableTrac
The motor shaft is secured at both ends to reduce system-induced vibration and stabilize platters for accurate tracking during read and write operations. (2 TB and above)
Multi-axis shock sensor
Automatically detects the subtlest shock events and compensates to protect the data.
Vibration Protection
Enhanced RAFF technology includes sophisticated electronics to monitor the drive and correct both linear and rotational vibration in real time. The result is a significant performance improvement in high vibration environments over the previous generation of drives.
RAID-specific, time-limited error recovery (TLER)
Prevents drive fallout caused by the extended hard drive error-recovery processes common to desktop drives.
Thermal extended burn-in test
Each drive is put through extended burn-in testing with thermal cycling to ensure reliable operation.
Dynamic fly height technology
Each read-write head's fly height is adjusted in real time for optimum reliability.
NoTouch ramp load technology
The recording head never touches the disk media ensuring significantly less wear to the recording head and media as well as better drive protection in transit.
Environmentally responsible.
In addition to being RoHS compliant, these drives are built with halogen reduced components.
The WD advantage.
WD puts our datacenter products through extensive Functional Integrity Testing (F.I.T) prior to any product launch. This testing ensures our products consistently meet the high quality and reliability standards of the WD brand. Following a FIT test the Enterprise System Group (ESG) testing validates interoperability with HBAs, operating systems and drivers to ensure an even greater level of quality, reliability and peace of mind.
WD also has a detailed Knowledge Base with helpful articles and software utilities. Our customer support lines have longer operational hours to ensure you get the help you need when you need it. Our toll-free customer support lines are here to help or you can access our WD Support site for additional details.
Specifications
| WD5001F9YZ |
SATA 6 Gb/s |
3.5 Inch |
7200 |
5 TB |
128 MB |
