| Supported Operating Systems |
| Operating system |
Windows 7 Professional 64 (available through downgrade rights from Windows 10 Pro 64) |
| Operating system note |
This
system is preinstalled with Windows 7 Professional software and also
comes with a license and media for Windows 10 Pro software. You may only
use one version of the Windows software at a time. Switching between
versions will require you to uninstall one version and install the other
version. You must back up all data (files, photos, etc.) before
uninstalling and installing operating systems to avoid loss of your
data. |
| Processor |
| Chipset |
Mobile Intel® CM236 |
| Processor speed |
2.8 GHz |
| Processor family |
Intel® Xeon® processor |
| Processor |
Intel®
Xeon® E3-1505M v5 with Intel HD graphics P530 (2.80 GHz, up to 3.70 GHz
with Intel Turbo Boost Technology, 8 MB cache, 4 cores) |
| Memory |
| Memory, standard |
16 GB DDR4-2133 (2 x 8 GB) |
| Memory slots |
2 SODIMM |
| Standard memory note |
Transfer rates up to 2133 MT/s |
| Drives |
| Hard drive description |
512 GB HP Z Turbo Drive PCIe SSD |
| Storage type |
SSD |
| Display Specifications |
| Display size (diagonal) |
15.6" |
| Display |
15.6" diagonal UHD UWVA IPS anti-glare LED-backlit (3840 x 2160) |
| Graphic Subsystem |
| Graphics |
HP ZBook Studio special edition NVIDIA® Quadro® M1000M (4 GB dedicated GDDR5) |
| Multimedia |
| Audio |
Bang
& Olufsen HD audio. Integrated stereo speakers and microphone
(dual-microphone array when equipped with optional webcam). Button for
volume mute, functions keys for volume up and down. Combo
microphone-in/stereo headphone-out jack. |
| Multimedia and Input Devices |
| Camera |
720p HD webcam |
| Input devices |
| Keyboard |
HP Spill Resistant Keyboard (backlit with function key control) |
| Pointing device |
Image sensor clickpad with on/off button, two-way scroll, gestures, two buttons |
| Connectivity and Communications |
| Network interface |
Intel® Dual Band Wireless-AC 8260 802.11 a/b/g/n/ac (2x2) non-vPro Wi-Fi and Bluetooth® 4.0 combo |
| Ports |
1 RJ-45
1 USB 3.0
1 USB 3.0 (charging) |
| Expansion slots |
1 SD UHS-II flash media |
| Expansion slots note |
SD supports next generation secure digital and is backward compatible to SDHC, SDXC |
| I/O Port location |
Left side |
| Ports |
1 power connector
2 Thunderboltâ„¢ 3
1 HDMI 1.4
1 USB 3.0
1 stereo microphone-in/headphone-out combo |
| I/O Port location |
Right side |
| External I/O ports footnote number |
[9] |
| Battery and Power |
| Battery type |
HP Long Life 4-cell 64 Wh Li-ion prismatic |
| Power |
150 W Slim Smart AC adapter (external) |
| Weights |
| Weight |
Starting at 2 kg |
| Security Management |
| Security management |
One-step logon
Common Criteria EAL4+ Augmented Certified Discrete TPM 1.2/2.0 Embedded Security Chip
Security lock slot
Support for Intel® AT
HP FingerPrint Sensor
Absolute Persistence Module
HP BIOSphere with Sure Start
SATA port disablement (via BIOS)
DriveLock and Automatic DriveLock
RAID (available as a configurable option)
Serial, parallel, USB enable/disable (via BIOS)
Optional USB port disable at factory (user configurable via BIOS)
Removable media write/boot control
Power-on password (via BIOS)
Setup password (via BIOS) |
| Security management footnote number |
[16,17,18] |
| Software and Applications |
| Software |
HP
Mobile Workstations are shipped with a variety of software titles
including: HP Performance Advisor, HP Remote Graphics Software, HP
Client Security, Microsoft Security Essentials, Microsoft Defender, HP
ePrint Driver, HP PageLift. Please refer to this product's quick spec
document for a full list of preinstalled software. |
| Software footnote number |
[14,15] |
| Dimensions |
| Minimum dimensions (W x D x H) |
375 x 255 x 18 mm |
| Warranty |
| Warranty |
3
years standard parts, labour and on-site limited warranty, depending on
country (upgrades available), 3 years limited warranty on primary
battery |
