Part Number:
411474
(?) Brand:
Manuf No:
MFY-B2NN-13NMK-R1
MFYB2NN13NMKR1
Shipping Weight:
0.2 KG (Includes product packaging)
Estimate Shipping
Date Added:
All stock codes associated to this product
MFYB2NN13NMKR1, MFY-B2NN-13NMK-R1, 3711646, 4719512052587, 884102028694

 Overview

In tackling your cases cooling needs, there is no one fan fits all. Each of the three 120mm fans in the MasterFan Pro series provides a specific air cooling solution while all being fitted with multiple layers of our exclusive noise reduction technology and adjustable speed profiles. Put together, they work in harmony to cool your entire case and its components. Air Balance fans are ideal for blowing air through denser. We recommend them for use on CPU air coolers or the front panel.

Hybrid Design

  • Draws from both jet engine and helicopter blade designs.

Speed Profiles

  • Switch between three curve profiles for your preferred mix of silence and speed.

Quiet Spin

  • Exclusive technology stabilizes the driver that spins the blades, reducing clicks and noisy vibrations.

Noise Absorption

  • Rubber mounting inserts on the frame absorb fan rattle.

Jam Protection

  • Automatically stops the fan motor if jammed by objects.

Specifications

Model number

MFY-B2NN-13NMK-R1

LED Color

Non-LED

Dimensions (LxWxH)

120(L) x 120(W) x 25(H) mm

Speed

S Mode (Silent)

Q Mode (Quiet)

P Mode (Performance)

650-1,300 RPM 10%

650-2,000 RPM 10%

650-2,500 RPM 10%

Airflow

S Mode (Silent)

Q Mode (Quiet)

P Mode (Performance)

42.7 CFM 10%

66.7 CFM 10%

83.1 CFM 10%

Air Pressure

S Mode (Silent)

Q Mode (Quiet)

P Mode (Performance)

0.96 mmH2O 10%

2.34 mmH2O 10%

3.63 mmH2O 10%

Life Expectancy

490,000 hrs

Noise Level (dBA)

S Mode (Silent)

Q Mode (Quiet)

P Mode (Performance)

6 - 20 dBA

6 - 30 dBA

6 - 36 dBA

Bearing Type

POM Bearing

Connector

4-Pin (PWM)

Rated Voltage

12 VDC

Rated Current

S Mode (Silent)

Q Mode (Quiet)

P Mode (Performance)

0.07A

0.15A

0.23A

Power Consumption

S Mode (Silent)

Q Mode (Quiet)

P Mode (Performance)

0.84W

1.8W

2.76W

Weight

164g

Accessory

4x Tap Screw

Warranty

2 years

EAN Code

4.71951E+12

UPC Code

8.84102E+11
