Hardware
Specs |
|
|
CPU |
ARM v7 1.1 GHz
Dual-core |
|
System
memory |
1GB DDR3
RAM |
|
Flash
Memory |
4
GB |
|
Hard Disk
Drive |
2 x 3.5" SATA 3Gb/s
HDDs |
|
LAN
Port |
1 x Gigabit RJ-45
Ethernet port |
|
USB
Port |
1 X USB 3.0
(Front) |
|
1 X USB 2.0
(Rear) |
|
LED
Indicators |
HDD 1-2, LAN, Status,
USB |
|
Buttons |
Power/Status, USB
One-Touch-Backup, reset |
|
Alarm
Buzzer |
System
warning |
|
Form
Factor |
Mini-tower |
|
Dimensions |
187.7(H) x 90(W) x
125(D) mm |
|
7.36(H) x 3.54(W) x
4.92(D) inch |
|
Weight |
Net: 0.7 kg
(1.54lbs) |
|
Gross: 1.88 kg
(4.14lbs) |
|
Power
Consumption |
HDD standby6.05W |
|
(HDD standby
mode) |
In operation13.24W |
|
(with 2 x 2TB HDDs
intalled) |
|
Sound
Level* |
Sound pressure (LpAm):
17.0 dB(A) |
|
Temperature &
Humidity |
0 - 40 C5-95%
RH |
|
Power
Supply |
External Power Adapter
60W, 100-240V |
|
Fan |
Yes |
|
Software
Specs |
|
|
|
|
Operating
System |
Storage
Management |
|
QTS 4.2 (embedded
Linux) |
1. Single Disk, JBOD,
RAID 0, 1 |
|
2. Bad block scan and
hard drive S.M.A.R.T. |
|
3. Bad block
recovery |
|
4. RAID
recovery |
|
5. Bitmap
support |
|
Supported Client
OS |
Power
Management |
|
1. Windows XP and
Windows Server 2003 onward |
1. Automatic power on
after power recovery |
|
2. Apple Mac OS
X |
2. USB and network UPS
support with SNMP management |
|
3. Linux &
UNIX |
|
|
Supported
Browsers |
Access Right
Management |
|
1. Microsoft Internet
Explorer 10+ |
1. Batch users
creation |
|
2. Mozilla Firefox
8+ |
2. Import/Export
users |
|
3. Apple Safari
4+ |
3. User quota
management |
|
4. Google
Chrome |
4. Local user access
control for CIFS, AFP, FTP, and WebDAV |
|
5. Application access
control for Photo Station, Music Station, Video Station, and Multimedia
Station |
|
6. Subfolder
permissions support for CIFS/SMB (3.0), AFP, FTP, and File
Station |
|
Multilingual
Support |
myQNAPcloud
Service |
|
1. Chinese (Traditional
& Simplified), Czech, Danish, Dutch, English, Finnish, French, German,
Greek, Hungarian, Italian, Japanese, Korean, Norwegian, Polish, Portuguese
(Brazil), Romanian, Russian, Spanish, Swedish, Thai,
Turkish |
1. Private cloud
storage and sharing with myQNAPcloud id (qid) |
|
2. Free host name
registration (DDNS) |
|
3. Auto router
configuration (via UPnP) |
|
4. Web-based file
manager with HTTPS 2048-bit encryption |
|
5. CloudLink for remote
access without any complicated router setup |
|
File
System |
Qsync |
|
1. Internal Hard Drive:
EXT4 |
1. Syncs files among
multiple devices with SSL support |
|
2. External Hard Drive:
EXT3, EXT4, NTFS, FAT32, HFS+ |
2. Selective
synchronization for syncing specific folders only |
|
3. Share team folder as
a file center for team collaboration |
|
4. Shares files by
links via e-mail |
|
5. Policy settings for
conflicting files and file type filter support |
|
6. Version control: up
to 64 versions. |
|
7. Supports Windows
& Mac OS |
|
8. Incremental
synchronization for HDD space saving |
|
Networking |
Web
Administration |
|
1. TCP/IP :
IPv4 |
1. Multi-window,
multi-tasking based system management |
|
2. Proxy client, proxy
server |
2. Personalized
desktop |
|
3. DHCP client, DHCP
server |
3. Smart toolbar and
dashboard for neat system status display |
|
4. Protocols: CIFS/SMB
(3.0), AFP (v3.3), NFS(v3), FTP, FTPS, SFTP, TFTP, HTTP(S), Telnet, SSH,
SNMP, SMTP, and SMSC |
4. Dynamic DNS
(DDNS) |
|
5. UPnP & Bonjour
Discovery |
5. Login screen with
personalized photo-wall style |
|
6. Smart fan
control |
|
7. SNMP (v2 &
v3) |
|
8. Resource
monitor |
|
9. Network recycle bin
for file deletion via CIFS/SMB (3.0), AFP, and File
Station |
|
Automatic
Cleanup |
|
File Type
Filter |
|
10. Comprehensive logs
(events & connection) |
|
11. Syslog
client/server |
|
12. System settings
backup and restore |
|
13. Mobile app:
Qmanager for remote system monitoring &
management |
|
Security |
|
|
1. Network access
protection with auto-blocking: SSH, Telnet, HTTP(S), FTP, CIFS/SMB (3.0),
AFP |
|
|
2. CIFS host access
control for shared folders |
|
|
3. Importable SSL
certificates |
|
|
4. Instant alerts via
email, SMS, beep |
|
|
Powerful All-in-one
server |
|
|
File
Server |
Video
Station |
|
1. File sharing across
Windows, Mac, and Linux/UNIX |
1. Show photos by
thumbnails, list, timeline, or folder view |
|
2. Windows
ACL |
2. Supports
virtual/smart collections |
|
3. Advanced folder
permissions for CIFS/SMB (3.0), AFP, FTP |
3. Validity control for
sharing collections |
|
4. Shared folder
aggregation (CIFS/SMB (3.0) |
4. Tag videos with
text, color, and ratings |
|
5. Animated thumbnails
for videos |
|
6. Share video links to
social websites or through email |
|
7. Sorting videos
automatically into defined classifications |
|
8. Share video links to
social websites or through email |
|
9. Display movie
information from IMDB |
|
10. Mobile app: Qvideo
for online video browsing and management |
|
FTP
Server |
Cloud Backup
Station |
|
1. FTP over SSL/TLS
(Explicit) |
1. Amazon
S3 |
|
2. FXP
supported |
2. Amazon
Glacier |
|
3. Passive ftp port
range control |
3. WebDAV-based cloud
storage |
|
4. Microsoft
Azure |
|
5.
OpenStack |
|
File
Station |
Download
Station |
|
1. Supports ISO
Mounting (Up to 256 ISO Files) |
1. PC-less BT,
FTP/FTPS, and HTTP/HTTPS, Thunder, FlashGet and qqdl download (up to 500
Tasks) |
|
2. Support thumbnail
display of multimedia files |
2. BT download with
Magnet Link and PT support |
|
3. Supports sharing
download links and upload links |
3. The maximum number
of concurrent downloads for an ARM-based NAS is 30 (10 BT/PT downloads, 10
HTTP, 10 FTP downloads) |
|
4. Drag-n-drop Files
via Chrome and Firefox Browsers |
4. Scheduled download
and bandwidth control |
|
5. Photo, music, and
video preview and playback |
5. RSS subscription and
download (broadcatching) |
|
6. File Compression
(ZIP or 7z) |
6. Proxy support for BT
download |
|
7. Bulk download with
wildcard settings |
|
8. BT
search |
|
9. PC utility: Qget for
downloads browsing and management |
|
10. Mobile app: Qget
for downloads browsing and management |
|
Backup
Station |
Surveillance
Station |
|
1. Remote replication
server (over rsync) |
1. Supports over 3,000
IP cameras |
|
2. Real-time remote
replication (RTRR) to another QNAP NAS or FTP server |
2. Includes 2 free
camera licenses, up to 8 camera channels by purchasing additional
licenses |
|
3. Works as both RTRR
server & client with bandwidth control |
3. Instant playback to
check recent events |
|
4. Real-time &
scheduled backup |
4. Visual aid by
e-map |
|
5. Compression, file
filter, and transfer rate limitation |
5. Playback and speed
control using the shuttle bar |
|
6. Desktop backup with
QNAP NetBak Replicator for Windows |
6. Video preview on
playback timeline |
|
7. Apple Time Machine
backup support |
7. Intelligent video
analytics (IVA) for advanced video searching |
|
8. Data backup to
multiple external storage devices |
8. Surveillance client
for Mac |
|
9. Synchronizes with
cloud storage: Amazon Drive, Dropbox*, and Google Drive. |
9. Mobile surveillance
app: Vmobile (iOS and Android) |
|
10. Third party backup
software support: Veeam backup & replication, Acronis True Image,
Arcserve backup, emc retrospect, Symantec Backup Exec,
etc. |
10. Mobile recording
app: Vcam (iOS and Android) |
|
Print
Server |
VPN
Server |
|
1. Max number of
printers: 3 |
1. Secure remote
access: PPTPL2TP/IPsec & OpenVPN VPN services |
|
2. Supports Internet
Printing Protocol |
2. Max number of
clients: 30 |
|
3. Print job display
and management |
|
|
4. IP-based and domain
name-based privilege control |
|
|
Hybrid Backup Sync
(beta) |
VPN
Client |
|
1. Amazon
Drive |
1. Supported VPN
protocols: PPTP & OpenVPN services |
|
2. Google
Drive |
2. PPTP Authentication:
PAP, CHAP, MS-CHAP, MS-CHAPv2 |
|
3.
Dropbox |
3. PPTP Encryption:
None, AES 40/128 bit, AES 256 bit |
|
4. Microsoft
OneDrive |
4. OpenVPN Encryption:
None, AES 40/128 bit, AES 256 bit |
|
5.
Yandex.Disk |
5. Transmission package
monitor |
|
6.
Box |
6. OpenVPN port
control |
|
7. OpenVPN link
compression |
|
Station |
DLNA
Server |
|
1. Show photos by
thumbnails, list, timeline, or folder view |
1. Supports DLNA/UPnP
TVs and Players such as PlayStation 3 and Xbox 360 |
|
2. Supports
virtual/smart albums |
2. Support CUE indexing
file |
|
3. Validity control for
sharing albums |
* DRM encryption format
is not supported. |
|
4. Tag photos with
text, colors, and ratings |
|
|
5. Slideshows with
background music and different transition effects |
|
|
6. Geotag photos and
display them on Google maps |
|
|
7. Animated thumbnails
for videos |
|
|
8. Shares slideshows
link to social websites or through email |
|
|
9. Supports
modification on photo taken date |
|
|
10. Supports Facebook
friends login |
|
|
Music
Station |
Mobile
App |
|
1. Play or share music
via web browser |
1. Qfile: iOS, Android,
Window phone& Tablets |
|
2. Internet radio
(MP3) |
2. Qmanager: iOS,
Android Phone |
|
3. Up to 8 music
alarms |
3. Qmusic: iOS,
Android Phone |
|
4. Mobile app: Qmusic
for music streaming and management |
4. Qget: Android
Phone |
|
* DRM encryption format
is not supported. |
5. Vmobile: iOS, iPad,
Android Phone |
|
iTunes
Server |
|
|
1. Audio and video
sharing for Windows & Mac iTunes |
|
